VAILLANT
VIH GB 310/2 S 2011-2016 (0010010905) - (Exploded View)
Appliance Code: VIH GB 310-2 S

Appliance Diagram


Exploded View diagram for Vaillant VIH GB 310/2 S 2011-2016 (0010010905)Click the diagram to open it on a new page

You can then pinch & zoom to adjust the size.

1 Part number 0020009863, installation kit expansion vessel INSTALLATION KIT EXPANSION VESSEL
Vaillant part no. 0020009863

1 Part number 0020181041, Expansion vessel, incl. bracket (25 L) EXPANSION VESSEL, INCL. BRACKET (25 L)
Vaillant part no. 0020181041
£189.89
2 Part number 0020127599, Manifold, Brass (Safety Group) MANIFOLD, BRASS (SAFETY GROUP)
Vaillant part no. 0020127599
£154.30
3 Part number 0020127600, Pressure relief valve PRESSURE RELIEF VALVE
Vaillant part no. 0020127600
£41.37
4 Part number 0020009867, tundish TUNDISH
Vaillant part no. 0020009867
£35.98
5 Part number 0020009866, Temperature&pressure relief valve TEMPERATURE&PRESSURE RELIEF VALVE
Vaillant part no. 0020009866
£86.45
6   VALVE, MOTORISED (2-PORT)
Vaillant part no. 0020127598
£170.66
7   COVER, WITH LOGO
Vaillant part no. 0020010128
£18.38
8 Part number 0020127606, Casing (EPP) CASING (EPP)
Vaillant part no. 0020127606
£51.11
8 Part number 0020145261, Fastening kit (PK4) FASTENING KIT (PK4)
Vaillant part no. 0020145261
£45.06
9 Part number 0020127604, Thermostat, cylinder controls twin THERMOSTAT, CYLINDER CONTROLS TWIN
Vaillant part no. 0020127604
£129.46
10 Part number 0020127601, Heating rod HEATING ROD
Vaillant part no. 0020127601
£215.52
10 Part number 0020143611, Heating element, Titan HEATING ELEMENT, TITAN
Vaillant part no. 0020143611
£409.37
11 Part number 0020127603, Gasket, heating rod GASKET, HEATING ROD
Vaillant part no. 0020127603
£8.47
