ARISTON
MICROGENUS HE 32MFFI - (Casing Expansion Vessel)
Appliance Code: 47-116-39

Appliance Diagram


Casing Expansion Vessel diagram for Ariston Microgenus HE 32MFFIClick the diagram to open it on a new page

You can then pinch & zoom to adjust the size.

201 Part number 990373, SUPPORT PLATE SUPPORT PLATE
Ariston part no. 990373		 £2,73
202 Part number 65101317, GASKET (AIR PRESSURE SWITCH) GASKET (AIR PRESSURE SWITCH)
Ariston part no. 65101317		 £2,67
206 Part number 65102164-01, AIR PRESSURE SWITCH 40 Pa AIR PRESSURE SWITCH 40 PA
Ariston part no. 65102164-01		 £43,26
206 Part number 65102164, NOW USE 65102164-01 AIR PRESSURE SWITCH NOW USE 65102164-01 AIR PRESSURE SWITCH
Ariston part no. 65102164
207 Part number 65101271, EARTH CABLE (FAN) EARTH CABLE (FAN)
Ariston part no. 65101271		 £2,06
208 Part number 573343, GASKET (FAN) GASKET (FAN)
Ariston part no. 573343		 £6,80
210 Part number 573329, AIR INTAKE COVER AIR INTAKE COVER
Ariston part no. 573329		 £6,22
212 Part number 990368, SEAL (SILICONE - D=5 mm) SEAL (SILICONE - D=5 MM)
Ariston part no. 990368		 £5,52
216 Part number 65102566, FAN FAN
Ariston part no. 65102566		 £52,23
220 Part number 65104623, CONDENSATE TRAP CONDENSATE TRAP
Ariston part no. 65104623		 £16,12
220 Part number 65104290, NOW USE 65104623 CONDENSATE TRAP NOW USE 65104623 CONDENSATE TRAP
Ariston part no. 65104290
303 Part number 995315, RESTRICTOR (D=41) RESTRICTOR (D=41)
Ariston part no. 995315		 £4,61
303   NOW USE 995315 RESTRICTOR (D.41)
Ariston part no. 65102774
304   FLUE (EXHAUST MANIFOLD / HEADER)
Ariston part no. 999400		 £25,36
304   NOW USE 999400 FLUE (EXHAUST MANIFOLD / HEADER)
Ariston part no. 990678
306 Part number 998595, PLUG (AIR INTAKE) PLUG (AIR INTAKE)
Ariston part no. 998595		 £6,47
310 Part number 570717, SPRING (FASTENING) SPRING (FASTENING)
Ariston part no. 570717		 £4,21
315 Part number 571562, CABLE CLAMP CABLE CLAMP
Ariston part no. 571562		 £2,67
320 Part number 998637, GASKET (FLUE COLLAR) GASKET (FLUE COLLAR)
Ariston part no. 998637		 £1,65
322 Part number 998565, COVER (FLUE TEST POINT) (TO 03/06) COVER (FLUE TEST POINT) (TO 03/06)
Ariston part no. 998565		 £3,28
323 Part number 998636, GASKET (FLUE TEST POINT) (TO 03/06) GASKET (FLUE TEST POINT) (TO 03/06)
Ariston part no. 998636		 £5,17
324   PIPE (EXPANSION VESSEL)
Ariston part no. 65100681		 £14,99
325 Part number 573521, GASKET 3/8" GASKET 3/8"
Ariston part no. 573521		 £0,94
327 Part number 998616, EXPANSION VESSEL 6L EXPANSION VESSEL 6L
Ariston part no. 998616		 £82,16
337   HYDRAULIC GROUP SUPPORT
Ariston part no. 65104577		 £14,80
338 Part number 998776, BUSH (EXPANSION VESSEL) BUSH (EXPANSION VESSEL)
Ariston part no. 998776		 £6,63
339 Part number 998581, LOCK NUT 3/8" LOCK NUT 3/8"
Ariston part no. 998581		 £4,54
342   CASE PANEL (L.H. SIDE)
Ariston part no. 998477		 £161,57
343 Part number 995305, WASHER WASHER
Ariston part no. 995305		 £7,68
344 Part number 995343, PANEL (FRONT CASE) PANEL (FRONT CASE)
Ariston part no. 995343		 £49,48
345   CASE PANEL (R.H. SIDE)
Ariston part no. 998476		 £140,70
346 Part number 991944, FRONT PANEL CROSS BAR FRONT PANEL CROSS BAR
Ariston part no. 991944		 £4,53
380   SUPPORT
Ariston part no. 65101393		 £13,81
392 Part number 65102575, CLIPS CLIPS
Ariston part no. 65102575		 £5,45
393   DISCHARGE PIPE (CONDENSATE)
Ariston part no. 65102563		 £26,92
394 Part number 65102564, CLAMP CLAMP
Ariston part no. 65102564		 £6,28
401 Part number 65100244, GAS VALVE GAS VALVE
Ariston part no. 65100244		 £197,78
404 Part number 65100704, EARTH CABLE (VALVE) EARTH CABLE (VALVE)
Ariston part no. 65100704		 £2,82
405 Part number 574279, GASKET (SPARK GENERATOR) GASKET (SPARK GENERATOR)
Ariston part no. 574279		 £1,45
406 Part number 573520, GASKET 3/4" GASKET 3/4"
Ariston part no. 573520		 £0,94
407 Part number 573576, COMPENSATION TUBE COMPENSATION TUBE
Ariston part no. 573576		 £7,22
408 Part number 573325, RIVET RIVET
Ariston part no. 573325		 £0,98
418   GAS PIPE
Ariston part no. 65102569		 £24,41
444 Part number 65100249, SPARK GENERATOR SPARK GENERATOR
Ariston part no. 65100249		 £72,22
