SIME
PLANET SUPER 4 WM - (Casing And Controls)
Appliance Code: 47-719-16

Appliance Diagram


Casing And Controls diagram for Sime Planet Super 4 WMClick the diagram to open it on a new page

You can then pinch & zoom to adjust the size.

1   RH/LH PANEL BFR
Sime part no. 6138555		 £21.31
3   FRAME ASSEMBLY UPPER SUPPORT
Sime part no. 6138705		 £21.19
3   FRAME ASSEMBLY UPPER SUPPORT
Sime part no. 6138706
5   FRAME ASSEMBLY LOWER SIDE 630MM
Sime part no. 6138859		 £58.94
5   FRAME ASSEMBLY LOWER SIDE 600MM
Sime part no. 6138864
11 Part number 2013302, FASTENER FOR SELF TAPPING SCREW FASTENER FOR SELF TAPPING SCREW
Sime part no. 2013302		 £0.83
30 Part number 6146301, BRASS NUT 1/2 BRASS NUT 1/2
Sime part no. 6146301		 £2.84
32   D.H.W. CYLINDER UPPER FIXING BRACKET 630MM
Sime part no. 6138704		 £10.45
32   D.H.W. CYLINDER UPPER FIXING BRACKET 600MM
Sime part no. 6138708
45 Part number 2030228, GASKET 17 X 24 X 2 - REPS 2030212 GASKET 17 X 24 X 2 - REPS 2030212
Sime part no. 2030228		 £1.56
49 Part number 2030227, NOW USE 2030255 GASKET 12 X 18 X 2 NOW USE 2030255 GASKET 12 X 18 X 2
Sime part no. 2030227
49 Part number 2030255, GASKET GASKET
Sime part no. 2030255		 £1.56
70 Part number 6240703, TRANSFORMER 230/24V TRANSFORMER 230/24V
Sime part no. 6240703		 £47.20
71   CASING FRONT PANEL FIXING BRACKET 630MM
Sime part no. 6009533		 £13.07
71   CASING FRONT PANEL FIXING BRACKET 600MM
Sime part no. 6009550
74   CONTROL PANEL
Sime part no. 6272900		 £28.89
77   CASING FRONT PANEL EXTENSION 630MM
Sime part no. 6279601		 £28.89
77   FRONT PANEL EXTN. 600MM
Sime part no. 6279605		 £27.48
78 Part number 6230682, MAIN PCB WITH IGNITION MAIN PCB WITH IGNITION
Sime part no. 6230682		 £419.12
79 Part number 6201501, TRIMMER SPINDLE 5MM TRIMMER SPINDLE 5MM
Sime part no. 6201501		 £1.62
80 Part number 6201502, TRIMMER SPINDLE 6MM TRIMMER SPINDLE 6MM
Sime part no. 6201502		 £1.62
82   EARTH FASTON
Sime part no. 2211610		 £3.23
83   CONTROL PANEL PROTECTING COVER
Sime part no. 6273000		 £21.74
84   ROOM STAT COVER
Sime part no. 6273100		 £3.23
85 Part number 6230921, KNOB 40MM KNOB 40MM
Sime part no. 6230921		 £4.43
86 Part number 6201503, SELECTOR SPINDLE SELECTOR SPINDLE
Sime part no. 6201503		 £2.84
87   OBSOLETE FLAP DOOR
Sime part no. 6273301
90   CASING RIGHT HAND SIDE PANEL
Sime part no. 6242112		 £30.51
91   CASING LEFT HAND SIDE PANEL
Sime part no. 6242212		 £38.92
92 Part number 2003000, PIN M5 ZN PIN M5 ZN
Sime part no. 2003000		 £2.35
93   CASING FRONT PANEL
Sime part no. 6273516		 £55.32
94 Part number 2015000, SPRING CLIP MO/A8 SPRING CLIP MO/A8
Sime part no. 2015000		 £1.91
98   GUIDELIGHT - 12 WAYS OUT
Sime part no. 6273200		 £2.84
99   GUIDELIGHT - 6 WAYS OUT
Sime part no. 6273201		 £2.84
101   QUARTER BEND 1/2X15
Sime part no. 6142330		 £12.73
103 Part number 6177505, BALL COCK 3/4 X 22 BALL COCK 3/4 X 22
Sime part no. 6177505		 £24.03
109 Part number 6177506, BALL COCK 1/2X 15 BALL COCK 1/2X 15
Sime part no. 6177506		 £24.21
110 Part number 6177504, GAS COCK 1/2 X 1/2 GAS COCK 1/2 X 1/2
Sime part no. 6177504		 £27.48
