POTTERTON
PERFORMA 24 HE SYSTEM - (Combustion Box)
Appliance Code: 41-591-26

Appliance Diagram


Combustion Box diagram for Potterton Performa 24 HE SystemClick the diagram to open it on a new page

You can then pinch & zoom to adjust the size.

201 Part number 5112369, FLUE ADAPTER HE (NO SEALS) FLUE ADAPTER HE (NO SEALS)
Potterton part no. 5112369		 £12.74
202 Part number 5112370, GASKET ADAPTER GASKET ADAPTER
Potterton part no. 5112370		 £4.74
203 Part number 5113313, TAP ADAPTER TAP ADAPTER
Potterton part no. 5113313		 £6.42
204 Part number 247731, PLATE BLANKING PLATE BLANKING
Potterton part no. 247731		 £8.09
205 Part number 247732, GASKET - PLATE BLANKING GASKET - PLATE BLANKING
Potterton part no. 247732		 £3.26
206 Part number 062617, SCR-ST-No8x1/2 PAN POZ.TYPE B SCR-ST-NO8X1/2 PAN POZ.TYPE B
Potterton part no. 062617		 £1.86
208 Part number 248192, STUD - FRONT PANEL STUD - FRONT PANEL
Potterton part no. 248192		 £3.44
209 Part number 635431, NUT FULL M4 HEX. MS NICK.PLT NUT FULL M4 HEX. MS NICK.PLT
Potterton part no. 635431		 £3.26
210 Part number 5137531, FAN PRESSURE SWITCH FAN PRESSURE SWITCH
Potterton part no. 5137531		 £45.57
211 Part number 5112367, PIPE-PRESSURE SWITCH NEG.BLACK PIPE-PRESSURE SWITCH NEG.BLACK
Potterton part no. 5112367
212 Part number 248003, PIPE - VALVE COMPENSATION PIPE - VALVE COMPENSATION
Potterton part no. 248003		 £3.35
213 Part number 617414, WASHER SHAKEPROOF INT M4 S WASHER SHAKEPROOF INT M4 S
Potterton part no. 617414		 £2.32
215 Part number 248094, WASHER - SEALING G3/8 WASHER - SEALING G3/8
Potterton part no. 248094		 £3.63
216 Part number 247445, ADAPTER - PRESSURE PIPE ADAPTER - PRESSURE PIPE
Potterton part no. 247445		 £8.28
217 Part number 248003, PIPE - VALVE COMPENSATION PIPE - VALVE COMPENSATION
Potterton part no. 248003		 £3.35
218 Part number 248010, INSULATION SIDE PANEL - 80 INSULATION SIDE PANEL - 80
Potterton part no. 248010		 £7.63
219 Part number 248012, INSULATION - REAR PANEL INSULATION - REAR PANEL
Potterton part no. 248012		 £13.95
220 Part number 248013, INSULATION - FRONT PANEL INSULATION - FRONT PANEL
Potterton part no. 248013		 £13.95
221 Part number 248014, PANEL-COMBUSTION CHAMBER-80 PANEL-COMBUSTION CHAMBER-80
Potterton part no. 248014		 £15.81
223 Part number 248363, PANEL-COMBUSTION BOX PANEL-COMBUSTION BOX
Potterton part no. 248363		 £32.55
224 Part number 247437, SURROUND - VIEWING WINDOW SURROUND - VIEWING WINDOW
Potterton part no. 247437		 £6.05
225 Part number 247436, VIEWING WINDOW VIEWING WINDOW
Potterton part no. 247436		 £7.91
228 Part number 248023, CLIP - HEAT EXCHANGER - FIXING CLIP - HEAT EXCHANGER - FIXING
Potterton part no. 248023		 £8.09
230 Part number 247429, O RING 22mm X 3mm O RING 22MM X 3MM
Potterton part no. 247429		 £3.35
232 Part number 5112431, HEAT EXCHANGER-PRIMARY - 105HE HEAT EXCHANGER-PRIMARY - 105HE
Potterton part no. 5112431		 £379.44
233 Part number 248035, ADAPTER - MANIFOLD ADAPTER - MANIFOLD
Potterton part no. 248035		 £13.02
234 Part number 248036, GASKET - MANIFOLD ADAPTER GASKET - MANIFOLD ADAPTER
Potterton part no. 248036		 £3.35
236 Part number 248034, GASKET - BURNER MANIFOLD GASKET - BURNER MANIFOLD
Potterton part no. 248034		 £3.26
237 Part number 248211, INJECTOR - 0.77 LPG INJECTOR - 0.77 LPG
Potterton part no. 248211		 £6.14
237 Part number 247439, INJECTOR 1.18mm INJECTOR 1.18MM
Potterton part no. 247439
239   MANIFOLD BURNER
Potterton part no. 248470
239   MANIFOLD - BURNER - 80
Potterton part no. 5112639
240 Part number 5112770, BURNER ASSEMBLY BURNER ASSEMBLY
Potterton part no. 5112770		 £43.71
240 Part number 248030, NOW USE 5112770 BURNER ASSEMBLY 105 NOW USE 5112770 BURNER ASSEMBLY 105
Potterton part no. 248030
242 Part number 248038, INSULATION BOOT - ELECTRODE INSULATION BOOT - ELECTRODE
Potterton part no. 248038		 £6.14
244 Part number 248037, LEAD - IGNITION ELECTRODE LEAD - IGNITION ELECTRODE
Potterton part no. 248037		 £7.35
245 Part number 5112382, LEAD-SENSING ELEC/TRAP CONNECT LEAD-SENSING ELEC/TRAP CONNECT
Potterton part no. 5112382		 £9.86
246   COMBUSTION CHAMBER ASSY-80 HE
Potterton part no. 5112631		 £45.64
247 Part number 247384, IGNITION ELECTRODE - FRONT IGNITION ELECTRODE - FRONT
Potterton part no. 247384		 £12.37
248 Part number 5113314, O RING O RING
Potterton part no. 5113314		 £4.46
