KESTON
KESTON K170 NG - (Control Assembly)
Appliance Code: 41-930-04

Appliance Diagram


Control Assembly diagram for Keston Keston K170 NGClick the diagram to open it on a new page

You can then pinch & zoom to adjust the size.

13 Part number B04100400, M4x10 SCREW - cross recessed pan head M4X10 SCREW - CROSS RECESSED PAN HEAD
Keston part no. B04100400		 £2.10
105 Part number B17400021, RELAY CLAMP-Replaces B17400020-B34003000 RELAY CLAMP-REPLACES B17400020-B34003000
Keston part no. B17400021		 £2.00
106 Part number B04427000, IGN.CONT.BOX-RAM(SN2357)ReplacsB04401001 IGN.CONT.BOX-RAM(SN2357)REPLACSB04401001
Keston part no. B04427000		 £180.76
107 Part number B04421000, OBSOLETE THERMAL FUSE ASSEMBLY OBSOLETE THERMAL FUSE ASSEMBLY
Keston part no. B04421000
108 Part number B04400060, M3x16 SCREW cross recessed pan head M3X16 SCREW CROSS RECESSED PAN HEAD
Keston part no. B04400060		 £2.02
109 Part number B04404001, OBSOLETE K80 & K170 AIR PRESSURE SWITCH OBSOLETE K80 & K170 AIR PRESSURE SWITCH
Keston part no. B04404001
111   OBSOLETE TERMINAL BLOCK BASE ASSEMBLY
Keston part no. B04423000
111 Part number B13412000, TERMINAL BLOCK BASE ASSEMBLY - Main Term TERMINAL BLOCK BASE ASSEMBLY - MAIN TERM
Keston part no. B13412000		 £2.95
113 Part number B04406000, ON/OFF SWITCH ON/OFF SWITCH
Keston part no. B04406000
114 Part number B04407000, GREEN LAMP (supplied without neon) GREEN LAMP (SUPPLIED WITHOUT NEON)
Keston part no. B04407000		 £7.11
115 Part number B04408000, RED LAMP (supplied without neon) RED LAMP (SUPPLIED WITHOUT NEON)
Keston part no. B04408000		 £4.91
116 Part number B04424001, OBSOLETE PRESSURE GAUGE (inc washer and Adapter) OBSOLETE PRESSURE GAUGE (INC WASHER AND ADAPTER)
Keston part no. B04424001
117 Part number B13410002, OBSOLETE K130 HARNESS OBSOLETE K130 HARNESS
Keston part no. B13410002
119 Part number B04412000, NEON BULB NEON BULB
Keston part no. B04412000		 £4.86
121 Part number B04400040, Gasket GASKET
Keston part no. B04400040		 £1.54
122 Part number B04411001, OBSOLETE IGNITION CABLE - RAM (FROM SN 2357) OBSOLETE IGNITION CABLE - RAM (FROM SN 2357)
Keston part no. B04411001
123 Part number B17403001, OBSOLETE RELAY OBSOLETE RELAY
Keston part no. B17403001
124 Part number B17404001, OBSOLETE RELAY SOCKET OBSOLETE RELAY SOCKET
Keston part no. B17404001
125 Part number B17400010, M4x30 SCREW cross recessed pan head M4X30 SCREW CROSS RECESSED PAN HEAD
Keston part no. B17400010		 £0.48
144   OBSOLETE MAIN SUPRESSOR FILTER (FROM SN 1576)
Keston part no. B04402000
145   THERMAL FUSE INSULATION PLATE
Keston part no. B04420000		 £1.47
148   OBSOLETE PUMP TERMINAL BLOCK - K130 ONLY
Keston part no. B13400100
154 Part number B04100780, M4x5 SCREW - cross recessed pan head M4X5 SCREW - CROSS RECESSED PAN HEAD
Keston part no. B04100780		 £0.38
156 Part number B04100840, M4x16 SCREW cross recessed pan head M4X16 SCREW CROSS RECESSED PAN HEAD
Keston part no. B04100840		 £2.02
158 Part number B17411000, TR2 THERMOSTAT - IMIT // OPTIONAL TR2 THERMOSTAT - IMIT // OPTIONAL
Keston part no. B17411000		 £23.92
