GLOWWORM
ULTRACOM 38 CXI - (Hydraulic/Pump)
Appliance Code: 47-019-03

Appliance Diagram


Hydraulic/Pump diagram for Glowworm Ultracom 38 CXIClick the diagram to open it on a new page

You can then pinch & zoom to adjust the size.

  LIMITER 16 L/MIN
Glowworm part no. 0020070706		 £9.87
62 Part number 0020037291, Pipe, return PIPE, RETURN
Glowworm part no. 0020037291		 £27.37
63 Part number 0020037287, Pipe, flow PIPE, FLOW
Glowworm part no. 0020037287		 £34.84
64 Part number S212332, SEALING WASHER 24.5X18.2MM SEALING WASHER 24.5X18.2MM
Glowworm part no. S212332		 £6.57
88 Part number 0020014183, O-ring (PK10) O-RING (PK10)
Glowworm part no. 0020014183		 £11.19
98 Part number 0020014403, heat exchanger DHW (20 plates) HEAT EXCHANGER DHW (20 PLATES)
Glowworm part no. 0020014403		 £190.67
99 Part number 0020038094, Screw M5X87 (PK4) SCREW M5X87 (PK4)
Glowworm part no. 0020038094		 £10.52
100 Part number 0020014166, Gasket, C-Type, (PK10) GASKET, C-TYPE, (PK10)
Glowworm part no. 0020014166		 £10.01
101 Part number 0020038227, connection piece CONNECTION PIECE
Glowworm part no. 0020038227		 £14.29
102 Part number 0020038228, connection piece CONNECTION PIECE
Glowworm part no. 0020038228		 £14.55
103 Part number 0020038230, pipe PIPE
Glowworm part no. 0020038230		 £12.13
104 Part number 0020038089, O-ring (PK10) O-RING (PK10)
Glowworm part no. 0020038089		 £6.61
106 Part number 0020038234, filter FILTER
Glowworm part no. 0020038234		 £6.61
107 Part number 0020038083, pipe PIPE
Glowworm part no. 0020038083		 £26.09
109 Part number 0020038092, pipe PIPE
Glowworm part no. 0020038092		 £30.11
110 Part number 0020038093, pipe PIPE
Glowworm part no. 0020038093		 £22.42
111 Part number 0020038091, pipe PIPE
Glowworm part no. 0020038091		 £32.82
113 Part number 0020014168, valve VALVE
Glowworm part no. 0020014168		 £126.20
114 Part number 0020014169, bypass BYPASS
Glowworm part no. 0020014169		 £31.19
116 Part number 0020014164, Wire retaining clip (PK10) WIRE RETAINING CLIP (PK10)
Glowworm part no. 0020014164		 £8.47
117 Part number 0020014176, Clip (PK10) CLIP (PK10)
Glowworm part no. 0020014176		 £12.38
118 Part number 0020014174, Flow sensor (black) FLOW SENSOR (BLACK)
Glowworm part no. 0020014174		 £31.75
119 Part number 0020014175, O-ring (PK10) O-RING (PK10)
Glowworm part no. 0020014175		 £8.11
120 Part number 0020038090, clip CLIP
Glowworm part no. 0020038090		 £6.61
121 Part number 0020014186, Nut (PK4) NUT (PK4)
Glowworm part no. 0020014186		 £7.49
122 Part number 0020014171, pump PUMP
Glowworm part no. 0020014171
123 Part number 0020014161, automatic air vent AUTOMATIC AIR VENT
Glowworm part no. 0020014161		 £21.92
124 Part number 0020014170, NOW USE 0020038628 clip NOW USE 0020038628 CLIP
Glowworm part no. 0020014170
124 Part number 0020038628, CLIP CLIP
Glowworm part no. 0020038628		 £5.80
125 Part number 0020014185, Clip (PK10) CLIP (PK10)
Glowworm part no. 0020014185		 £18.28
126 Part number 0020014173, NOW USE 0020047005 pressure relief valve(3 bar) NOW USE 0020047005 PRESSURE RELIEF VALVE(3 BAR)
Glowworm part no. 0020014173
126 Part number 0020047005, Pressure relief valve, 3 bar PRESSURE RELIEF VALVE, 3 BAR
Glowworm part no. 0020047005		 £14.99
127 Part number 0020014172, support SUPPORT
Glowworm part no. 0020014172		 £33.12
128 Part number 0020038080, Screw (PK10) SCREW (PK10)
Glowworm part no. 0020038080		 £6.61
129 Part number 0020014188, Screw (PK10) SCREW (PK10)
Glowworm part no. 0020014188		 £6.61
131 Part number 0020014177, O-ring (PK10) O-RING (PK10)
Glowworm part no. 0020014177		 £6.61
134   OBSOLETE SCREW, CPL. (SET OF 10)
Glowworm part no. 0020038079
135 Part number 0020038229, nut NUT
Glowworm part no. 0020038229		 £6.61
136   PIPE, RETURN
Glowworm part no. 0020037292		 £14.90
