GLOWWORM
ULTIMATE 30 C - (07 Electronics)
Appliance Code: 47-019-20

Appliance Diagram


07 Electronics diagram for Glowworm Ultimate 30 CClick the diagram to open it on a new page

You can then pinch & zoom to adjust the size.

1 Part number 0020097250, Screw (PK10) SCREW (PK10)
Glowworm part no. 0020097250
£6.39
2   COVER
Glowworm part no. 0020118140
£6.39
3   WIRING HARNESS
Glowworm part no. 0020118149
£9.22
4   WIRING HARNESS
Glowworm part no. 0020118156
£8.86
5 Part number 0020118159, Printed circuit board PRINTED CIRCUIT BOARD
Glowworm part no. 0020118159
£58.46
6 Part number A000035144, ignition transformer IGNITION TRANSFORMER
Glowworm part no. A000035144
£38.23
7   SCREW - IGN FLAME ELEC (PK50)
Glowworm part no. 2000801960
£5.13
7 Part number S5490600, Screw (pk50) SCREW (PK50)
Glowworm part no. S5490600
£14.38
8 Part number 2000801935, NOW USE S5739800 ntc with clip d=18mm 10kOhm NOW USE S5739800 NTC WITH CLIP D=18MM 10KOHM
Glowworm part no. 2000801935

8 Part number S5739800, Temperature sensor TEMPERATURE SENSOR
Glowworm part no. S5739800
£23.87
9 Part number 0020097284, Strap (PK5) STRAP (PK5)
Glowworm part no. 0020097284
£6.39
10 Part number 0020014787, 2 AMMP FUSE 2 AMMP FUSE
Glowworm part no. 0020014787
£4.46
10 Part number 05651700, Fuse 2A (PK5) FUSE 2A (PK5)
Glowworm part no. 05651700
£6.36
11   WIRING HARNESS
Glowworm part no. 0020118156
£8.86
12 Part number 0020118138, Printed circuit PRINTED CIRCUIT
Glowworm part no. 0020118138
£226.59
13 Part number 0020118154, Wiring harness - Three way valve WIRING HARNESS - THREE WAY VALVE
Glowworm part no. 0020118154
£12.43
14 Part number 0020097285, Plastic control box cover PLASTIC CONTROL BOX COVER
Glowworm part no. 0020097285
£8.58
15 Part number 0020118146, Wiring harness WIRING HARNESS
Glowworm part no. 0020118146
£43.34
16 Part number 0020097303, Plug 5 wires PLUG 5 WIRES
Glowworm part no. 0020097303
£6.61
17 Part number 0020097304, Plug 6 wires (PK5) PLUG 6 WIRES (PK5)
Glowworm part no. 0020097304
£30.99
18   CONNECTION BOX
Glowworm part no. 0020097286
£21.92
19   COVER
Glowworm part no. 0020118148
£25.57
20 Part number 0020117131, Clock CLOCK
Glowworm part no. 0020117131
£126.40
