GLOWWORM
ULTRAPOWER 100SXI - (Hydraulic/Pump)
Appliance Code: 41-019-09

Appliance Diagram


Hydraulic/Pump diagram for Glowworm Ultrapower 100SXIClick the diagram to open it on a new page

You can then pinch & zoom to adjust the size.

22   GASKET 30X21X2.1
Glowworm part no. 802225
£6.23
33 Part number 0020038251, Pipe PIPE
Glowworm part no. 0020038251
£34.61
34 Part number 0020038250, clip CLIP
Glowworm part no. 0020038250
£6.23
35 Part number 0020014183, O-ring (PK10) O-RING (PK10)
Glowworm part no. 0020014183
£10.56
35   NOW USE 0020014183 1SEAL O-RING
Glowworm part no. 0020020741

36 Part number 0020020742, clip (tube) CLIP (TUBE)
Glowworm part no. 0020020742
£6.23
38 Part number 0020038236, Pipe PIPE
Glowworm part no. 0020038236
£26.69
39 Part number 0020014186, Nut (PK4) NUT (PK4)
Glowworm part no. 0020014186
£7.07
40 Part number 0020038237, Pipe PIPE
Glowworm part no. 0020038237
£22.75
41 Part number 0020014164, Wire retaining clip (PK10) WIRE RETAINING CLIP (PK10)
Glowworm part no. 0020014164
£7.99
41 Part number 0020020754, NOW USE 0020014164 CLIP NOW USE 0020014164 CLIP
Glowworm part no. 0020020754

42   NOW USE 0020079644 SENSOR
Glowworm part no. 0020038275

42 Part number 0020079644, Sensor SENSOR
Glowworm part no. 0020079644
£26.16
43 Part number 0020014168, valve VALVE
Glowworm part no. 0020014168
£126.20
44 Part number 0020038230, pipe PIPE
Glowworm part no. 0020038230
£11.45
45 Part number 0020014169, bypass BYPASS
Glowworm part no. 0020014169
£29.43
46 Part number 0020038232, heat exchanger HEAT EXCHANGER
Glowworm part no. 0020038232
£195.95
47 Part number 0020014166, Gasket, C-Type, (PK10) GASKET, C-TYPE, (PK10)
Glowworm part no. 0020014166
£10.01
48 Part number 0020038249, Pipe PIPE
Glowworm part no. 0020038249
£44.06
49 Part number 0020014171, pump PUMP
Glowworm part no. 0020014171
£180.74
50 Part number 0020014173, NOW USE 0020047005 pressure relief valve(3 bar) NOW USE 0020047005 PRESSURE RELIEF VALVE(3 BAR)
Glowworm part no. 0020014173

50 Part number 0020047005, Pressure relief valve, 3 bar PRESSURE RELIEF VALVE, 3 BAR
Glowworm part no. 0020047005
£14.14
51 Part number 2000802538, WASHER SEALING WASHER SEALING
Glowworm part no. 2000802538
£6.23
52   PIPE
Glowworm part no. 0020038238
£17.67
53 Part number 0020014182, Gasket Type-C (PK10) GASKET TYPE-C (PK10)
Glowworm part no. 0020014182
£10.01
54   GASKET KIT
Glowworm part no. 0020038231
£6.23
55 Part number 0020020751, O-ring O-RING
Glowworm part no. 0020020751
£6.23
56 Part number 0020038235, Pipe PIPE
Glowworm part no. 0020038235
£26.69
57 Part number 0020038247, connection CONNECTION
Glowworm part no. 0020038247
£67.86
58 Part number 0020038244, fitting FITTING
Glowworm part no. 0020038244
£17.50
59   CLIP
Glowworm part no. 0020038246
£6.23
60   PUMP
Glowworm part no. 0020038245
£235.38
61   CONNECTION
Glowworm part no. 0020038239
£68.31
105 Part number 0020014185, Clip (PK10) CLIP (PK10)
Glowworm part no. 0020014185
£17.24
106 Part number 0020014161, automatic air vent AUTOMATIC AIR VENT
Glowworm part no. 0020014161
£21.92
116 Part number 0020014170, NOW USE 0020038628 clip NOW USE 0020038628 CLIP
Glowworm part no. 0020014170

116 Part number 0020038628, CLIP CLIP
Glowworm part no. 0020038628
£5.47
124 Part number 0020038227, connection piece CONNECTION PIECE
Glowworm part no. 0020038227
£13.48
125 Part number 0020038228, connection piece CONNECTION PIECE
Glowworm part no. 0020038228
£13.73
126 Part number 0020014165, Screw (PK10) SCREW (PK10)
Glowworm part no. 0020014165
£7.93
