GLOWWORM
ULTRAPOWER 100SXI - (PCB/Controls)
Appliance Code: 41-019-09

Appliance Diagram


PCB/Controls diagram for Glowworm Ultrapower 100SXIClick the diagram to open it on a new page

You can then pinch & zoom to adjust the size.

73 Part number S1042400, Gasket electrode (PK5) GASKET ELECTRODE (PK5)
Glowworm part no. S1042400		 £21.33
73 Part number 0020018811, NOW USE S1042400 seal (set of 5) NOW USE S1042400 SEAL (SET OF 5)
Glowworm part no. 0020018811
74 Part number 0020018810, electrode+ screw + gasket ELECTRODE+ SCREW + GASKET
Glowworm part no. 0020018810		 £28.31
102 Part number 0020014161, automatic air vent AUTOMATIC AIR VENT
Glowworm part no. 0020014161		 £22.57
103 Part number S5739800, Temperature sensor TEMPERATURE SENSOR
Glowworm part no. S5739800		 £23.87
103 Part number 0020020781, NOW USE S5739800 temperature monitor NOW USE S5739800 TEMPERATURE MONITOR
Glowworm part no. 0020020781
103 Part number 2000801935, NOW USE S5739800 ntc with clip d=18mm 10kOhm NOW USE S5739800 NTC WITH CLIP D=18MM 10KOHM
Glowworm part no. 2000801935
104 Part number 0020020780, cable tree (zig harness) CABLE TREE (ZIG HARNESS)
Glowworm part no. 0020020780		 £15.25
107 Part number 0020020763, igniter IGNITER
Glowworm part no. 0020020763		 £29.39
108 Part number SK7959, Screw, M3x6mm SCREW, M3X6MM
Glowworm part no. SK7959		 £6.80
109 Part number 0020038062, Casing CASING
Glowworm part no. 0020038062		 £26.23
110 Part number 0020038061, display DISPLAY
Glowworm part no. 0020038061		 £191.26
111 Part number 0020037668, printed circuit PRINTED CIRCUIT
Glowworm part no. 0020037668		 £303.65
112 Part number 0020025183, appliance interface harness APPLIANCE INTERFACE HARNESS
Glowworm part no. 0020025183		 £13.66
113   BACK PANEL
Glowworm part no. 0020038063		 £13.32
114 Part number 0020079603, Fuse 2,0 A T2H (PK10) FUSE 2,0 A T2H (PK10)
Glowworm part no. 0020079603		 £14.51
114 Part number 0020026405, NOW USE 0020079603 fuse NOW USE 0020079603 FUSE
Glowworm part no. 0020026405
115 Part number 0020038263, fitting FITTING
Glowworm part no. 0020038263		 £6.80
117 Part number 0020038266, cable tree (harness) CABLE TREE (HARNESS)
Glowworm part no. 0020038266		 £48.11
118 Part number 0020038267, cable tree (harness) CABLE TREE (HARNESS)
Glowworm part no. 0020038267		 £48.11
131 Part number 802256, IGNITION LEAD IGNITION LEAD
Glowworm part no. 802256		 £20.45
132 Part number 0020038260, Gasket GASKET
Glowworm part no. 0020038260		 £19.11
133 Part number 0020038262, Box BOX
Glowworm part no. 0020038262		 £34.91
134 Part number 0020038262, Box BOX
Glowworm part no. 0020038262		 £34.91
135 Part number 0020014188, Screw (PK10) SCREW (PK10)
Glowworm part no. 0020014188		 £6.80
136   TOOTHED WASHER
Glowworm part no. 0020038265		 £6.80
