GLOWWORM
ULTRACOM 2 35 CXI 2010 - 2015 - (09 Hydraulics)
Appliance Code: 47-019-12

Appliance Diagram


09 Hydraulics diagram for Glowworm Ultracom 2 35 CXI 2010 - 2015Click the diagram to open it on a new page

You can then pinch & zoom to adjust the size.

1 Part number 0020097218, NOW USE 0010035668 HYDRAULIC BLOCK PUMP NOW USE 0010035668 HYDRAULIC BLOCK PUMP
Glowworm part no. 0020097218

1   PUMP - HIGH EFFICIENCY (REQUIRES CONVERSIOIN CABLE 0010032761)
Glowworm part no. 0010035668
£261.56
2 Part number 0020014169, bypass BYPASS
Glowworm part no. 0020014169
£31.19
3 Part number 0020097207, Sensor flow SENSOR FLOW
Glowworm part no. 0020097207
£34.44
4 Part number 0020097222, VALVE FOR 3WV VALVE FOR 3WV
Glowworm part no. 0020097222
£12.74
5 Part number 0020097220, NOW USE 0010035666 Motor pump NOW USE 0010035666 MOTOR PUMP
Glowworm part no. 0020097220

5 Part number 0010035666, PUMP, HIGH-EFFICIENCY (REQUIRES CONVERSION CABLE 0010032761) PUMP, HIGH-EFFICIENCY (REQUIRES CONVERSION CABLE 0010032761)
Glowworm part no. 0010035666
£226.03
7 Part number 0020097336, Tap drain piece TAP DRAIN PIECE
Glowworm part no. 0020097336
£6.39
8 Part number 2000801956, O-ring (PK10) O-RING (PK10)
Glowworm part no. 2000801956
£9.48
9 Part number 0020014176, Clip (PK10) CLIP (PK10)
Glowworm part no. 0020014176
£12.38
10 Part number 0020018569, NOW USE S1024500 automatic air vent NOW USE S1024500 AUTOMATIC AIR VENT
Glowworm part no. 0020018569

10 Part number S1024500, Automatic de-aerator AUTOMATIC DE-AERATOR
Glowworm part no. S1024500
£22.24
11 Part number 0020014182, Gasket Type-C (PK10) GASKET TYPE-C (PK10)
Glowworm part no. 0020014182
£10.61
11 Part number 2000801949, NOW USE 0020014182 gasket plate heat exchanger (20 pcs.) NOW USE 0020014182 GASKET PLATE HEAT EXCHANGER (20 PCS.)
Glowworm part no. 2000801949

12 Part number 0020038229, nut NUT
Glowworm part no. 0020038229
£6.61
13 Part number 0020097193, Screw M5x33 (PK10) SCREW M5X33 (PK10)
Glowworm part no. 0020097193
£6.74
14 Part number 0020097203, O-ring (PK10) O-RING (PK10)
Glowworm part no. 0020097203
£6.61
15 Part number A000024135, NOW USE S5720500 Pressure sensor d=10mm NOW USE S5720500 PRESSURE SENSOR D=10MM
Glowworm part no. A000024135

15 Part number S5720500, Pressure Sensor PRESSURE SENSOR
Glowworm part no. S5720500
£27.02
16   CLIP PACK 10
Glowworm part no. 0020097196
£5.36
16 Part number 0020097197, Clip (PK10) CLIP (PK10)
Glowworm part no. 0020097197
£7.14
17 Part number 0020014166, Gasket, C-Type, (PK10) GASKET, C-TYPE, (PK10)
Glowworm part no. 0020014166
£10.01
18 Part number 2000801948, O-ring, (PK20) O-RING, (PK20)
Glowworm part no. 2000801948
£12.05
20 Part number 0020097234, O-ring (PK10) O-RING (PK10)
Glowworm part no. 0020097234
£6.74
21   FILTER, FLOW SENSOR (PK10)
Glowworm part no. 0020097232
£63.14
21   NOW USE 0020097232 FILTER, FLOW SENSOR (PK10
Glowworm part no. 0020097233

22 Part number 0020097226, O-ring (PK10) O-RING (PK10)
Glowworm part no. 0020097226
£6.61
23 Part number 0020097224, O-ring (PK10) O-RING (PK10)
Glowworm part no. 0020097224
£6.61
24 Part number 0020097214, Diverter valve 3 way DIVERTER VALVE 3 WAY
Glowworm part no. 0020097214
£57.05
25 Part number 0020097185, Screw (PK10) SCREW (PK10)
Glowworm part no. 0020097185
£6.61
26 Part number A000035133, motor 3-way valve TM3HR MOTOR 3-WAY VALVE TM3HR
Glowworm part no. A000035133
£100.50
27 Part number 0020097228, Screw (PK10) SCREW (PK10)
Glowworm part no. 0020097228
£6.61
28 Part number 0020014164, Wire retaining clip (PK10) WIRE RETAINING CLIP (PK10)
Glowworm part no. 0020014164
£8.47
29 Part number 0020014195, O-ring (PK10) O-RING (PK10)
Glowworm part no. 0020014195
£6.61
