WORCESTER
CAMRAY 3 135/175 (DEC 1994 - DEC 2000) 7716139052 - (Heat Exchanger And Burner)
Appliance Code: 7716139052

Appliance Diagram


Heat Exchanger And Burner diagram for Worcester Camray 3 135/175 (Dec 1994 - Dec 2000) 7716139052Click the diagram to open it on a new page

You can then pinch & zoom to adjust the size.

Part number 87161109190, TIMER GRASSLIN TACTIC 111.2 TIMER GRASSLIN TACTIC 111.2
Worcester part no. 87161109190
2 Part number 87161096280, BOTTOM BAFFLE BOTTOM BAFFLE
Worcester part no. 87161096280		 £109.96
3 Part number 87161096220, MIDDLE BAFFLE MIDDLE BAFFLE
Worcester part no. 87161096220		 £51.68
4   TOP BAFFLE ASSEMBLY CAM 3 135/175
Worcester part no. 87161096200		 £18.02
5   COMBUSTION CHAMBER BASE INSULATION
Worcester part no. 87161076030		 £21.20
6   INSPECTION COVER COMPLETE
Worcester part no. 87161075570		 £20.39
7 Part number 87161078720, CONTROL THERMOSTAT (RANCO) CONTROL THERMOSTAT (RANCO)
Worcester part no. 87161078720		 £22.26
8 Part number 87161078710, MANUAL RESET LIMIT THERMOSTAT (RANCO) MANUAL RESET LIMIT THERMOSTAT (RANCO)
Worcester part no. 87161078710		 £25.93
9   BURNER LEAD
Worcester part no. 87161091970		 £39.64
10   4 WAY SOCKET
Worcester part no. 87161078500		 £6.55
