VAILLANT
ECOTEC PLUS 438 2006-2016 - (Burner Gas Valve Heat Exchanger)
Appliance Code: 41-044-57

Appliance Diagram


Burner Gas Valve Heat Exchanger diagram for Vaillant Ecotec Plus 438 2006-2016Click the diagram to open it on a new page

You can then pinch & zoom to adjust the size.

1 Part number 0020035220, fan FAN
Vaillant part no. 0020035220		 £205.45
2 Part number 981331, O-ring for venturi plate O-RING FOR VENTURI PLATE
Vaillant part no. 981331		 £6.89
3 Part number 105911, Screw (M4x10mm) SCREW (M4X10MM)
Vaillant part no. 105911		 £6.86
4 Part number 012861, venturi plate fan VENTURI PLATE FAN
Vaillant part no. 012861		 £26.96
5 Part number 0020035222, gas section GAS SECTION
Vaillant part no. 0020035222		 £219.93
5 Part number 053574, gas section GAS SECTION
Vaillant part no. 053574		 £236.83
6 Part number 123535, Pipe, gas PIPE, GAS
Vaillant part no. 123535		 £25.34
7 Part number 210992, grommet GROMMET
Vaillant part no. 210992		 £6.86
8 Part number 098933, bracket gas pipe BRACKET GAS PIPE
Vaillant part no. 098933		 £6.86
9 Part number 981337, Gasket gas pipe GASKET GAS PIPE
Vaillant part no. 981337		 £6.86
10   OBSOLETE GAS COCK LINER
Vaillant part no. 210996
11 Part number 0020176262, Pump, 25/6 RKC 130 PUMP, 25/6 RKC 130
Vaillant part no. 0020176262		 £227.76
11   NOW USE 0020176262 PUMP
Vaillant part no. 0020083523
12 Part number 116696, manifold fan (assembly) MANIFOLD FAN (ASSEMBLY)
Vaillant part no. 116696		 £107.76
13 Part number 105908, screw ejot M5X16 SCREW EJOT M5X16
Vaillant part no. 105908		 £6.86
14 Part number 105907, screw fan manifold SCREW FAN MANIFOLD
Vaillant part no. 105907		 £6.86
15 Part number 981334, seal fan SEAL FAN
Vaillant part no. 981334		 £6.86
16 Part number 161245, inspection glass INSPECTION GLASS
Vaillant part no. 161245		 £6.86
16 Part number 161275, NOW USE 161245 sight glass replacement kit NOW USE 161245 SIGHT GLASS REPLACEMENT KIT
Vaillant part no. 161275
17 Part number 981333, seal heat exchanger door / mixing arm SEAL HEAT EXCHANGER DOOR / MIXING ARM
Vaillant part no. 981333		 £6.86
18 Part number 088134, flange FLANGE
Vaillant part no. 088134		 £100.10
19 Part number 0020026537, Nut, M6 (PK5) NUT, M6 (PK5)
Vaillant part no. 0020026537		 £6.86
20 Part number 114642, Nut (hexagon nut) NUT (HEXAGON NUT)
Vaillant part no. 114642		 £6.86
21 Part number 0020038679, Gasket kit GASKET KIT
Vaillant part no. 0020038679		 £19.87
22 Part number 210754, insulation h/e door INSULATION H/E DOOR
Vaillant part no. 210754		 £27.57
23 Part number 981103, Gasket burner GASKET BURNER
Vaillant part no. 981103		 £8.88
23 Part number 981327, NOW USE 981103 gasket, burner NOW USE 981103 GASKET, BURNER
Vaillant part no. 981327
24 Part number 049324, Burner BURNER
Vaillant part no. 049324		 £110.07
24 Part number 050470, burner with gaskets BURNER WITH GASKETS
Vaillant part no. 050470		 £153.32
25 Part number 098929, Support (heat exchanger) SUPPORT (HEAT EXCHANGER)
Vaillant part no. 098929		 £6.86
26 Part number 105900, Screw, (PK10) SCREW, (PK10)
Vaillant part no. 105900		 £6.86
27 Part number 981329, Gasket (h/e door inspection) GASKET (H/E DOOR INSPECTION)
Vaillant part no. 981329		 £6.86
28 Part number 065180, heat exchanger 30kW HEAT EXCHANGER 30KW
Vaillant part no. 065180		 £598.61
29 Part number 981324, O-ring (18x3) O-RING (18X3)
Vaillant part no. 981324		 £6.86
32 Part number 0020107702, Clip (PK5) CLIP (PK5)
Vaillant part no. 0020107702		 £6.86
32 Part number 219650, NOW USE 0020107702 clip, h/e Adapter NOW USE 0020107702 CLIP, H/E ADAPTER
Vaillant part no. 219650
33 Part number 0020059512, Siphon Adapter Set SIPHON ADAPTER SET
Vaillant part no. 0020059512		 £17.07
34   SUPPORT, H/E BRACKET
Vaillant part no. 098935		 £16.08
35   SUPPORT, H/E BRACKET, LH
Vaillant part no. 098934		 £14.88
36 Part number 981348, seal, washer (24.5 x 18.2mm) SEAL, WASHER (24.5 X 18.2MM)
Vaillant part no. 981348		 £6.89
37 Part number 105906, screw electrode SCREW ELECTRODE
Vaillant part no. 105906		 £6.86
38 Part number 090709, Electrode ELECTRODE
Vaillant part no. 090709		 £23.13
39 Part number 981330, gasket electrode GASKET ELECTRODE
Vaillant part no. 981330		 £6.40
40 Part number 0020153950, Electrode (ignition) ELECTRODE (IGNITION)
Vaillant part no. 0020153950		 £32.10
40 Part number 0020035226, NOW USE 0020153950 cable NOW USE 0020153950 CABLE
Vaillant part no. 0020035226
41 Part number 0020035211, pipework PIPEWORK
Vaillant part no. 0020035211		 £20.07
41 Part number 0020035212, pipework PIPEWORK
Vaillant part no. 0020035212		 £20.12
42 Part number 0020035213, pipework PIPEWORK
Vaillant part no. 0020035213		 £18.74
42   PIPEWORK
Vaillant part no. 0020035214		 £18.46
43 Part number 105910, screw 4.2x3.5mm SCREW 4.2X3.5MM
Vaillant part no. 105910		 £6.86
44 Part number 105903, screw M6X60 SCREW M6X60
Vaillant part no. 105903		 £6.86
44   SCREW ( M6X120 )
Vaillant part no. 105909		 £6.86
