REMEHA-COMMERCIAL
W40/60 1:1 RATIO HIGH / LOW - (Exploded View)
Appliance Code: W40/60

Appliance Diagram


Exploded View diagram for Remeha-Commercial W40/60 1:1 Ratio High / LowClick the diagram to open it on a new page

You can then pinch & zoom to adjust the size.

  FAN CONNECTION PIECE (BURNER TO FAN) W40/60 1:1 H/L ONLY
Remeha-Commercial part no. 46025		 £31.43
Part number 54498, Hinge HINGE
Remeha-Broag part no. 54498		 £37.62
Part number S45926, Flue connection plate (twin pipe 100mm) for W40/60 FLUE CONNECTION PLATE (TWIN PIPE 100MM) FOR W40/60
Remeha-Commercial part no. S45926		 £258.33
Part number S47170, Hose Silicone D:4Mm I/D-8Mm (1 Meter) HOSE SILICONE D:4MM I/D-8MM (1 METER)
Remeha-Commercial part no. S47170		 £21.98
Part number S47929, Transformer tr 182.96 230/24v TRANSFORMER TR 182.96 230/24V
Remeha-Commercial part no. S47929		 £301.32
Part number S54051, Set fixing strips for inspection cover W40 (L=444) SET FIXING STRIPS FOR INSPECTION COVER W40 (L=444)
Remeha-Commercial part no. S54051		 £76.82
Part number S54052, Set fixing strips for inspection cover W60 (L=672) (PK 5) SET FIXING STRIPS FOR INSPECTION COVER W60 (L=672) (PK 5)
Remeha-Commercial part no. S54052		 £179.80
Part number 47170, NOW USE S47170 Hose silicone 4mm I/d-8mm per M for gas valve venturi & air vent discharge NOW USE S47170 HOSE SILICONE 4MM I/D-8MM PER M FOR GAS VALVE VENTURI & AIR VENT DISCHARGE
Remeha-Broag part no. 47170
1 Part number S41671, Sealing Spigot D (100mm D:) SEALING SPIGOT D (100MM D:)
Remeha-Commercial part no. S41671		 £17.74
1 Part number 41671, (USE S41671)Sealing ring D=100mm for fluegas (USE S41671)SEALING RING D=100MM FOR FLUEGAS
Remeha-Broag part no. 41671
2 Part number S45772, Air press differential switch AIR PRESS DIFFERENTIAL SWITCH
Remeha-Commercial part no. S45772		 £207.77
3   INJECTOR D=11.75MM 60KW
Remeha-Commercial part no. S45873		 £23.89
3   INJECTOR D=8.2MM
Remeha-Commercial part no. S46404		 £84.62
4 Part number S45174, Valve multi block VR8615VA1012B VALVE MULTI BLOCK VR8615VA1012B
Remeha-Commercial part no. S45174		 £397.31
4 Part number S45924, Valve multi block VALVE MULTI BLOCK
Remeha-Commercial part no. S45924		 £494.14
5 Part number S103212, Fan assembly EBM G1G 126 AC 13 Q30/W40/Selecta c/w X21 connector FAN ASSEMBLY EBM G1G 126 AC 13 Q30/W40/SELECTA C/W X21 CONNECTOR
Remeha-Commercial part no. S103212		 £281.88
5 Part number S46631, Fan 40kW 1: 9 Ratio only EBM G1G 126/45 (NOT FOR W40 H/L OR M ECO BOILERS) FAN 40KW 1: 9 RATIO ONLY EBM G1G 126/45 (NOT FOR W40 H/L OR M ECO BOILERS)
Remeha-Commercial part no. S46631		 £608.72
5 Part number S44644, Fan 60kW EBM G1G 144 FAN 60KW EBM G1G 144
Remeha-Commercial part no. S44644
5 Part number S54878, NOW USE S103212 Fan assembly EBM G1G 126 AC 13 Q30/W40/Selecta c/w X21 connector NOW USE S103212 FAN ASSEMBLY EBM G1G 126 AC 13 Q30/W40/SELECTA C/W X21 CONNECTOR
Remeha-Broag part no. S54878
6 Part number S45182, Gasket for flue fan (10 pcs.) GASKET FOR FLUE FAN (10 PCS.)
Remeha-Commercial part no. S45182
7 Part number S45895, O-Ring 73x1.8mm (10 pcs) O-RING 73X1.8MM (10 PCS)
Remeha-Commercial part no. S45895		 £35.49
8 Part number S46746, Seal burner deck cord (2 pieces) 60kW SEAL BURNER DECK CORD (2 PIECES) 60KW
Remeha-Commercial part no. S46746		 £75.23
9 Part number S46199, Burner Deck 60kW BURNER DECK 60KW
Remeha-Commercial part no. S46199		 £615.99
9 Part number S51503, Burner deck 40kW (not 1:9) BURNER DECK 40KW (NOT 1:9)
Remeha-Commercial part no. S51503		 £722.44
10 Part number S41601, Air vent 1/8" AIR VENT 1/8"
Remeha-Commercial part no. S41601		 £62.29
10 Part number S44655, Burner assembly 60kW BURNER ASSEMBLY 60KW
Remeha-Commercial part no. S44655		 £2,913.90
10 Part number S51485, Burner assembly 40kW (not 1:9) BURNER ASSEMBLY 40KW (NOT 1:9)
Remeha-Commercial part no. S51485		 £1,870.95
10 Part number 44655, (USE S44655) Burner assembly 60kW (USE S44655) BURNER ASSEMBLY 60KW
Remeha-Broag part no. 44655
11 Part number S62728, Auto Air Vent bleed device 3/8" AUTO AIR VENT BLEED DEVICE 3/8"
Remeha-Commercial part no. S62728		 £50.58
11 Part number S37628, NEW PART NUMBER S62728 Vent auto air bleed device 3/8" for W40/60, Quinta, Gas6, Gas2000/3000, Selecta NEW PART NUMBER S62728 VENT AUTO AIR BLEED DEVICE 3/8" FOR W40/60, QUINTA, GAS6, GAS2000/3000, SELECTA
Remeha-Broag part no. S37628
11 Part number S37628, NEW PART NUMBER S62728 Vent auto air bleed device 3/8" for W40/60, Quinta, Gas6, Gas2000/3000, Selecta NEW PART NUMBER S62728 VENT AUTO AIR BLEED DEVICE 3/8" FOR W40/60, QUINTA, GAS6, GAS2000/3000, SELECTA
Remeha-Broag part no. S37628
12 Part number S56867, Heat Exchanger 40KW (Includes ALL seals and Insp Plate) HEAT EXCHANGER 40KW (INCLUDES ALL SEALS AND INSP PLATE)
Remeha-Commercial part no. S56867		 £3,332.00
12 Part number S56868, Heat exchanger 60kW HEAT EXCHANGER 60KW
Remeha-Commercial part no. S56868		 £3,603.59
13 Part number S44698, Temperature Sensor (flow And return) Elmwood NTC 12K/007 TEMPERATURE SENSOR (FLOW AND RETURN) ELMWOOD NTC 12K/007
Remeha-Commercial part no. S44698		 £43.92
14 Part number S56961, Cable set for fan and sensors (X16 - X2) CABLE SET FOR FAN AND SENSORS (X16 - X2)
Remeha-Commercial part no. S56961		 £49.96
14 Part number S55807, Cable ignition c/w cap CABLE IGNITION C/W CAP
Remeha-Commercial part no. S55807
15 Part number S30153, Cap brown ionisation CAP BROWN IONISATION
Remeha-Commercial part no. S30153		 £27.65
15 Part number S49574, Cap for flue gas measuring point CAP FOR FLUE GAS MEASURING POINT
Remeha-Commercial part no. S49574		 £13.39
16 Part number S45004, Glass inspection c/w gasket 32x32x3mm and screws GLASS INSPECTION C/W GASKET 32X32X3MM AND SCREWS
Remeha-Commercial part no. S45004		 £55.65
17 Part number S54338, W40/60 series Electrode Ignition/Ionisation crni inc Gasket W40/60 SERIES ELECTRODE IGNITION/IONISATION CRNI INC GASKET
Remeha-Commercial part no. S54338		 £43.92
18 Part number S41676, Seal black cord 12mm. (lower inspection hatch) SEAL BLACK CORD 12MM. (LOWER INSPECTION HATCH)
Remeha-Commercial part no. S41676		 £13.54
19 Part number S45836, Control unit gas module mcba 1460d (not for modulating) CONTROL UNIT GAS MODULE MCBA 1460D (NOT FOR MODULATING)
Remeha-Commercial part no. S45836		 £707.89
19 Part number S52061, Control unit mcba 1460d m CONTROL UNIT MCBA 1460D M
Remeha-Commercial part no. S52061		 £599.76
20 Part number S42754, PCB display PCB DISPLAY
Remeha-Commercial part no. S42754		 £98.07
21 Part number S6710, Gasket 044x032x2mm (pump union) GASKET 044X032X2MM (PUMP UNION)
Remeha-Commercial part no. S6710		 £14.74
23   SYPHON ELBOW 90 DEGR. 32X1,9
Remeha-Commercial part no. 30537		 £4.20
23 Part number S45885, Syphon Assembly - W40/60 SYPHON ASSEMBLY - W40/60
Remeha-Commercial part no. S45885		 £92.69
23 Part number 45885, (REPLACED BY S45885) Syphon assembly (REPLACED BY S45885) SYPHON ASSEMBLY
Remeha-Broag part no. 45885
24 Part number S43561, Fuses glass 2 Amp Slow Pack of 10 FUSES GLASS 2 AMP SLOW PACK OF 10
Remeha-Commercial part no. S43561		 £35.79
24 Part number S43562, Fuses glass 3.15 Amp Slow Pack of 10 FUSES GLASS 3.15 AMP SLOW PACK OF 10
Remeha-Commercial part no. S43562		 £50.17
24 Part number S43563, Fuses glass 2 Amp fast Pack of 10 FUSES GLASS 2 AMP FAST PACK OF 10
Remeha-Commercial part no. S43563		 £26.03
24 Part number S44493, Female Nylon Catch (10 pc FEMALE NYLON CATCH (10 PC
Remeha-Commercial part no. S44493		 £17.74
24 Part number S44494, Mail Nylon Catch (10 pc MAIL NYLON CATCH (10 PC
Remeha-Commercial part no. S44494		 £20.58
25 Part number S45884, Gas pressure switch GAS PRESSURE SWITCH
Remeha-Commercial part no. S45884		 £92.42
26   PUMP CABLE ASSEMBLY L=450
Remeha-Commercial part no. 37753		 £15.72
27 Part number 33232, OBSOLETE Drain cock 1/2" OBSOLETE DRAIN COCK 1/2"
Remeha-Broag part no. 33232
28 Part number S36489, Pressure gauge 1/8" PRESSURE GAUGE 1/8"
Remeha-Commercial part no. S36489		 £26.96
29 Part number S41673, Inspection Plate W40 (1:1 & 1:9) INSPECTION PLATE W40 (1:1 & 1:9)
Remeha-Commercial part no. S41673		 £183.47
29 Part number S43438, Inspection Hatch 60KW INSPECTION HATCH 60KW
Remeha-Commercial part no. S43438		 £178.61
29 Part number 41673, NOW USE S41673 Inspection hatch 40kW NOW USE S41673 INSPECTION HATCH 40KW
Remeha-Broag part no. 41673
29 Part number 43438, Inspection hatch 60kW (USE S43438) INSPECTION HATCH 60KW (USE S43438)
Remeha-Broag part no. 43438
30 Part number S53144, Seal for inspection hatch 40kw SEAL FOR INSPECTION HATCH 40KW
Remeha-Commercial part no. S53144		 £50.58
30 Part number S53145, Seal for inspection hatch 60kw SEAL FOR INSPECTION HATCH 60KW
Remeha-Commercial part no. S53145		 £47.13
31   CASING RIGHT SIDE
Remeha-Commercial part no. 45178		 £78.08
32   CASING LEFT SIDE
Remeha-Commercial part no. 45177		 £78.08
33   CASING FRONT WHITE W40
Remeha-Commercial part no. 49044		 £80.72
33   CASING FRONT WHITE W60
Remeha-Commercial part no. 49045		 £86.01
34   SLEEVE FRONT CASING
Remeha-Commercial part no. 50811		 £8.99
37 Part number S49297, Flue gas temp. sensor NTC 12kohm 3% (blue dot-Eco boiler) FLUE GAS TEMP. SENSOR NTC 12KOHM 3% (BLUE DOT-ECO BOILER)
Remeha-Commercial part no. S49297		 £35.79
40 Part number S53282, Switch On/Off 40c1350al with cap SWITCH ON/OFF 40C1350AL WITH CAP
Remeha-Commercial part no. S53282		 £33.36
