500	ACCESS PANEL Main part n^o. 5118384	£14.15
501	ELECTRIC BOX COVER Main part n^o. 5118383	£29.53
502	PANEL - ACCESS Main part n^o. 248072	£5.71
503	NOW USE 7679739 PCB SYSTEM 28 ECO Main part n^o. 5131263
503	PCB SYSTEM 28 Main part n^o. 7679739	£115.60
504	PRESSURE GAUGE Main part n^o. 5118385	£31.20
505	COVER - INTEGRAL TIMER Main part n^o. 248076	£5.71
506	PANEL CONTROLS Main part n^o. 5130613	£34.29
507	COV CONT AY COMBI Main part n^o. 5130614	£32.04
508	TERMINAL BLOCK Main part n^o. 247480	£6.95
509	NOW USE 7727139 FUSE 2A-250V Main part n^o. 248089
509	NOW USE 7727139 FUSE 2A 250V IN FUSE HOLDER Main part n^o. 720853801
509	KIT TERMINAL BLOCK AND FUSES Main part n^o. 7727139	£28.75
509	FUSE 2A 250V IN FUSEHOLDER Baxi part n^o. 7727139	£28.75
510	FUSE HOLDER Main part n^o. 247481	£4.44
511	SWITCH - SELECTOR Main part n^o. 248095	£11.61
512	CONTROL KNOB-POTENTIOMETER Main part n^o. 005409691
513	CONTROL KNOB-SELECTOR Main part n^o. 005409681
514	PIN - HINGED FACIA PANEL Main part n^o. 248194	£2.22
515	DRIVE PIN - POTENTIOMETER Main part n^o. 248096	£3.16
516	TERMINAL BLOCK Main part n^o. 5114775	£5.71
517	SCREW NO.6X20 PLAS PAN POZ SZ Main part n^o. 5109202	£2.81
518	SCREWNO6X6.5 ABPAN POZ SN Main part n^o. 612841	£2.96
519	SCR-ST-NO6X3/8 PAN HD PZ ZP Main part n^o. 062699	£3.03
519	NOW USE 062699 SCREW NO 6X9.5 AB PAN POZ SZ Main part n^o. 670037
520	SCREW 6A X 1" LG S/T Main part n^o. 612830	£3.03
