IDEAL
ICOS SYSTEM HE15 - (Controls)
Appliance Code: 41-421-99

Appliance Diagram


Controls diagram for Ideal Icos System HE15Click the diagram to open it on a new page

You can then pinch & zoom to adjust the size.

34 Part number 170983, CONTROLS HINGE KIT ISAR/ICOS SYSTEM CONTROLS HINGE KIT ISAR/ICOS SYSTEM
Ideal part no. 170983

35 Part number 173532, USER CONTROL KIT ICOS/ICOS SYST HE USER CONTROL KIT ICOS/ICOS SYST HE
Ideal part no. 173532
£100.43
36 Part number 174486, PCB PRIMARY CONTROL KIT PCB PRIMARY CONTROL KIT
Ideal part no. 174486
£189.61
38 Part number 173536, USER CTRL HOUSING KIT-ISAR/ICOS SYST HE USER CTRL HOUSING KIT-ISAR/ICOS SYST HE
Ideal part no. 173536
£33.23
39 Part number 173537, MAINS SWITCH KIT MAINS SWITCH KIT
Ideal part no. 173537
£16.20
