IDEAL
C32 COMBI - (Boiler Exploded View)
Appliance Code: 47-348-98

Appliance Diagram


Boiler Exploded View diagram for Ideal C32 CombiClick the diagram to open it on a new page

You can then pinch & zoom to adjust the size.

104   RETURN VALVE PACK VOGUE
Ideal part no. 176826		 £27,25
105 Part number 176827, FLOW VALVE PACK VOGUE FLOW VALVE PACK VOGUE
Ideal part no. 176827		 £27,04
106 Part number 176825, DHW PACK VOGUE COMBI DHW PACK VOGUE COMBI
Ideal part no. 176825		 £28,54
107 Part number 176671, FILLING LOOP PACK(AAC ONLY) FILLING LOOP PACK(AAC ONLY)
Ideal part no. 176671		 £47,40
108 Part number 176857, PUMP HEAD KIT PUMP HEAD KIT
Ideal part no. 176857		 £447,36
111 Part number 174813, DIVERTER VALVE HEAD DIVERTER VALVE HEAD
Ideal part no. 174813		 £55,20
112 Part number 176863, DIVERTER VALVE CARTRIDGE DIVERTER VALVE CARTRIDGE
Ideal part no. 176863		 £74,33
113 Part number 175413, PRESSURE RELIEF VALVE KIT (AAC & AAB ONLY) PRESSURE RELIEF VALVE KIT (AAC & AAB ONLY)
Ideal part no. 175413		 £16,43
114 Part number 175545, PIPE - PRV OUTLET (AAC & AAB ONLY) PIPE - PRV OUTLET (AAC & AAB ONLY)
Ideal part no. 175545		 £18,16
115   PIPE FLOW - C26-32- S15-18-26
Ideal part no. 176860		 £32,47
116   PIPE RETURN - C26-32-40- S18-26-32
Ideal part no. 176861		 £35,09
117 Part number 176864, PIPE - EXPANSION VESSEL PIPE - EXPANSION VESSEL
Ideal part no. 176864		 £25,99
118 Part number 176865, EXPANSION VESSEL KIT EXPANSION VESSEL KIT
Ideal part no. 176865		 £101,69
119 Part number 175552, RETURN GROUP KIT (MANIFOLD ONLY AAC ONLY) RETURN GROUP KIT (MANIFOLD ONLY AAC ONLY)
Ideal part no. 175552		 £101,36
120 Part number 176867, FLOW GROUP KIT - COMBI FLOW GROUP KIT - COMBI
Ideal part no. 176867		 £356,17
121 Part number 176546, PLATE HEAT EXCHANGER KIT 35KW PLATE HEAT EXCHANGER KIT 35KW
Ideal part no. 176546		 £90,43
123 Part number 175590, FLOW SENSOR HALL EFFECT FLOW SENSOR HALL EFFECT
Ideal part no. 175590		 £12,86
124 Part number 176875, FLOW TURBINE 32KW - REF 10.0574 FLOW TURBINE 32KW - REF 10.0574
Ideal part no. 176875		 £56,76
125 Part number 175596, WATER PRESSURE TRANSDUCER (PRE ABU) WATER PRESSURE TRANSDUCER (PRE ABU)
Ideal part no. 175596		 £31,32
127 Part number 176880, PRESSURE GAUGE PRESSURE GAUGE
Ideal part no. 176880		 £29,64
203   PIPE - GAS INLET - C32-40- S26-32
Ideal part no. 176886		 £30,66
204 Part number 176887, GAS VALVE KIT GAS VALVE KIT
Ideal part no. 176887		 £195,13
205   INJECTOR KIT DIAMETER 5.15
Ideal part no. 176888		 £22,57
205   INJECTOR KIT DIAMETER 4.4
Ideal part no. 176889		 £22,57
205   INJECTOR KIT DIAMETER 4.3
Ideal part no. 176890		 £21,50
207   VENTURI KIT C26-C32-S26
Ideal part no. 176895		 £51,47
208 Part number 176898, FAN KIT FAN KIT
Ideal part no. 176898		 £223,68
209   GASKET FAN
Ideal part no. 176899		 £19,29
210   FAN ADAPTER KIT
Ideal part no. 176900		 £34,92
211   VENTURI DEFLECTOR
Ideal part no. 176901		 £12,36
212 Part number 176902, CONDENSATE HOSE CONDENSATE HOSE
Ideal part no. 176902		 £18,54
213 Part number 175983, CLAMP RETAINING FLUE TURRET (COMBI ZY ONWARDS - COMBI ES AAQ ONWARDS) CLAMP RETAINING FLUE TURRET (COMBI ZY ONWARDS - COMBI ES AAQ ONWARDS)
Ideal part no. 175983		 £7,10
214 Part number 175583, SIPHON TRAP KIT SIPHON TRAP KIT
Ideal part no. 175583		 £23,10
217 Part number 176824, GAS COCK VALVE PACK VOGUE GAS COCK VALVE PACK VOGUE
Ideal part no. 176824		 £31,33
218   FLUE MANIFOLD
Ideal part no. 176918		 £42,76
219 Part number 176919, FLUE MANIFOLD SEAL FLUE MANIFOLD SEAL
Ideal part no. 176919		 £12,29
220   FAN ADAPTER SEAL
Ideal part no. 176920		 £14,04
302 Part number 176916, PRIMARY PCB (A BCC CARD MUST BE PURCHASED WITH THIS ITEM) PRIMARY PCB (A BCC CARD MUST BE PURCHASED WITH THIS ITEM)
Ideal part no. 176916		 £238,76
303 Part number 176917, CUI BOARD CUI BOARD
Ideal part no. 176917		 £261,15
304 Part number 175589, CONTROL THERMISTOR (FLOW/RETURN) pack of 2- Withdrawn : 16/01/2017 CONTROL THERMISTOR (FLOW/RETURN) PACK OF 2- WITHDRAWN : 16/01/2017
Ideal part no. 175589
304 Part number 176432, CONTROL THERMISTOR CONTROL THERMISTOR
Ideal part no. 176432		 £10,53
306 Part number 176913, ELECTRODE IGNITION(C/W GASKET & SCREWS) ELECTRODE IGNITION(C/W GASKET & SCREWS)
Ideal part no. 176913		 £37,52
307 Part number 176914, ELECTRODE DETECTION(C/W GASKET & SCREWS) ELECTRODE DETECTION(C/W GASKET & SCREWS)
Ideal part no. 176914		 £34,47
308   INJECTORS FOR LPG MINI HE (BI1003 509)
Ideal part no. 173982		 £26,67
317   CONTROL BOX FRONT KIT - COMBI
Ideal part no. 177077		 £50,23
318   CONTROL BOX LID KIT
Ideal part no. 176915		 £19,00
319 Part number 176928, PROGRAMMER BLANK INSERT PROGRAMMER BLANK INSERT
Ideal part no. 176928		 £11,99
321 Part number 176969, HINGES & FIXING KIT HINGES & FIXING KIT
Ideal part no. 176969		 £16,42
401   HEAT ENGINE 4 COIL
Ideal part no. 176907		 £753,87
403 Part number 176966, BURNER GASKET KIT BURNER GASKET KIT
Ideal part no. 176966		 £17,70
404   COLD BURNER DOOR ASSEMBLY - 3+1
Ideal part no. 176962		 £400,47
404   COLD BURNER DOOR ASSEMBLY - 5+1
Ideal part no. 176964		 £573,06
501 Part number 176968, FRONT PANEL DOOR KIT COMBI FRONT PANEL DOOR KIT COMBI
Ideal part no. 176968		 £223,33
503 Part number 175619, WALL MOUNTING BRACKET KIT WALL MOUNTING BRACKET KIT
Ideal part no. 175619		 £15,48
504   BRACKET - IGNITION
Ideal part no. 176971		 £12,66
