SABRE 28 REV 3 (01/08) - (Hydraulics 1)

Appliance Diagram


Hydraulics 1 diagram for Vokera Sabre 28 Rev 3 (01/08)Click the diagram to open it on a new page

You can then pinch & zoom to adjust the size.

2 Part number 10022658, Connection CONNECTION
Vokera part no. 10022658
£15.72
3 Part number 10028141, NOW USE 20003181 Water Pressure switch NOW USE 20003181 WATER PRESSURE SWITCH
Vokera part no. 10028141

3 Part number 20003181, Water pressure switch - Replaced 10028141 WATER PRESSURE SWITCH - REPLACED 10028141
Vokera part no. 20003181
£8.71
7 Part number 2047, Heating bypass valve HEATING BYPASS VALVE
Vokera part no. 2047
£5.51
22 Part number 2907, Safety valve Replaced 8433 (Push Fit) SAFETY VALVE REPLACED 8433 (PUSH FIT)
Vokera part no. 2907
£12.69
23 Part number 10022499, Connection (replaces 2260) CONNECTION (REPLACES 2260)
Vokera part no. 10022499
£4.03
24 Part number 10025080, Flow governor 12 Litres per Minute (Red) FLOW GOVERNOR 12 LITRES PER MINUTE (RED)
Vokera part no. 10025080
£5.75
24 Part number 8009, Flow governor (Blue) FLOW GOVERNOR (BLUE)
Vokera part no. 8009
£3.13
25   PIPE
Vokera part no. 10023950
£15.98
26 Part number 10022349, DHW Actuator replaces 10020330 DHW ACTUATOR REPLACES 10020330
Vokera part no. 10022349
£30.08
27 Part number 1789, Heating Cock 22mm (Washers are 5237) HEATING COCK 22MM (WASHERS ARE 5237)
Vokera part no. 1789
£21.81
28 Part number 1790, Connection Rep 088128 CONNECTION REP 088128
Vokera part no. 1790
£14.05
30 Part number 10025733, Water supply stop cock WATER SUPPLY STOP COCK
Vokera part no. 10025733
£20.60
31 Part number 01005137, Venting Plugs Kit VENTING PLUGS KIT
Vokera part no. 01005137
£8.65
36 Part number 10023949, Pipe PIPE
Vokera part no. 10023949
£32.90
63 Part number 10020898, Safety Valve Outlet Tail SAFETY VALVE OUTLET TAIL
Vokera part no. 10020898
£9.79
124   FLOW GOVERNOR (BLANK)
Vokera part no. 1466
£1.60
201 Part number 5026, 1/2" Fibre Washer 1/2" FIBRE WASHER
Vokera part no. 5026
£0.35
288 Part number 6898, O Ring O RING
Vokera part no. 6898
£0.93
289 Part number 2223, Locking Pin LOCKING PIN
Vokera part no. 2223
£3.47
290 Part number 10027757, Locking Pin LOCKING PIN
Vokera part no. 10027757
£0.68
290 Part number 2165, NOW USE 10027757 LOCKING PIN NOW USE 10027757 LOCKING PIN
Vokera part no. 2165

299   WASHER
Vokera part no. 10022726
£2.67
300 Part number 2222, Locking Pin LOCKING PIN
Vokera part no. 2222
£3.47
303 Part number 2217, Screwed Connection SCREWED CONNECTION
Vokera part no. 2217
£3.49
351 Part number 1823, Nut (Small) NUT (SMALL)
Vokera part no. 1823
£1.41
353 Part number 1824, Nut (Large) NUT (LARGE)
Vokera part no. 1824
£1.41
520 Part number 10027352, Thermistor/NTC Sensor (20004978) THERMISTOR/NTC SENSOR (20004978)
Vokera part no. 10027352
£12.03
