GLOWWORM
FLEXICOM 24 HX - (Appliance Overview)
Appliance Code: 41-315-61

Appliance Diagram


Appliance Overview diagram for Glowworm Flexicom 24 HXClick the diagram to open it on a new page

You can then pinch & zoom to adjust the size.

1   COMPANY PLAQUE
Glowworm part no. 0020020693		 £10.33
2   FRONT PANEL
Glowworm part no. 0020020697		 £95.81
3   SIDE PANEL HX
Glowworm part no. 0020020699		 £58.39
4 Part number 801700, SCREW 4.2X13.5mm SCREW 4.2X13.5MM
Glowworm part no. 801700		 £6.80
5 Part number 0020020706, support, wall hanging SUPPORT, WALL HANGING
Glowworm part no. 0020020706		 £25.52
6 Part number 0020020719, cover, rear (flue outlet) COVER, REAR (FLUE OUTLET)
Glowworm part no. 0020020719		 £15.13
7 Part number 0020026459, Gasket GASKET
Glowworm part no. 0020026459		 £6.80
8 Part number 0020020720, screw SCREW
Glowworm part no. 0020020720		 £6.80
8 Part number 0020020725, NOW USE 0020020720 screw NOW USE 0020020720 SCREW
Glowworm part no. 0020020725
9 Part number 0020020714, cover, top (flue outlet) COVER, TOP (FLUE OUTLET)
Glowworm part no. 0020020714		 £19.11
10 Part number 0020014192, Gasket, red large GASKET, RED LARGE
Glowworm part no. 0020014192		 £6.80
11 Part number 0020026488, Heat exchanger + sump HEAT EXCHANGER + SUMP
Glowworm part no. 0020026488		 £612.80
12 Part number 0020020708, elbow, flow and return ELBOW, FLOW AND RETURN
Glowworm part no. 0020020708		 £39.13
13   ELBOW, RETURN
Glowworm part no. 0020020709		 £24.24
14   ELBOW, RETURN
Glowworm part no. 0020020709		 £24.24
14   NOW USE 0020020709 DRAIN PIECE
Glowworm part no. 0020020710
15 Part number 0020018447, Screw (PK10) SCREW (PK10)
Glowworm part no. 0020018447		 £6.58
15 Part number 0020020743, NOW USE 0020018447 screw NOW USE 0020018447 SCREW
Glowworm part no. 0020020743
16 Part number 0020020711, Washer WASHER
Glowworm part no. 0020020711		 £6.80
17 Part number 0020020723, condensate trap CONDENSATE TRAP
Glowworm part no. 0020020723		 £26.98
18 Part number 0020020724, O-ring O-RING
Glowworm part no. 0020020724		 £6.80
20 Part number 0020020726, Pipe, condense drain PIPE, CONDENSE DRAIN
Glowworm part no. 0020020726		 £10.86
21 Part number 0020013712, FLOAT FLOAT
Glowworm part no. 0020013712		 £6.80
22 Part number 0020020742, clip (tube) CLIP (TUBE)
Glowworm part no. 0020020742		 £6.80
23 Part number 0020020728, burner BURNER
Glowworm part no. 0020020728		 £232.64
24 Part number 0020020729, Gasket (burner) GASKET (BURNER)
Glowworm part no. 0020020729		 £16.04
25 Part number 0020020730, nut, extended M5 NUT, EXTENDED M5
Glowworm part no. 0020020730		 £6.80
26 Part number 0020020731, electrode ELECTRODE
Glowworm part no. 0020020731		 £16.41
27 Part number 0020020732, Gasket (electrode) GASKET (ELECTRODE)
Glowworm part no. 0020020732		 £6.80
28 Part number 0020020734, fan FAN
Glowworm part no. 0020020734		 £197.23
29 Part number 0020020735, gas section GAS SECTION
Glowworm part no. 0020020735		 £197.23
30 Part number 801648, O-ring for venturi plate O-RING FOR VENTURI PLATE
Glowworm part no. 801648		 £6.80
31 Part number 0020020737, screw SCREW
Glowworm part no. 0020020737		 £6.80
32 Part number 0020020739, Gasket (fan) GASKET (FAN)
Glowworm part no. 0020020739		 £7.00
33 Part number 0020026402, Nut NUT
Glowworm part no. 0020026402		 £6.80
34 Part number 0020020760, Pipe, flow PIPE, FLOW
Glowworm part no. 0020020760		 £22.97
35 Part number 0020020761, Pipe, return PIPE, RETURN
Glowworm part no. 0020020761		 £32.36
36   PIPE, GAS
Glowworm part no. 0020020762		 £36.75
37   CLIP, FAN MOUNTING
Glowworm part no. 0020020733		 £16.82
38 Part number 0020020757, Gasket (pipe flange) GASKET (PIPE FLANGE)
Glowworm part no. 0020020757		 £6.80
39 Part number 0020020763, igniter IGNITER
Glowworm part no. 0020020763		 £29.39
40   CLIP (ZIG IGNITOR)
Glowworm part no. 0020020764		 £8.05
41 Part number SK7959, Screw, M3x6mm SCREW, M3X6MM
Glowworm part no. SK7959		 £6.80
42 Part number 0020020766, casing (installer housing) CASING (INSTALLER HOUSING)
Glowworm part no. 0020020766		 £10.86
43   STRIP, 8 POLE CONNECTOR
Glowworm part no. 0020020767		 £8.05
44   STRIP, 5 POLE TERM 230V EARTH
Glowworm part no. 0020020768		 £6.80
45   STRIP, 3 POLE TERM 230V N L E
Glowworm part no. 0020020769		 £6.80
46   COVER (INSTALLER HOOD)
Glowworm part no. 0020020770		 £6.80
47 Part number 0020020774, Support (PK2) SUPPORT (PK2)
Glowworm part no. 0020020774		 £6.80
48   SCREW
Glowworm part no. 0020020776		 £6.80
49 Part number 0020020780, cable tree (zig harness) CABLE TREE (ZIG HARNESS)
Glowworm part no. 0020020780		 £15.25
50 Part number S5739800, Temperature sensor TEMPERATURE SENSOR
Glowworm part no. S5739800		 £23.87
50 Part number 0020020781, NOW USE S5739800 temperature monitor NOW USE S5739800 TEMPERATURE MONITOR
Glowworm part no. 0020020781
51 Part number 0020020783, cable (ignition lead assembly) CABLE (IGNITION LEAD ASSEMBLY)
Glowworm part no. 0020020783		 £45.59
52   CLIP (HARNESS)
Glowworm part no. 0020020784		 £6.80
53 Part number 0020025182, control box front (openvent) CONTROL BOX FRONT (OPENVENT)
Glowworm part no. 0020025182		 £19.11
54 Part number 0020025184, control box rear CONTROL BOX REAR
Glowworm part no. 0020025184		 £11.09
55 Part number 0020025183, appliance interface harness APPLIANCE INTERFACE HARNESS
Glowworm part no. 0020025183		 £13.66
56 Part number 0020023825, PCB main PCB MAIN
Glowworm part no. 0020023825		 £192.24
57 Part number 0020023826, appliance interface APPLIANCE INTERFACE
Glowworm part no. 0020023826		 £122.20
58 Part number 0020014187, cable bushing CABLE BUSHING
Glowworm part no. 0020014187		 £11.23
59 Part number 2000801883, Sealing ring 3/4 (PK10) SEALING RING 3/4 (PK10)
Glowworm part no. 2000801883		 £31.83
59 Part number 0020026403, NOW USE 2000801883 seal NOW USE 2000801883 SEAL
Glowworm part no. 0020026403
60   SUPPORT, HEAT EXCHANGER TOP
Glowworm part no. 0020020712		 £8.25
61   SILENCER
Glowworm part no. 0020055401		 £61.07
61   NOW USE 0020055401 ABSORBER CPL., REAR
Glowworm part no. 0020020713
62   SILENCER
Glowworm part no. 0020055401		 £61.07
62   NOW USE 0020055401 ABSORBER CPL., FRONT
Glowworm part no. 0020020715
63 Part number 0020020716, flue duct top assembly FLUE DUCT TOP ASSEMBLY
Glowworm part no. 0020020716		 £59.98
64 Part number 0020020718, flue duct front assembly FLUE DUCT FRONT ASSEMBLY
Glowworm part no. 0020020718		 £34.25
65   CLIP, FAN FIXING
Glowworm part no. 0020020738		 £10.59
66 Part number 0020020721, Gasket (flue hood front) GASKET (FLUE HOOD FRONT)
Glowworm part no. 0020020721		 £10.64
67 Part number 0020026404, O-ring O-RING
Glowworm part no. 0020026404		 £6.77
68 Part number 0020020740, Nut NUT
Glowworm part no. 0020020740		 £6.80
69   FLUEWAY TOP BAFFLE
Glowworm part no. 0020020717		 £58.37
70 Part number 0020026409, Gas tap GAS TAP
Glowworm part no. 0020026409		 £46.98
70 Part number 0020020789, NOW USE 0020026409 tap, gas NOW USE 0020026409 TAP, GAS
Glowworm part no. 0020020789
71   TUBE (GAS PIPE TAIL)
Glowworm part no. 0020020790		 £11.93
72 Part number 0020026460, Lip seal LIP SEAL
Glowworm part no. 0020026460		 £6.81
73 Part number 0020038076, Gasket exchanger / flue GASKET EXCHANGER / FLUE
Glowworm part no. 0020038076		 £8.13
73 Part number 2000801616, NOW USE 0020038076 FLUE SEAL NOW USE 0020038076 FLUE SEAL
Glowworm part no. 2000801616
75 Part number 0020079603, Fuse 2,0 A T2H (PK10) FUSE 2,0 A T2H (PK10)
Glowworm part no. 0020079603		 £14.51
75 Part number 0020026405, NOW USE 0020079603 fuse NOW USE 0020079603 FUSE
Glowworm part no. 0020026405
76 Part number 0020020777, cable tree (mains inlet harness) CABLE TREE (MAINS INLET HARNESS)
Glowworm part no. 0020020777		 £16.07
77   CABLE TREE (MAINS PUMP HARNESS)
Glowworm part no. 0020020785		 £12.75
78 Part number 0020020778, Cable tree (combustion harness) CABLE TREE (COMBUSTION HARNESS)
Glowworm part no. 0020020778		 £30.32
79   CABLE TREE (HYDRAULIC HARNESS)
Glowworm part no. 0020020786		 £9.02
80 Part number 0020020773, Screw torx 4.2x13.5mm SCREW TORX 4.2X13.5MM
Glowworm part no. 0020020773		 £6.80
81 Part number 0020020782, Gasket (control box front) GASKET (CONTROL BOX FRONT)
Glowworm part no. 0020020782		 £6.80
82 Part number 0020054162, Resonator RESONATOR
Glowworm part no. 0020054162		 £14.13
83 Part number 0020054163, Heat Exchanger Hx HEAT EXCHANGER HX
Glowworm part no. 0020054163		 £607.55
84 Part number 0020054165, Silencer SILENCER
Glowworm part no. 0020054165		 £48.04
87 Part number 0020037299, housing HOUSING
Glowworm part no. 0020037299		 £66.39
88 Part number 0020041108, housing HOUSING
Glowworm part no. 0020041108		 £23.85
89 Part number 0020038263, fitting FITTING
Glowworm part no. 0020038263		 £6.80
90 Part number 0020038381, Gasket GASKET
Glowworm part no. 0020038381		 £6.80
91   SILENCER
Glowworm part no. 0020055401		 £61.07
