VAILLANT
THERMOCOMPACT 615E VU 152/2-5 R1 2002-2004 - (05 Gas Section (R1 2002-2004 ))
Appliance Code: 41-044-23-R1

Appliance Diagram


05 Gas Section (R1 2002-2004 ) diagram for Vaillant Thermocompact 615E VU 152/2-5 R1 2002-2004Click the diagram to open it on a new page

You can then pinch & zoom to adjust the size.

1 Part number 114189, Gas section H-gas GAS SECTION H-GAS
Vaillant part no. 114189
£96.73
1 Part number 053561, Gas section GAS SECTION
Vaillant part no. 053561
£140.66
2 Part number 090915, Connection cable CONNECTION CABLE
Vaillant part no. 090915
£13.23
2 Part number 114192, Connection cable CONNECTION CABLE
Vaillant part no. 114192
£13.63
3   GAS TUBE VU
Vaillant part no. 123526
£20.26
4 Part number 0020107695, Screw, (PK10) SCREW, (PK10)
Vaillant part no. 0020107695
£6.28
5 Part number 123522, Gas tube GAS TUBE
Vaillant part no. 123522
£23.67
6 Part number 0020085467, Gasket GASKET
Vaillant part no. 0020085467
£6.17
7 Part number 981142, Sealing ring, (PK10) SEALING RING, (PK10)
Vaillant part no. 981142
£6.63
8   THROTTLE JET 1 X 3.75
Vaillant part no. 049744
£6.28
9 Part number 981307, Sealing ring, (PK10) SEALING RING, (PK10)
Vaillant part no. 981307
£6.28
