VAILLANT
AQUA PLUS VUI 362-7 R3 2005-2008 - (08 Hydraulic Parts)
Appliance Code: 47-044-29 (306592)

Appliance Diagram


08 Hydraulic Parts diagram for Vaillant Aqua Plus VUI 362-7 R3 2005-2008Click the diagram to open it on a new page

You can then pinch & zoom to adjust the size.

1 Part number 064724, Heat exchanger dhw (28 plates) HEAT EXCHANGER DHW (28 PLATES)
Vaillant part no. 064724		 £118.22
2 Part number 0020183478, Motor d.h.w. pump (E1) MOTOR D.H.W. PUMP (E1)
Vaillant part no. 0020183478		 £276.44
2 Part number 255031, NOW USE 0020183478 d.h.w. pump motor NOW USE 0020183478 D.H.W. PUMP MOTOR
Vaillant part no. 255031
3 Part number 092001, Connection piece with non-return valve CONNECTION PIECE WITH NON-RETURN VALVE
Vaillant part no. 092001		 £71.14
4   PUMP, HIGH-EFFICIENCY (IF THIS IS THE REPLACEMENT PART THEN PART NUMBER 0010032769 CABLE IS ALSO REQUIRED)
Vaillant part no. 0010030634		 £230.09
4 Part number 160977, NOW USE 0010030634 Pump, VP5/2 S2 NOW USE 0010030634 PUMP, VP5/2 S2
Vaillant part no. 160977
4A Part number 118951, Pan head screw, M6x28,5 PAN HEAD SCREW, M6X28,5
Vaillant part no. 118951		 £4.92
5 Part number 061707, automatic de-aerator AUTOMATIC DE-AERATOR
Vaillant part no. 061707		 £20.36
6 Part number 252457, Diverter valve DIVERTER VALVE
Vaillant part no. 252457		 £143.60
7 Part number 140429, Actuator - diverter valve ACTUATOR - DIVERTER VALVE
Vaillant part no. 140429		 £58.90
8 Part number 194819, Aqua-sensor AQUA-SENSOR
Vaillant part no. 194819		 £87.53
9 Part number 711933, Sensor, hall effect SENSOR, HALL EFFECT
Vaillant part no. 711933		 £23.13
10 Part number 190745, Pressure relief valve, 10 bar PRESSURE RELIEF VALVE, 10 BAR
Vaillant part no. 190745		 £19.42
11 Part number 190732, pressure relief valve PRESSURE RELIEF VALVE
Vaillant part no. 190732		 £45.83
12 Part number 181081, expansion vessel 1 ltr. EXPANSION VESSEL 1 LTR.
Vaillant part no. 181081		 £107.40
13 Part number 181079, expansion vessel 10 ltr. EXPANSION VESSEL 10 LTR.
Vaillant part no. 181079		 £113.02
14   RESERVOIR 15 LTR.
Vaillant part no. 064072		 £263.99
14A Part number 0020050743, Cover COVER
Vaillant part no. 0020050743		 £225.56
14B Part number 0020050744, Gasket GASKET
Vaillant part no. 0020050744		 £6.91
15   PRICE ON APPLICATION
Vaillant part no. 0000
16 Part number 101271, Pressure gauge PRESSURE GAUGE
Vaillant part no. 101271		 £38.09
17 Part number 019392, Connecting piece CONNECTING PIECE
Vaillant part no. 019392		 £86.37
17A Part number 118937, Pan head screw (M 5x12) PAN HEAD SCREW (M 5X12)
Vaillant part no. 118937		 £5.13
18 Part number 094111, connecting tube CONNECTING TUBE
Vaillant part no. 094111		 £22.54
19 Part number 094115, connecting tube CONNECTING TUBE
Vaillant part no. 094115		 £12.96
20 Part number 019383, Connecting tube CONNECTING TUBE
Vaillant part no. 019383		 £26.96
21 Part number 022590, Connecting tube CONNECTING TUBE
Vaillant part no. 022590		 £10.44
22 Part number 023227, connecting tube CONNECTING TUBE
Vaillant part no. 023227		 £40.07
23   PRICE ON APPLICATION
Vaillant part no. 0000
24 Part number 094122, Connecting tube CONNECTING TUBE
Vaillant part no. 094122		 £35.01
25 Part number 094112, Connecting Tube CONNECTING TUBE
Vaillant part no. 094112		 £35.33
26 Part number 0020050697, Distributor DISTRIBUTOR
Vaillant part no. 0020050697		 £6.86
27 Part number 091700, Warm water connection tube WARM WATER CONNECTION TUBE
Vaillant part no. 091700		 £10.44
28 Part number 094113, Warm water connection tube WARM WATER CONNECTION TUBE
Vaillant part no. 094113		 £18.06
29 Part number 094140, connecting tube CONNECTING TUBE
Vaillant part no. 094140		 £40.07
30 Part number 150240, Automatic bypass valve 2.5m AUTOMATIC BYPASS VALVE 2.5M
Vaillant part no. 150240		 £15.17
30 Part number 150242, Automatic bypass valve 1.7m AUTOMATIC BYPASS VALVE 1.7M
Vaillant part no. 150242		 £22.37
30 Part number 150243, Automatic bypass valve 3.5m AUTOMATIC BYPASS VALVE 3.5M
Vaillant part no. 150243		 £31.49
31 Part number 094114, connecting tube CONNECTING TUBE
Vaillant part no. 094114		 £9.77
32 Part number 023226, connecting tubes (set) CONNECTING TUBES (SET)
Vaillant part no. 023226		 £60.69
33 Part number 092002, Connection piece CONNECTION PIECE
Vaillant part no. 092002		 £6.86
34 Part number 094139, connecting tube CONNECTING TUBE
Vaillant part no. 094139		 £40.07
35 Part number 023226, connecting tubes (set) CONNECTING TUBES (SET)
Vaillant part no. 023226		 £60.69
36 Part number 023226, connecting tubes (set) CONNECTING TUBES (SET)
Vaillant part no. 023226		 £60.69
37 Part number 014675, Filling valve without non-return valve FILLING VALVE WITHOUT NON-RETURN VALVE
Vaillant part no. 014675		 £29.02
38 Part number 125151, handle for drain cock HANDLE FOR DRAIN COCK
Vaillant part no. 125151		 £7.24
39   PRICE ON APPLICATION
Vaillant part no. 0000
40   CONNECTING TUBE
Vaillant part no. 023225		 £10.76
41 Part number 014676, Non-return valve NON-RETURN VALVE
Vaillant part no. 014676		 £19.77
42 Part number 095610, Tube, flexible TUBE, FLEXIBLE
Vaillant part no. 095610		 £18.11
43   PRICE ON APPLICATION
Vaillant part no. 0000
44   PRICE ON APPLICATION
Vaillant part no. 0000
45   PRICE ON APPLICATION
Vaillant part no. 0000
46 Part number 981142, Sealing ring, (PK10) SEALING RING, (PK10)
Vaillant part no. 981142		 £8.62
47   PRICE ON APPLICATION
Vaillant part no. 0000
48   PRICE ON APPLICATION
Vaillant part no. 0000
49 Part number 011603, Limiter 14l/min LIMITER 14L/MIN
Vaillant part no. 011603		 £6.86
50 Part number 074514, Filter FILTER
Vaillant part no. 074514		 £6.86
51 Part number 252805, Sensor - NTC SENSOR - NTC
Vaillant part no. 252805		 £23.36
52 Part number 256304, cable tree CABLE TREE
Vaillant part no. 256304
53 Part number 219622, Spring clamp (PK10) SPRING CLAMP (PK10)
Vaillant part no. 219622		 £9.77
54 Part number 219623, Spring clamp (PK10) SPRING CLAMP (PK10)
Vaillant part no. 219623		 £9.77
55 Part number 0020107694, Clip, (PK5) CLIP, (PK5)
Vaillant part no. 0020107694		 £7.24
56 Part number 219621, Spring clamp, (PK10) SPRING CLAMP, (PK10)
Vaillant part no. 219621		 £9.77
57 Part number 0020107709, Support SUPPORT
Vaillant part no. 0020107709		 £6.86
57 Part number 085751, NOW USE 0020107709 pressure gauge clip NOW USE 0020107709 PRESSURE GAUGE CLIP
Vaillant part no. 085751
60 Part number 981140, Sealing ring, 3/4 (PK10) SEALING RING, 3/4 (PK10)
Vaillant part no. 981140		 £7.25
61 Part number 981142, Sealing ring, (PK10) SEALING RING, (PK10)
Vaillant part no. 981142		 £8.62
62 Part number 981149, Sealing ring, (PK10) SEALING RING, (PK10)
Vaillant part no. 981149		 £8.20
63 Part number 981146, Sealing ring, (PK10) SEALING RING, (PK10)
Vaillant part no. 981146		 £6.89
64 Part number 981151, O-ring, (PK10) O-RING, (PK10)
Vaillant part no. 981151		 £8.09
65 Part number 981163, O-ring, (PK10) O-RING, (PK10)
Vaillant part no. 981163		 £7.24
66 Part number 981165, O-ring, (PK10) O-RING, (PK10)
Vaillant part no. 981165		 £6.89
67 Part number 981154, O-ring, (PK10) O-RING, (PK10)
Vaillant part no. 981154		 £6.89
68 Part number 981155, O-ring, (PK10) O-RING, (PK10)
Vaillant part no. 981155		 £6.53
69 Part number 981373, Sealing ring (PK10) SEALING RING (PK10)
Vaillant part no. 981373		 £6.86
70 Part number 980308, O-ring (PK10) O-RING (PK10)
Vaillant part no. 980308		 £6.86
