ALPHA
INTEC 26C - (Exploded View)
Appliance Code: 47-532-47

Appliance Diagram


Exploded View diagram for Alpha Intec 26CClick the diagram to open it on a new page

You can then pinch & zoom to adjust the size.

2 Part number 1.030996, EXPANSION VESSEL EXPANSION VESSEL
Alpha part no. 1.030996		 £118.12
3 Part number 3.021702, PUMP PUMP
Alpha part no. 3.021702		 £212.87
9   HYDRAULIC ASSEMBLY SEAL KIT
Alpha part no. 3.022653		 £16.69
10   PRIMARY H/E SEAL KIT
Alpha part no. 3.022654		 £43.37
11   GAS MANIFOLD COVER
Alpha part no. 1.023442		 £34.03
15   AIR INTAKE PIPE
Alpha part no. 1.031101		 £50.04
16 Part number 1.027277, PRIMARY PRESSURE SWITCH PRIMARY PRESSURE SWITCH
Alpha part no. 1.027277		 £23.12
17   PRIMARY H/E SEAL KIT
Alpha part no. 3.022654		 £43.37
18   PRIMARY H/E SEAL KIT
Alpha part no. 3.022654		 £43.37
19   PRIMARY H/E SEAL KIT
Alpha part no. 3.022654		 £43.37
20   PRIMARY H/E SEAL KIT
Alpha part no. 3.022654		 £43.37
21   SCREW M4 X 6 - CONDENSATE TRAP
Alpha part no. 1.0153		 £1.12
22 Part number 1.027178, FAN FAN
Alpha part no. 1.027178		 £164.65
23 Part number 1.023999, BURNER CD25 BURNER CD25
Alpha part no. 1.023999		 £91.42
24   PRESSURE POINT CAP
Alpha part no. 1.025690		 £5.22
27 Part number 1.021972, SPRING PIPE CLAMP FOR D.22 SILICONE PIPE SPRING PIPE CLAMP FOR D.22 SILICONE PIPE
Alpha part no. 1.021972		 £1.13
29   SCREW M5 X 25
Alpha part no. 1.023578		 £0.53
30 Part number 1.028572, 3-WAY VALVE MOTOR 3-WAY VALVE MOTOR
Alpha part no. 1.028572		 £53.35
34   SCREW M5 X 8
Alpha part no. 1.1176		 £1.51
35   METAL SHEET CLIP - INTEC
Alpha part no. 2.014033		 £1.40
36   CONDENSATE DRAIN ELBOW
Alpha part no. 1.023581		 £12.32
37   PIPE COLD INLET (CD25/28X)
Alpha part no. 1.023583		 £14.36
38   TWO PUMP COUPLER FITTINGS OKIT
Alpha part no. 3.021694		 £16.40
43   M5 LOCK WASHER -STAINLESS STEEL (CD50)
Alpha part no. 1.012468		 £1.17
44 Part number 1.8372, M5 X 10 SCREW M5 X 10 SCREW
Alpha part no. 1.8372		 £0.38
48   HYDRAULIC ASSEMBLY SEAL KIT
Alpha part no. 3.022653		 £16.69
54 Part number 1.016187, SILICONE TUBE 8 X 12 750MM SILICONE TUBE 8 X 12 750MM
Alpha part no. 1.016187		 £13.94
55   COLD INLET BLOCK
Alpha part no. 1.028647		 £45.22
56 Part number 1.024296, FLUE TEMPERATURE SENSOR FLUE TEMPERATURE SENSOR
Alpha part no. 1.024296		 £22.36
57   PRIMARY H/E SEAL KIT
Alpha part no. 3.022654		 £43.37
60   FLUE AND AIR CONNECTION
Alpha part no. 3.022655		 £16.69
61   FAN FLANGE
Alpha part no. 1.031102		 £7.49
62   PLUG FOR POCKET FLANGE CD25/28/35C
Alpha part no. 1.021464		 £6.86
67   FLUE TURRET
Alpha part no. 1.030636		 £21.29
72 Part number 3.020380, 3-WAY MOTOR CARTRIDGE ASSEMBLY 3-WAY MOTOR CARTRIDGE ASSEMBLY
Alpha part no. 3.020380		 £190.66
74   FLUE AND AIR CONNECTION
Alpha part no. 3.022655		 £16.69
75   CLIP - INTEC RANGE
Alpha part no. 1.029426		 £1.88
76   SCREW M5 X 16
Alpha part no. 1.010289		 £0.34
88 Part number 1.028650, AUTO BYPASS HOUSING AUTO BYPASS HOUSING
Alpha part no. 1.028650		 £103.51
89 Part number 1.028643, 3-BAR PRESSURE RELIEF VALVE 3-BAR PRESSURE RELIEF VALVE
Alpha part no. 1.028643		 £30.66
90   FLUE TRAY CONNECTION
Alpha part no. 1.030667		 £12.48
92   PRIMARY H/E SEAL KIT
Alpha part no. 3.022654		 £43.37
93   BURNER INSP WINDOW BRACKET
Alpha part no. 2.013322		 £2.40
94   HYDRAULIC ASSEMBLY SEAL KIT
Alpha part no. 3.022653		 £16.69
97   GAS MANIFOLD
Alpha part no. 1.023334		 £94.21
98   COMB CHAMBER INS PANEL FRONT
Alpha part no. 1.024543		 £8.83
99   PRIMARY H/E SEAL KIT
Alpha part no. 3.022654		 £43.37
100 Part number 1.028548, HOUSING, OUTLET MANIFOLD HOUSING, OUTLET MANIFOLD
Alpha part no. 1.028548		 £84.04
105 Part number 3.017281, CONDENSATE TRAP CONDENSATE TRAP
Alpha part no. 3.017281		 £39.93
106 Part number 1.028570, NOW USE 1.035365 FLOW SWITCH NOW USE 1.035365 FLOW SWITCH
Alpha part no. 1.028570
106   DHW FLOW SWITCH
Alpha part no. 1.035365		 £42.68
108   HYDRAULIC ASSEMBLY SEAL KIT
Alpha part no. 3.022653		 £16.69
109 Part number 1.019144, PIPE- CONDENSATION DISCHARGE PIPE- CONDENSATION DISCHARGE
Alpha part no. 1.019144		 £11.76
110 Part number 1.031447, PRI HEAT EX - INT 26C,24X,18S PRI HEAT EX - INT 26C,24X,18S
Alpha part no. 1.031447		 £320.60
111   HYDRAULIC ASSEMBLY SEAL KIT
Alpha part no. 3.022653		 £16.69
112   BY-PASS ASSEMBLY
Alpha part no. 3.021689		 £33.38
114   PRIMARY H/E SEAL KIT
Alpha part no. 3.022654		 £43.37
115   HYDRAULIC ASSEMBLY SEAL KIT
Alpha part no. 3.022653		 £16.69
116 Part number 1.025380, DHW TEMPERATURE SENSOR DHW TEMPERATURE SENSOR
Alpha part no. 1.025380		 £15.69
117   HYDRAULIC ASSEMBLY SEAL KIT
Alpha part no. 3.022653		 £16.69
118   HYDRAULIC ASSEMBLY SEAL KIT
Alpha part no. 3.022653		 £16.69
121 Part number 3.021692, DHW 12 PLATE HEAT EXCHANGER WITH SEAL KIT DHW 12 PLATE HEAT EXCHANGER WITH SEAL KIT
Alpha part no. 3.021692		 £134.44
126 Part number 1.016967, SPRING CLIP SILICONE TUBE SPRING CLIP SILICONE TUBE
Alpha part no. 1.016967		 £1.35
127 Part number 1.024387, T PIECE - MANIFOLD TRAY TUBE T PIECE - MANIFOLD TRAY TUBE
Alpha part no. 1.024387		 £8.11
135   VENTURI (CD24S/C)
Alpha part no. 1.010918		 £39.33
138   SCREW 3.5 X 6.4
Alpha part no. 1.1656		 £1.18
147 Part number 1.018162, SPARK GENERATOR (CD24S/C) SPARK GENERATOR (CD24S/C)
Alpha part no. 1.018162		 £36.49
156 Part number 3.016875, CONDENSATE TRAP, COMPLETE (CD18R) CONDENSATE TRAP, COMPLETE (CD18R)
Alpha part no. 3.016875		 £29.38
157   SCREW M4 X 8 (CD50) FLUE INLET / OUTLET MOULDING
Alpha part no. 1.2170		 £0.29
158 Part number 1.019228, DRAIN TAP - CONDENSATE TRAP DRAIN TAP - CONDENSATE TRAP
Alpha part no. 1.019228		 £6.15
159 Part number 3.017477, IGNITION ELECTRODE AND LEAD IGNITION ELECTRODE AND LEAD
Alpha part no. 3.017477		 £46.14
160   AIR TRAP PLUG
Alpha part no. 1.021892		 £0.25
161   SCREW 2.9 X 9.5 - SELF TAPPING
Alpha part no. 1.6984		 £1.12
170   M5 COPPER WASHER
Alpha part no. 1.016869		 £1.12
172   PRIMARY H/E SEAL KIT
Alpha part no. 3.022654		 £43.37
176 Part number 1.032007, FLAME SENSING ELECTRODE FLAME SENSING ELECTRODE
Alpha part no. 1.032007		 £30.42
177   HOSE UNION FOR SILICONE TUBES (CD24S/C)
Alpha part no. 1.6221		 £0.71
179 Part number 1.027110, AUTOMATIC AIR VENT AUTOMATIC AIR VENT
Alpha part no. 1.027110		 £56.22
183 Part number 1.021762, TEMPERATURE SENSOR (NTC) (240/280/500/CB/CD/SY) TEMPERATURE SENSOR (NTC) (240/280/500/CB/CD/SY)
Alpha part no. 1.021762		 £14.92
185   BRASS FAN PRESSURE PORT CD25/28/35C
Alpha part no. 1.024996		 £3.95
190   PUMP ONLY - INTEC
Alpha part no. 3.022793		 £205.69
196 Part number 1.025797, O/H THERMOSTAT 100c O/H THERMOSTAT 100C
Alpha part no. 1.025797		 £15.68
198   PIPE CLAMP(SILICONE)
Alpha part no. 1.010500		 £1.35
200   SCREW M5 X 14MM POZI-DRIVE
Alpha part no. 1.024084		 £1.17
202   HYDRAULIC ASSEMBLY SEAL KIT
Alpha part no. 3.022653		 £16.69
204   FLEXIBLE HOSE (1.200)
Alpha part no. 1.025898		 £2.77
206 Part number 1.019654, L.600 HOSE (CD24S/C) L.600 HOSE (CD24S/C)
Alpha part no. 1.019654		 £16.27
208   WASHER M3 X 7 X 0.5MM (CD50)
Alpha part no. 1.011163		 £0.84
212 Part number 1.031823, GAS VALVE ASSEMBLY GAS VALVE ASSEMBLY
Alpha part no. 1.031823		 £146.31
213   M4 BRASS WASHER
Alpha part no. 1.0237		 £0.57
221   INJECTOR INTEC 26C,18S,24X LPG
Alpha part no. 1.022050		 £25.96
221   INJECTOR-INTEC 30C, 28 LPG
Alpha part no. 1.022052		 £81.79
221   MAIN INJECTOR 5.1MM
Alpha part no. 1.022472		 £14.63
221   BURNER INJECTOR - 6.80MM
Alpha part no. 1.031471		 £17.23
221   INTEC 28S, 34C, 40GS LPG INJECTOR
Alpha part no. 1.022049		 £20.60
222 Part number 1.0017, SCREW M6 X 12 (CB50) SCREW M6 X 12 (CB50)
Alpha part no. 1.0017		 £1.28
228   HYDRAULIC ASSEMBLY SEAL KIT
Alpha part no. 3.022653		 £16.69
363   FLUE AND AIR CONNECTION
Alpha part no. 3.022655		 £16.69
