VALOR GAS FIRE
MODEL 860 ASHDOWN, CHESTER, EDEN, RICHMOND, SHAFTESBURY, VIENNA - (Ashdown And Richmond)
Appliance Code: EF-032-27

Appliance Diagram


Ashdown And Richmond diagram for Valor Gas Fire Model 860 Ashdown, Chester, Eden, Richmond, Shaftesbury, ViennaClick the diagram to open it on a new page

You can then pinch & zoom to adjust the size.

1   OBSOLETE DOOR HANGING PIN
Valor Gas Fire part no. 5118257

2   OBSOLETE DOOR SUPPORTS
Valor Gas Fire part no. 5121582

3   SCREW NO8 X 20
Valor Gas Fire part no. 5122480
4   OBSOLETE BACK PANEL BKTS
Valor Gas Fire part no. 5121566

5   SCREW
Valor Gas Fire part no. 0508109
6   OBSOLETE DOOR LH
Valor Gas Fire part no. 5121801

7   OBSOLETE LH STOVE DOOR - TYPE C
Valor Gas Fire part no. 5118027

8   OBSOLETE GLASS PANEL
Valor Gas Fire part no. 5118249

9   OBSOLETE GLASS RETAINER
Valor Gas Fire part no. 5121794

10   OBSOLETE SCREW
Valor Gas Fire part no. 5121800

11   OBSOLETE CUP WASHER
Valor Gas Fire part no. 5121799

12   OBSOLETE STOVE DOOR HANDLE - PART ONE
Valor Gas Fire part no. 5118032

13   OBSOLETE STOVE DOOR HANDLE - PART TWO
Valor Gas Fire part no. 5118033

14   OBSOLETE SCREW M4 X 12 CSK POZI
Valor Gas Fire part no. 5122482

15   OBSOLETE DOOR RH
Valor Gas Fire part no. 5121802

16   OBSOLETE RH STOVE DOOR - TYPE C
Valor Gas Fire part no. 5118028

17   OBSOLETE BACK PANEL
Valor Gas Fire part no. 5121565

18   OBSOLETE SET OF FEET
Valor Gas Fire part no. 5121564

19   OBSOLETE CHASSIS SUB ASSY
Valor Gas Fire part no. 5131255

20   OBSOLETE AIR OUTLET GRILLE
Valor Gas Fire part no. 5122562BN

21   8X3/8 S/DR C/BSCREW
Valor Gas Fire part no. 0513479
22   OBSOLETE RETAINING BAFFLE
Valor Gas Fire part no. 5121586AY

23   OBSOLETE SCREW NO8X3/8" AB POZI PAN HD
Valor Gas Fire part no. 5111426

24   MAINS LEAD
Valor Gas Fire part no. 5116941
25   OBSOLETE TANGENTIAL FAN
Valor Gas Fire part no. 5121724

27   OBSOLETE ELEMENT
Valor Gas Fire part no. 5116950

28   SPACER BRKTS
Valor Gas Fire part no. 5121516
29 Part number 0534629, SCREW SCREW
Valor Gas Fire part no. 0534629
30   MOTHERBOARD
Valor Gas Fire part no. 5121726
31   THERMISTOR
Valor Gas Fire part no. 5121848
32   PCB SUPPORT
Valor Gas Fire part no. 5122599
33   RECEIVER BOARD ATB08
Valor Gas Fire part no. 5121767
34   SWITCH BKT
Valor Gas Fire part no. 5121517
35   OBSOLETE INSULATION PAD
Valor Gas Fire part no. 5122600

36   NOW USE 082061 TIE LEAD
Valor Gas Fire part no. 0547699

36   TIE-CABLE-INSULOID LKO.
Valor Gas Fire part no. 082061
38   WIRING LOOM
Valor Gas Fire part no. 5121681
41   OBSOLETE FAN 30 X 250 50942
Valor Gas Fire part no. 5121583

42   OBSOLETE CHASSIS TOP PANEL
Valor Gas Fire part no. 5121512

44   LAMP HOLDER
Valor Gas Fire part no. 5113540
45   OBSOLETE BUSH THREADED
Valor Gas Fire part no. 5123057

46   OBSOLETE WASHER SERRATED
Valor Gas Fire part no. 5116980

48   OBSOLETE EFFECTS REFLECTOR
Valor Gas Fire part no. 5131209

49   RIBBON - TUMBLED
Valor Gas Fire part no. 5117137
50   OBSOLETE EFFECTS SCREEN
Valor Gas Fire part no. 5121508

51   OBSOLETE SCREEN SUPPORT
Valor Gas Fire part no. 5121509AY

52   OBSOLETE RIBBON SIDE BKT LH
Valor Gas Fire part no. 5121506

53   OBSOLETE RIBBON SIDE BKT RH
Valor Gas Fire part no. 5121507

55   OBSOLETE HEAT DEFLECTOR
Valor Gas Fire part no. 5121597AZ

56   OBSOLETE 60W BULB
Valor Gas Fire part no. 0571339

56   OBSOLETE LAMP 60W BAYONET CLEAR
Valor Gas Fire part no. 5121728

57   OBSOLETE COAL BED
Valor Gas Fire part no. 5121609

58   BATTERY SIZE AAA ATB08
Valor Gas Fire part no. 5114179
60   OBSOLETE SCRE NO8 X 15 PAN POZI
Valor Gas Fire part no. 5122483

72   COAL SET 1/2KG
Valor Gas Fire part no. 0570359

72 Part number 0576309, WASHED COALS 1KG WASHED COALS 1KG
Valor Gas Fire part no. 0576309
