GLOWWORM
HOME 15R FROM 2015- 2016 - (03 Pipework)
Appliance Code: 41-019-32

Appliance Diagram


03 Pipework diagram for Glowworm Home 15r From 2015- 2016Click the diagram to open it on a new page

You can then pinch & zoom to adjust the size.

1 Part number 0020014176, Clip (PK10) CLIP (PK10)
Glowworm part no. 0020014176
£13.39
2 Part number 0020047027, Sensor, NTC SENSOR, NTC
Glowworm part no. 0020047027
£7.15
3 Part number 0020018487, O-ring (PK10) O-RING (PK10)
Glowworm part no. 0020018487
£7.77
4 Part number 0020203978, Elbow ELBOW
Glowworm part no. 0020203978
£7.42
5   SEALING RING 1/2 (PK10)
Glowworm part no. 0020160380
£7.15
6 Part number 0020195617, Tube TUBE
Glowworm part no. 0020195617
£28.72
7   GAS PIPE
Glowworm part no. 0020195618
£32.99
8   TUBE
Glowworm part no. 0020195619
£46.38
9 Part number S1045900, Screw M4x12 (PK10) SCREW M4X12 (PK10)
Glowworm part no. S1045900
£6.91
10 Part number 0020014719, Screw (PK25) SCREW (PK25)
Glowworm part no. 0020014719
£7.75
11 Part number 0020195571, Wiring harness, heat engine OV WIRING HARNESS, HEAT ENGINE OV
Glowworm part no. 0020195571
£23.80
12 Part number 0020211096, Gas valve GAS VALVE
Glowworm part no. 0020211096

13 Part number 0020211101, Gas pipe GAS PIPE
Glowworm part no. 0020211101
£13.12
14 Part number 0020044964, Gasket (PK10) GASKET (PK10)
Glowworm part no. 0020044964
£13.60
15   SEALING RING 1/2 (PK10)
Glowworm part no. 0020160380
£7.15
