WORCESTER
HEATSLAVE HE 18/25 INTERNAL(AUG 2005 ONWARDS) 7716100098 - (Secondary Heat Exchanger)
Appliance Code: 7716100098

Appliance Diagram


Secondary Heat Exchanger diagram for Worcester Heatslave HE 18/25 Internal(Aug 2005 Onwards) 7716100098Click the diagram to open it on a new page

You can then pinch & zoom to adjust the size.

  INSULATION SECONDARY TOP
Worcester part no. 87161089370		 £6.39
  INSULATION SECONDARY BOTTOM
Worcester part no. 87161089380		 £3.04
Part number 87161420010, TAPE AT500 SILVER 50MM X 5M TAPE AT500 SILVER 50MM X 5M
Worcester part no. 87161420010		 £9.32
1 Part number 87161075120, SECONDARY HEAT EXCHANGER FINAL ASSEMBLY BEFORE FD782 SECONDARY HEAT EXCHANGER FINAL ASSEMBLY BEFORE FD782
Worcester part no. 87161075120		 £410.07
1   SECONDARY HEAT EXCHANGER FINAL ASSEMBLY AFTER FD783
Worcester part no. 87161124300		 £1,046.89
2 Part number 87161104470, SCREW HEX Z M6 X 16 8.8 ZP BEFORE FD782 SCREW HEX Z M6 X 16 8.8 ZP BEFORE FD782
Worcester part no. 87161104470		 £3.83
2 Part number 87161130660, SCREW HEX Z M6 X 25 8.8 ZP AFTER FD783 SCREW HEX Z M6 X 25 8.8 ZP AFTER FD783
Worcester part no. 87161130660		 £2.86
3 Part number 87161405160, AIR VENT MANUAL 1/4 BSP AIR VENT MANUAL 1/4 BSP
Worcester part no. 87161405160		 £9.72
4 Part number 87161412190, BOILER DRAIN TUBE BOILER DRAIN TUBE
Worcester part no. 87161412190		 £6.23
5 Part number 87161081030, GASKET SECONDARY HEAT EXCHANGER BEFORE FD782 GASKET SECONDARY HEAT EXCHANGER BEFORE FD782
Worcester part no. 87161081030		 £45.17
5 Part number 87161129540, SEAL SHE 16 TUBES AFTER FD783 SEAL SHE 16 TUBES AFTER FD783
Worcester part no. 87161129540		 £72.61
6 Part number 87161081050, BAFFLE DOUBLE SECONDARY HEAT EXCHANGER BAFFLE DOUBLE SECONDARY HEAT EXCHANGER
Worcester part no. 87161081050		 £21.82
7 Part number 87161402380, AIR VENT 1/8 BSP AIR VENT 1/8 BSP
Worcester part no. 87161402380		 £16.23
8 Part number 87161409200, WASHER 30.5X22.2X1.5 WASHER 30.5X22.2X1.5
Worcester part no. 87161409200		 £2.66
9   PIPE CH RETURN
Worcester part no. 87161085030		 £13.39
10 Part number 87161402470, NUT CLAMPING G1 NUT CLAMPING G1
Worcester part no. 87161402470		 £5.35
11   PIPE FEMALE SECONDARY
Worcester part no. 87161085040		 £11.90
12 Part number 87161408260, O-RING 3.0 SEC X 21.5 I/D E.P. O-RING 3.0 SEC X 21.5 I/D E.P.
Worcester part no. 87161408260		 £2.67
13   PIPE MALE SECONDARY
Worcester part no. 87161085050		 £20.73
14   PIPE SECONDARY HT EX TO CHECK VALVE BEFORE FD991
Worcester part no. 87161087280		 £9.89
14   PIPE W-WHT EX TO ISO VALVE AFTER FD992
Worcester part no. 87186850660		 £34.82
16   BOLT RETAINER M6
Worcester part no. 87161075290		 £0.56
18   SEAL HEAT EXCHANGER BEFORE FD782
Worcester part no. 87161124900		 £53.51
18 Part number 87161129540, SEAL SHE 16 TUBES AFTER FD783 SEAL SHE 16 TUBES AFTER FD783
Worcester part no. 87161129540		 £72.61
