REMEHA-COMMERCIAL
GAS 2000 H/L & ECO - (Exploded View)
Appliance Code: Gas 2000 H/L & Eco

Appliance Diagram


Exploded View diagram for Remeha-Commercial Gas 2000 H/L & EcoClick the diagram to open it on a new page

You can then pinch & zoom to adjust the size.

Part number 1035, (USE S103279) Pressure test nipple 1/8 (USE S103279) PRESSURE TEST NIPPLE 1/8
Remeha-Broag part no. 1035

  (USE S25944) CLEANING BRUSH ECO
Remeha-Broag part no. 25944

Part number 41617, Gasket for electrode GASKET FOR ELECTRODE
Remeha-Commercial part no. 41617
£0.50
  FAN CONNECTOR SUCTION SIDE 12 TO 16 SECTION
Remeha-Commercial part no. 42978
£98.07
  FAN CONNECTOR SUCTION SIDE 20 SECTION
Remeha-Commercial part no. 42979
£98.07
  GASKET 44X33X2MM
Remeha-Commercial part no. 46046
£2.88
  CABLE SET FOR INSTRUMENT PANEL H/L
Remeha-Commercial part no. 50330
£132.02
  CLEANING BRUSH BOILER BLOCK
Remeha-Commercial part no. 50707
£10.15
  (USE S51738) FUSE 4 AMP AUTOMATIC
Remeha-Broag part no. 51738

  CLEANING BRUSH ECO
Remeha-Commercial part no. S25944
£36.90
Part number S38558, Module TEM 1 ztr with thermostat MODULE TEM 1 ZTR WITH THERMOSTAT
Remeha-Commercial part no. S38558
£334.46
  MODULE TEM CONTROL PANEL TRANSPARENT DOOR
Remeha-Commercial part no. S41380
£27.66
  DISTRIBUTION PIPE
Remeha-Commercial part no. S43623
£23.89
  (DISCONTINUED) PIPE GAS PRESSURE SWITCH TO MIXING CHAMBER
Remeha-Broag part no. S43624
£10.62
  (DISCONTINUED) PIPE GAS PRESSURE SWITCH TO DISTRIBUTION CHAMBER
Remeha-Broag part no. S43625
£15.43
  PIPE GAS BLOCK TO MIXING CHAMBER
Remeha-Commercial part no. S43626
£26.40
  PIPE GAS BLOCK TO MIXING CHAMBER
Remeha-Commercial part no. S43627
£28.92
  PIPE GAS BLOCK TO DISTRIBUTION CHAMBER
Remeha-Commercial part no. S43628
£40.36
  PIPE GAS BLOCK TO DISTRIBUTION
Remeha-Commercial part no. S43629
£40.36
Part number S44493, Female Nylon Catch (10 pc FEMALE NYLON CATCH (10 PC
Remeha-Commercial part no. S44493
£17.74
Part number S44494, Mail Nylon Catch (10 pc MAIL NYLON CATCH (10 PC
Remeha-Commercial part no. S44494
£20.58
Part number S50422, Filter mains power nfb110rs FILTER MAINS POWER NFB110RS
Remeha-Commercial part no. S50422
£51.51
Part number S50525, Ignition Cable c/w spark plug (for Gas 450/2000/3002/6002) L=1000mm IGNITION CABLE C/W SPARK PLUG (FOR GAS 450/2000/3002/6002) L=1000MM
Remeha-Commercial part no. S50525
£66.64
  AUTOMATIC FUSE 4AMP
Remeha-Commercial part no. S51738
£54.35
  MINIATURE CIRCUIT BREAKER 6A FOR DIN RAIL MOUNTING
Remeha-Commercial part no. S51739
£129.29
  RETURN WATER DISTRIBUTION PIPE
Remeha-Commercial part no. S53384
£53.44
  RETURN WATER DISTRIBUTION PIPE
Remeha-Commercial part no. S53385
£57.84
  ECONOMISER BLOCK C/W GASKETS 12 SECTIONS
Remeha-Commercial part no. S54401
£5,250.74
  ECONOMISER BLOCK C/W GASKETS 16 SECTIONS
Remeha-Commercial part no. S54402
£5,387.79
  ECONOMISER BLOCK C/W GASKETS 20 SECTIONS
Remeha-Commercial part no. S54403
£5,879.42
1   FAN 12 TO 16 SECTION
Remeha-Commercial part no. S42976
£2,267.02
1   FAN 20 SECTION
Remeha-Commercial part no. S42977
£2,497.12
2 Part number 42988, FAN Gasket fan NRV 158x100x102mm FAN GASKET FAN NRV 158X100X102MM
Remeha-Commercial part no. 42988
£16.19
3   BURNER HOLDER 12 SECTION
Remeha-Commercial part no. S43068
£738.07
3   BURNER HOLDER 16 SECTION
Remeha-Commercial part no. S43069
£841.17
3 Part number S43070, Burner holder 20 section BURNER HOLDER 20 SECTION
Remeha-Commercial part no. S43070
£877.64
3   BURNER HOLDER 12 SECTION
Remeha-Commercial part no. S52955
£721.72
3   BURNER HOLDER 16 SECTION NOW P/N S58676 OR S58679 DEPENDING OF YEAR OF BOILER
Remeha-Broag part no. S52956

3   BURNER HOLDER 20 SECTION NOW P/N S58677
Remeha-Broag part no. S52957

3   BURNER HOLDER ASSY GAS 2000-16 (FOR BOILER FEB 93 TO AUG 95 ONLY)
Remeha-Commercial part no. S58676
£1,995.43
3   BURNER HOLDER ASSY GAS 2000-20 (FOR BOILER MANUFACTURED UP TO AUG 1995)
Remeha-Commercial part no. S58677
£1,942.62
4 Part number S53994, Valve multi block kroms. 1-¥" VALVE MULTI BLOCK KROMS. 1-¥"
Remeha-Commercial part no. S53994
£1,698.69
5   GASKET 38X27X02MM(GAS VALVE UNION) - (PACK OF 10)
Remeha-Commercial part no. S17509
£20.58
6   INJECTOR MAIN D=4.90 -¥" 12 SECTION
Remeha-Commercial part no. 42901
£98.07
6   INJECTOR MAIN D=5.60 -¥" 16 SECTION
Remeha-Commercial part no. 42902
£141.09
6   INJECTOR MAIN D=7.20 -¥" 20 SECTION
Remeha-Commercial part no. 42903
£110.70
7 Part number 46947, (NOW USE S100303) Gasket 155x104x3mm (NOW USE S100303) GASKET 155X104X3MM
Remeha-Broag part no. 46947

7 Part number S100303, Gasket Set GASKET SET
Remeha-Commercial part no. S100303
£20.58
8 Part number S45053, Non return valve nw 100 NON RETURN VALVE NW 100
Remeha-Commercial part no. S45053
£44.14
9 Part number 46946, (NOW USE S100302) Gasket 155x112x4mm (NOW USE S100302) GASKET 155X112X4MM
Remeha-Broag part no. 46946

9 Part number S100302, Gasket Set GASKET SET
Remeha-Commercial part no. S100302
£20.58
10 Part number S30153, Cap brown ionisation CAP BROWN IONISATION
Remeha-Commercial part no. S30153
£24.13
11 Part number S52735, Electrode Ionisation ELECTRODE IONISATION
Remeha-Commercial part no. S52735

12 Part number 4396, Cap black M4 threaded pin CAP BLACK M4 THREADED PIN
Remeha-Commercial part no. 4396
£13.08
13 Part number S52265, Electrode Ignition - G2000/3000/3002/6000/6002 ELECTRODE IGNITION - G2000/3000/3002/6000/6002
Remeha-Commercial part no. S52265

14 Part number 23607, (USE S100291) Seal neoprene strip 20x06mm (sold per mtr) (USE S100291) SEAL NEOPRENE STRIP 20X06MM (SOLD PER MTR)
Remeha-Broag part no. 23607

14 Part number s100291, Neoprene gasket strip 20x6 mm (10m) NEOPRENE GASKET STRIP 20X6 MM (10M)
Remeha-Commercial part no. s100291
£38.33
15   BURNER PREMIX ASSEMBLY 12 SECTION
Remeha-Commercial part no. S44753
£2,016.81
15 Part number S44754, Burner premix assembly 16 section BURNER PREMIX ASSEMBLY 16 SECTION
Remeha-Commercial part no. S44754
£2,387.73
15 Part number S44755, Burner premix assembly 20 section BURNER PREMIX ASSEMBLY 20 SECTION
Remeha-Commercial part no. S44755
£3,375.19
16 Part number 44530, Gasket tape tapa 12mm (REPLACED BY S100299) GASKET TAPE TAPA 12MM (REPLACED BY S100299)
Remeha-Broag part no. 44530

16 Part number S100299, Silicone Gasket Strip 15x5mm (10M) SILICONE GASKET STRIP 15X5MM (10M)
Remeha-Commercial part no. S100299
£342.06
17   GASKET 57X42X1.5MM (FLOW/RETURN UNION)
Remeha-Commercial part no. 7239
£6.28
18 Part number 57341, (DISCONTINUED) (USE S100300) Seal tapa cord 12/15 mm (sold per mtr) (DISCONTINUED) (USE S100300) SEAL TAPA CORD 12/15 MM (SOLD PER MTR)
Remeha-Broag part no. 57341

18 Part number S100300, Tapa cord 15mm (5m) TAPA CORD 15MM (5M)
Remeha-Commercial part no. S100300
£94.10
19 Part number S42391, Water pressure switch beck WATER PRESSURE SWITCH BECK
Remeha-Commercial part no. S42391
£92.42
20   DRAIN COCK
Remeha-Commercial part no. 1389
£61.75
20   DRAIN OFF COCK HANDLE
Remeha-Broag part no. 8993
£4.24
21   BOILER BLOCK 12 SECTIONS H/L ECO
Remeha-Commercial part no. 47908
£2,532.32
21   BOILER BLOCK 16 SECTIONS H/L ECO
Remeha-Commercial part no. 47909
£3,189.92
21   BOILER BLOCK 20 SECTIONS H/L ECO
Remeha-Commercial part no. 47910
£3,832.43
21   BOILER BLOCK 12 SECTIONS H/L AFTER 06/
Remeha-Commercial part no. 53077
£2,270.79
21   BOILER BLOCK 16 SECTIONS H/L AFTER 06/
Remeha-Commercial part no. 53078
£2,914.56
21   BOILER BLOCK 20 SECTIONS H/L AFTER 06/
Remeha-Commercial part no. 53079
£3,572.16
21   BOILER BLOCK 12 SECTION H/L PRE 06-95 STD
Remeha-Commercial part no. 54456
£2,090.99
21   BOILER BLOCK 16 SECTION H/L PRE 06-95 STD
Remeha-Commercial part no. 54457
£3,083.05
21   BOILER BLOCK 20 SECTION H/L PRE 06-95 STD
Remeha-Commercial part no. 54458
£3,696.64
22 Part number S57261, Air press differential switch AIR PRESS DIFFERENTIAL SWITCH
Remeha-Commercial part no. S57261
£430.05
23   OVERLOAD FOR FAN MOTOR
Remeha-Commercial part no. S47154
£121.08
24 Part number S48130, Transformer tr184.79 Serie 1102 230v 50Hz 105/115v TRANSFORMER TR184.79 SERIE 1102 230V 50HZ 105/115V
Remeha-Commercial part no. S48130
£195.88
25 Part number S32354, Relay failure ca2-kn22p7 RELAY FAILURE CA2-KN22P7
Remeha-Commercial part no. S32354
£140.82
26 Part number S43328, Relay mzpa002.96 220v-5a RELAY MZPA002.96 220V-5A
Remeha-Commercial part no. S43328
£54.70
29 Part number S45717, Control box Encon furimat 160 (H/L) CONTROL BOX ENCON FURIMAT 160 (H/L)
Remeha-Commercial part no. S45717
£2,370.29
30 Part number S43316, Pocket 1" L=160 POCKET 1" L=160
Remeha-Commercial part no. S43316
£640.13
31 Part number S46634, Thermostat control & H/L 35-95 degrees THERMOSTAT CONTROL & H/L 35-95 DEGREES
Remeha-Commercial part no. S46634
£47.13
32 Part number S36446, Thermostat TEM high limit 110 C l&g rak 77.4471 THERMOSTAT TEM HIGH LIMIT 110 C L&G RAK 77.4471
Remeha-Commercial part no. S36446
£92.69
33 Part number S38478, Thermometer TEM water temperature 0-120 Vertical Style THERMOMETER TEM WATER TEMPERATURE 0-120 VERTICAL STYLE
Remeha-Commercial part no. S38478
£198.71
34 Part number S38476, Switch on/off + lamp SWITCH ON/OFF + LAMP
Remeha-Commercial part no. S38476
£31.43
35   PUMP SWITCH
Remeha-Commercial part no. S38477
£49.54
36   HOUR RUN METER TEM (FWZ 36-I)
Remeha-Commercial part no. S38474
£183.57
37   TEM HOUSING MODULE 1 ZTR 4311 (FOR ON/OFF CONTROL STAT)
Remeha-Commercial part no. S41381
£32.65
38   (DISCONTINUED) TEM HOUSING MODULE 2 ZTR 4301 (FOR H/L CONTROL STAT)
Remeha-Broag part no. S41382
£11.58
39   TEM HOUSING MODULE 3 ZSI 4301 (FOR HIGH LIMIT STAT)
Remeha-Commercial part no. S41383
£21.38
40   TEM HOUSING MODULE 4 ZTA 4308 (FOR WATER TEMP THERMOMETER)
Remeha-Broag part no. S41384
£13.51
41 Part number S37628, NEW PART NUMBER S62728 Vent auto air bleed device 3/8" for W40/60, Quinta, Gas6, Gas2000/3000, Selecta NEW PART NUMBER S62728 VENT AUTO AIR BLEED DEVICE 3/8" FOR W40/60, QUINTA, GAS6, GAS2000/3000, SELECTA
Remeha-Broag part no. S37628

41 Part number S62728, Auto Air Vent bleed device 3/8" AUTO AIR VENT BLEED DEVICE 3/8"
Remeha-Commercial part no. S62728
£44.14
42 Part number S51417, Gasket Strip Front Plate ECO (5metre pre cut lengths) GASKET STRIP FRONT PLATE ECO (5METRE PRE CUT LENGTHS)
Remeha-Commercial part no. S51417
£194.45
43 Part number 25162, Syphon Adapter 1"x32x40 SYPHON ADAPTER 1"X32X40
Remeha-Commercial part no. 25162
£17.74
43   SYPHON ELBOW 90 DEGR. 32X1,9
Remeha-Commercial part no. 30537
£4.20
43 Part number S24494, Syphon assembly SYPHON ASSEMBLY
Remeha-Commercial part no. S24494
£55.93
