GLOWWORM
BG 330+ - (07 Electronics)
Appliance Code: 41-019-11

Appliance Diagram


07 Electronics diagram for Glowworm BG 330+Click the diagram to open it on a new page

You can then pinch & zoom to adjust the size.

26 Part number 0020020731, electrode ELECTRODE
Glowworm part no. 0020020731		 £16.41
39 Part number 0020020763, igniter IGNITER
Glowworm part no. 0020020763		 £29.39
41 Part number SK7959, Screw, M3x6mm SCREW, M3X6MM
Glowworm part no. SK7959		 £6.80
47 Part number 0020020774, Support (PK2) SUPPORT (PK2)
Glowworm part no. 0020020774		 £6.80
48   SCREW
Glowworm part no. 0020020776		 £6.80
49 Part number 0020020780, cable tree (zig harness) CABLE TREE (ZIG HARNESS)
Glowworm part no. 0020020780		 £15.25
50 Part number S5739800, Temperature sensor TEMPERATURE SENSOR
Glowworm part no. S5739800		 £23.87
50 Part number 0020020781, NOW USE S5739800 temperature monitor NOW USE S5739800 TEMPERATURE MONITOR
Glowworm part no. 0020020781
50 Part number 2000801935, NOW USE S5739800 ntc with clip d=18mm 10kOhm NOW USE S5739800 NTC WITH CLIP D=18MM 10KOHM
Glowworm part no. 2000801935
51 Part number 0020020783, cable (ignition lead assembly) CABLE (IGNITION LEAD ASSEMBLY)
Glowworm part no. 0020020783		 £45.59
53 Part number 0020058973, Casing (Front Part) CASING (FRONT PART)
Glowworm part no. 0020058973		 £102.57
54   CASING (BACK PANEL)
Glowworm part no. 0020058976		 £17.52
55 Part number 0020025183, appliance interface harness APPLIANCE INTERFACE HARNESS
Glowworm part no. 0020025183		 £13.66
56 Part number 0020058975, Printed Circuit Board PRINTED CIRCUIT BOARD
Glowworm part no. 0020058975		 £262.86
57 Part number 0020058974, Display DISPLAY
Glowworm part no. 0020058974		 £171.98
75 Part number 0020079603, Fuse 2,0 A T2H (PK10) FUSE 2,0 A T2H (PK10)
Glowworm part no. 0020079603		 £14.51
75 Part number 0020026405, NOW USE 0020079603 fuse NOW USE 0020079603 FUSE
Glowworm part no. 0020026405
78 Part number 0020020778, Cable tree (combustion harness) CABLE TREE (COMBUSTION HARNESS)
Glowworm part no. 0020020778		 £30.32
79   CABLE TREE (HYDRAULIC HARNESS)
Glowworm part no. 0020020786		 £9.02
81 Part number 0020061283, Gasket GASKET
Glowworm part no. 0020061283		 £7.01
87 Part number 0020061286, Housing HOUSING
Glowworm part no. 0020061286		 £89.29
88 Part number 0020041108, housing HOUSING
Glowworm part no. 0020041108		 £23.85
89 Part number 0020038263, fitting FITTING
Glowworm part no. 0020038263		 £6.80
112   SPRING CATCH (X15)
Glowworm part no. 2000802020		 £17.39
113   COVER
Glowworm part no. 0020061288		 £10.64
114   DAMPER
Glowworm part no. 0020061284		 £12.08
115 Part number 0020038260, Gasket GASKET
Glowworm part no. 0020038260		 £19.11
