GLOWWORM
ULTRACOM 2 35 STORE 2011 2015 - (09 Hydraulics)
Appliance Code: 47-019-15

Appliance Diagram


09 Hydraulics diagram for Glowworm Ultracom 2 35 Store 2011 2015Click the diagram to open it on a new page

You can then pinch & zoom to adjust the size.

1   HYDRAULIC TAPS (KIT) + CLIPS AND O-RINGS
Glowworm part no. 0020018590
£16.25
2 Part number 2000801951, NOW USE S5466200clip 10mm NOW USE S5466200CLIP 10MM
Glowworm part no. 2000801951

2 Part number S5466200, Clip 10mm (PK10) CLIP 10MM (PK10)
Glowworm part no. S5466200
£9.12
3 Part number 2000801950, O-ring for pipe (PK20) O-RING FOR PIPE (PK20)
Glowworm part no. 2000801950
£10.22
4 Part number A000024135, NOW USE S5720500 Pressure sensor d=10mm NOW USE S5720500 PRESSURE SENSOR D=10MM
Glowworm part no. A000024135

4 Part number S5720500, Pressure Sensor PRESSURE SENSOR
Glowworm part no. S5720500
£25.49
5 Part number 0020018569, NOW USE S1024500 automatic air vent NOW USE S1024500 AUTOMATIC AIR VENT
Glowworm part no. 0020018569

5 Part number S1024500, Automatic de-aerator AUTOMATIC DE-AERATOR
Glowworm part no. S1024500
£20.98
6 Part number 2000801954, NOW USE S5466500 o-ring (20 pieces) NOW USE S5466500 O-RING (20 PIECES)
Glowworm part no. 2000801954

6 Part number S5466500, O-ring (PK20) O-RING (PK20)
Glowworm part no. S5466500
£14.93
7 Part number 0020037988, Pump block PUMP BLOCK
Glowworm part no. 0020037988
£179.24
8 Part number 0020084525, NOW USE 0010034166 Motor pump NOW USE 0010034166 MOTOR PUMP
Glowworm part no. 0020084525

8   PUMP - HIGH EFFICENCY (IF THIS IF THE REPLACEMENT PART THEN CABLE 0010032765 IS REQUIRED)
Glowworm part no. 0010034166
£187.55
9 Part number 2000801945, NOW USE S5455000 clip cv-filter (set of 10) NOW USE S5455000 CLIP CV-FILTER (SET OF 10)
Glowworm part no. 2000801945

9 Part number S5455000, Clip 20mm (PK10) CLIP 20MM (PK10)
Glowworm part no. S5455000
£7.32
10 Part number 2000801956, O-ring (PK10) O-RING (PK10)
Glowworm part no. 2000801956
£8.94
11 Part number 0020097185, Screw (PK10) SCREW (PK10)
Glowworm part no. 0020097185
£6.23
12 Part number S1035900, Clip (pk10) CLIP (PK10)
Glowworm part no. S1035900
£6.03
13 Part number 2000801953, NOW USE S5466400 o-ring 13mm cv-filter (20 pieces) NOW USE S5466400 O-RING 13MM CV-FILTER (20 PIECES)
Glowworm part no. 2000801953

13 Part number S5466400, O-Ring (PK20) O-RING (PK20)
Glowworm part no. S5466400
£16.51
14 Part number S1024400, Heating filter HEATING FILTER
Glowworm part no. S1024400
£12.22
15 Part number 0020129830, DRAIN TAP DRAIN TAP
Glowworm part no. 0020129830
£6.03
16 Part number 0020111412, Pump PUMP
Glowworm part no. 0020111412
£250.23
17 Part number 0020129815, Housing of motor pump dcw HOUSING OF MOTOR PUMP DCW
Glowworm part no. 0020129815
£41.45
18   CLIP DOMESTIC HOT WATER SENSOR (PK10)
Glowworm part no. 0020022948
£5.66
18 Part number 0020018450, Clip (PK10) CLIP (PK10)
Glowworm part no. 0020018450
£31.22
19 Part number 2000801947, NOW USE S5465700 clip pressure relief valve NOW USE S5465700 CLIP PRESSURE RELIEF VALVE
Glowworm part no. 2000801947

19 Part number S5465700, Clip 18mm (PK10) CLIP 18MM (PK10)
Glowworm part no. S5465700
£10.20
20   NOW USE 2000801948 O RING (PK 20)
Glowworm part no. 0020038530

20 Part number 2000801948, O-ring, (PK20) O-RING, (PK20)
Glowworm part no. 2000801948
£11.37
21 Part number 0020125437, O-ring O-RING
Glowworm part no. 0020125437
£6.03
22   NON RETURN VALVE
Glowworm part no. 0020125436
£11.87
23 Part number 0020125439, O-ring (PK10) O-RING (PK10)
Glowworm part no. 0020125439
£6.03
