GLOWWORM
ENERGY 35 STORE - (06 Electronics)
Appliance Code: 47-019-37

Appliance Diagram


06 Electronics diagram for Glowworm Energy 35 StoreClick the diagram to open it on a new page

You can then pinch & zoom to adjust the size.

1 Part number S5490600, Screw (pk50) SCREW (PK50)
Glowworm part no. S5490600
£13.57
2 Part number A000035144, ignition transformer IGNITION TRANSFORMER
Glowworm part no. A000035144
£36.07
3 Part number 0020105959, Cable Electronics CABLE ELECTRONICS
Glowworm part no. 0020105959
£6.23
4 Part number 0020105963, Button RESET BUTTON RESET
Glowworm part no. 0020105963
£6.23
5 Part number 0020105922, Instrument panel INSTRUMENT PANEL
Glowworm part no. 0020105922
£31.67
6 Part number 0020084490, Electrical conduit (x5) ELECTRICAL CONDUIT (X5)
Glowworm part no. 0020084490
£6.23
7 Part number 0020084521, Plug 6 wires (x5) PLUG 6 WIRES (X5)
Glowworm part no. 0020084521
£27.82
8 Part number 0020097373, Plug 2 wires (x5) PLUG 2 WIRES (X5)
Glowworm part no. 0020097373
£9.01
9 Part number 0020105962, Power cable with ON/OFF switch POWER CABLE WITH ON/OFF SWITCH
Glowworm part no. 0020105962
£15.91
10 Part number 0020097250, Screw (PK10) SCREW (PK10)
Glowworm part no. 0020097250
£6.03
11 Part number 0020105960, Button ON/OFF BUTTON ON/OFF
Glowworm part no. 0020105960
£6.23
12 Part number 0020105958, Display DISPLAY
Glowworm part no. 0020105958
£58.28
13   WIRING HARNESS
Glowworm part no. 0020216398
£36.50
14 Part number 0020212696, Electronics ELECTRONICS
Glowworm part no. 0020212696
£99.67
15 Part number S5739800, Temperature sensor TEMPERATURE SENSOR
Glowworm part no. S5739800
£23.87
16 Part number 0020079603, Fuse 2,0 A T2H (PK10) FUSE 2,0 A T2H (PK10)
Glowworm part no. 0020079603
£13.28
17 Part number 0020105965, Control box CONTROL BOX
Glowworm part no. 0020105965
£19.21
18 Part number 0020101788, Cable tree gas valve (harness) CABLE TREE GAS VALVE (HARNESS)
Glowworm part no. 0020101788
£7.11
