VAILLANT
ECOMAX 646 VU (CONDENSING SYSTEM) 2006-2008 - (08 Connection Parts)
Appliance Code: 20-062-01

Appliance Diagram


08 Connection Parts diagram for Vaillant Ecomax 646 VU (Condensing System) 2006-2008Click the diagram to open it on a new page

You can then pinch & zoom to adjust the size.

1 Part number 065150, heat exchanger HEAT EXCHANGER
Vaillant part no. 065150		 £627.79
2 Part number 981140, Sealing ring, 3/4 (PK10) SEALING RING, 3/4 (PK10)
Vaillant part no. 981140		 £6.65
3 Part number 092006, Connection Piece CONNECTION PIECE
Vaillant part no. 092006		 £20.64
4 Part number 092007, Connection Piece CONNECTION PIECE
Vaillant part no. 092007		 £25.79
6 Part number 022566, Tube TUBE
Vaillant part no. 022566		 £66.45
7 Part number 252805, Sensor - NTC SENSOR - NTC
Vaillant part no. 252805		 £21.39
8 Part number 712087, pressure sensor PRESSURE SENSOR
Vaillant part no. 712087		 £21.59
9 Part number 981154, O-ring, (PK10) O-RING, (PK10)
Vaillant part no. 981154		 £6.31
11 Part number 981272, O-ring (PK10) O-RING (PK10)
Vaillant part no. 981272		 £6.28
13 Part number 061707, automatic de-aerator AUTOMATIC DE-AERATOR
Vaillant part no. 061707		 £18.65
14 Part number 981163, O-ring, (PK10) O-RING, (PK10)
Vaillant part no. 981163		 £6.63
15 Part number 981311, O-ring (PK10) O-RING (PK10)
Vaillant part no. 981311		 £6.65
17 Part number 085751, NOW USE 0020107709 pressure gauge clip NOW USE 0020107709 PRESSURE GAUGE CLIP
Vaillant part no. 085751
17 Part number 0020107709, Support SUPPORT
Vaillant part no. 0020107709		 £6.28
18 Part number 981155, O-ring, (PK10) O-RING, (PK10)
Vaillant part no. 981155		 £5.98
19 Part number 101271, Pressure gauge PRESSURE GAUGE
Vaillant part no. 101271		 £38.09
20   NUT (PK2)
Vaillant part no. 114633		 £7.84
21 Part number 022565, Tube TUBE
Vaillant part no. 022565		 £52.45
22   CONNECTION PIECE
Vaillant part no. 084765		 £20.64
23 Part number 160976, pump PUMP
Vaillant part no. 160976
24 Part number 236500, connection CONNECTION
Vaillant part no. 236500		 £15.71
27 Part number 140015, Screw - De-aeration SCREW - DE-AERATION
Vaillant part no. 140015		 £6.28
28   TUBE
Vaillant part no. 022564		 £13.63
29 Part number 022573, Tube TUBE
Vaillant part no. 022573		 £15.71
30 Part number 981158, O-ring (PK10) O-RING (PK10)
Vaillant part no. 981158		 £6.28
31 Part number 950017, Cap CAP
Vaillant part no. 950017		 £6.28
32   NUT, CPL. (2 P.)
Vaillant part no. 114634		 £4.45
33   CONNECTION TUBE (PK2)
Vaillant part no. 022574		 £23.67
34 Part number 097056, connection CONNECTION
Vaillant part no. 097056		 £52.45
35 Part number 023220, Tube TUBE
Vaillant part no. 023220		 £37.61
36   TUBE
Vaillant part no. 023219		 £24.39
37   CONNECTION
Vaillant part no. 097057		 £39.18
38 Part number 981142, Sealing ring, (PK10) SEALING RING, (PK10)
Vaillant part no. 981142		 £6.63
39 Part number 106350, drain cock DRAIN COCK
Vaillant part no. 106350		 £7.18
40 Part number 0020045973, Adapter ADAPTER
Vaillant part no. 0020045973		 £226.31
41 Part number 0020045974, Filter FILTER
Vaillant part no. 0020045974		 £18.42
42 Part number 0020045975, O-Ring (Pk10) O-RING (PK10)
Vaillant part no. 0020045975		 £8.95
43 Part number 190721, pressure relief valve PRESSURE RELIEF VALVE
Vaillant part no. 190721		 £30.70
44   ISOLATION VALVE
Vaillant part no. 0020073076
45 Part number 0020073075, Isolation valve ISOLATION VALVE
Vaillant part no. 0020073075		 £51.44
