VAILLANT
ECOMAX 665 VU (CONDENSING SYSTEM) 2006-2008 - (04 Burner)
Appliance Code: 20-062-02

Appliance Diagram


04 Burner diagram for Vaillant Ecomax 665 VU (Condensing System) 2006-2008Click the diagram to open it on a new page

You can then pinch & zoom to adjust the size.

1 Part number 180900, burner BURNER
Vaillant part no. 180900		 £93.99
2 Part number 981103, Gasket burner GASKET BURNER
Vaillant part no. 981103		 £8.62
3 Part number 105900, Screw, (PK10) SCREW, (PK10)
Vaillant part no. 105900		 £6.66
4 Part number 0020026537, Nut, M6 (PK5) NUT, M6 (PK5)
Vaillant part no. 0020026537		 £6.66
5 Part number 161245, inspection glass INSPECTION GLASS
Vaillant part no. 161245		 £6.66
6 Part number 090709, Electrode ELECTRODE
Vaillant part no. 090709		 £22.46
7 Part number 981330, gasket electrode GASKET ELECTRODE
Vaillant part no. 981330		 £6.21
8 Part number 118883, Flat head screw ISO 7045 FLAT HEAD SCREW ISO 7045
Vaillant part no. 118883
9 Part number 091551, ignition wire IGNITION WIRE
Vaillant part no. 091551		 £17.94
10 Part number 180901, Fan FAN
Vaillant part no. 180901		 £538.41
11 Part number 981104, Gasket GASKET
Vaillant part no. 981104		 £7.92
12 Part number 981051, Gasket kit GASKET KIT
Vaillant part no. 981051		 £17.95
13 Part number 180904, Gasket GASKET
Vaillant part no. 180904		 £8.87
14 Part number 284050, OBSOLETE Washer OBSOLETE WASHER
Vaillant part no. 284050
15 Part number 180913, insulation INSULATION
Vaillant part no. 180913		 £16.62
16 Part number 180902, adapter ADAPTER
Vaillant part no. 180902		 £16.66
18 Part number 981142, Sealing ring, (PK10) SEALING RING, (PK10)
Vaillant part no. 981142		 £8.62
19   TUBE
Vaillant part no. 180905		 £52.07
20 Part number 180908, flue bend FLUE BEND
Vaillant part no. 180908		 £99.14
22 Part number 139247, screw SCREW
Vaillant part no. 139247
23 Part number 118882, Flat head screw FLAT HEAD SCREW
Vaillant part no. 118882		 £5.13
24 Part number 180910, Air inlet pipe AIR INLET PIPE
Vaillant part no. 180910		 £26.17
25 Part number 981111, Gasket GASKET
Vaillant part no. 981111		 £6.66
26 Part number 180911, support SUPPORT
Vaillant part no. 180911		 £8.97
27 Part number 509685, Screw, (PK10) SCREW, (PK10)
Vaillant part no. 509685		 £6.66
28 Part number 180903, flange FLANGE
Vaillant part no. 180903		 £124.11
29 Part number 180906, cable tree CABLE TREE
Vaillant part no. 180906		 £44.70
30 Part number 180907, Wiring harness WIRING HARNESS
Vaillant part no. 180907
31 Part number 118951, Pan head screw, M6x28,5 PAN HEAD SCREW, M6X28,5
Vaillant part no. 118951		 £4.92
32 Part number 500046, NOW USE 0010047528 screw NOW USE 0010047528 SCREW
Vaillant part no. 500046
32   SCREW, (X10)
Vaillant part no. 0010047528		 £2.90
33 Part number 982319, O-ring O-RING
Vaillant part no. 982319		 £5.13
35   ADAPTER (GAS SECTION)
Vaillant part no. 0020046759		 £25.09
36 Part number 0020046760, Tube TUBE
Vaillant part no. 0020046760		 £181.90
37 Part number 981140, Sealing ring, 3/4 (PK10) SEALING RING, 3/4 (PK10)
Vaillant part no. 981140		 £7.05
38 Part number 0020012126, Compression Fitting COMPRESSION FITTING
Vaillant part no. 0020012126		 £12.58
39 Part number 080075, Compression fitting 1 inch COMPRESSION FITTING 1 INCH
Vaillant part no. 080075		 £38.14
