GLOWWORM
ENERGY 35 STORE - (09 Pipe Work)
Appliance Code: 47-019-37

Appliance Diagram


09 Pipe Work diagram for Glowworm Energy 35 StoreClick the diagram to open it on a new page

You can then pinch & zoom to adjust the size.

1 Part number 0020125445, Pipe tank 42L PIPE TANK 42L
Glowworm part no. 0020125445		 £18.05
2 Part number 2000801956, O-ring (PK10) O-RING (PK10)
Glowworm part no. 2000801956		 £8.94
3 Part number 0020018450, Clip (PK10) CLIP (PK10)
Glowworm part no. 0020018450		 £31.22
4 Part number 0020125476, Gasket (x10) GASKET (X10)
Glowworm part no. 0020125476		 £10.49
5 Part number 0020018462, Clip (PK10) CLIP (PK10)
Glowworm part no. 0020018462		 £15.49
6 Part number 2000802473, O-ring heat Ex / Pipe (PK10) O-RING HEAT EX / PIPE (PK10)
Glowworm part no. 2000802473		 £6.23
7 Part number S5485200, Sealing ring (PK100) SEALING RING (PK100)
Glowworm part no. S5485200		 £12.65
8 Part number 0020125455, Pipe inter-tank 42L PIPE INTER-TANK 42L
Glowworm part no. 0020125455		 £22.02
9 Part number S1037900, Clip, (PK10) CLIP, (PK10)
Glowworm part no. S1037900		 £6.65
10 Part number 0020125443, Pipe telescopic / heat exchangeur PIPE TELESCOPIC / HEAT EXCHANGEUR
Glowworm part no. 0020125443		 £11.87
11 Part number 0020125441, Pipe heat exchanger / filter PIPE HEAT EXCHANGER / FILTER
Glowworm part no. 0020125441		 £9.44
12 Part number 0020125440, NOW USE 0020105940 FILTER NOW USE 0020105940 FILTER
Glowworm part no. 0020125440
12   FILTER
Glowworm part no. 0020105940		 £44.49
13 Part number S5466500, O-ring (PK20) O-RING (PK20)
Glowworm part no. S5466500		 £14.93
14   PIPE FILTER / 3 WAY VALVE
Glowworm part no. 0020125442		 £17.41
15 Part number S5466200, Clip 10mm (PK10) CLIP 10MM (PK10)
Glowworm part no. S5466200		 £9.12
16 Part number S1075600, Pipe bypass PIPE BYPASS
Glowworm part no. S1075600		 £8.93
18 Part number 0020097203, O-ring (PK10) O-RING (PK10)
Glowworm part no. 0020097203		 £6.23
19   HOSE
Glowworm part no. 0020125450		 £9.33
21 Part number S5466400, O-Ring (PK20) O-RING (PK20)
Glowworm part no. S5466400		 £16.51
22 Part number S5490900, OBSOLETE Clip 13.5mm (PK15) OBSOLETE CLIP 13.5MM (PK15)
Glowworm part no. S5490900		 £12.58
23 Part number 0020125453, Hose tank / 3 way valve HOSE TANK / 3 WAY VALVE
Glowworm part no. 0020125453		 £39.22
24 Part number 0020125454, Hose tank / 3 way valve HOSE TANK / 3 WAY VALVE
Glowworm part no. 0020125454		 £40.01
25 Part number 0020125452, Hose pump / tank 42L HOSE PUMP / TANK 42L
Glowworm part no. 0020125452		 £43.74
26   GAS PIPE
Glowworm part no. 0020125451		 £22.78
27 Part number 2000801950, O-ring for pipe (PK20) O-RING FOR PIPE (PK20)
Glowworm part no. 2000801950		 £10.22
29 Part number 05459000, CLIP PACK (PK15) CLIP PACK (PK15)
Glowworm part no. 05459000		 £16.08
30 Part number 0020097306, Sealing ring pack (PK10) SEALING RING PACK (PK10)
Glowworm part no. 0020097306		 £18.14
31 Part number 0020125444, PIPE PUMP PIPE PUMP
Glowworm part no. 0020125444		 £13.69
32 Part number 0020018829, Screw AF M4x12 (PK10) SCREW AF M4X12 (PK10)
Glowworm part no. 0020018829		 £6.23
33 Part number S1045500, FLEXIBLE HOSE FLEXIBLE HOSE
Glowworm part no. S1045500		 £16.34
