IDEAL
ISTOR HE325 - (Boiler Exploded View)
Appliance Code: 41-394-14

Appliance Diagram


Boiler Exploded View diagram for Ideal Istor HE325Click the diagram to open it on a new page

You can then pinch & zoom to adjust the size.

15 Part number 174561, GAS COCK KIT GAS COCK KIT
Ideal part no. 174561		 £33.03
15 Part number 170912, NOW USE 174561 GAS COCK KIT NOW USE 174561 GAS COCK KIT
Ideal part no. 170912
29 Part number 173190, MIXER VALVE CONNECTOR MIXER VALVE CONNECTOR
Ideal part no. 173190
33 Part number 173161, MAINS SWITCH MAINS SWITCH
Ideal part no. 173161		 £5.74
37   PRE-PIPING FRAME (ISTOR)
Ideal part no. 173162		 £181.90
55   PIPE LOWER TUNDISH
Ideal part no. 173167		 £25.14
56   PIPE DHW OUTLET
Ideal part no. 173168		 £39.31
57   PIPE MANIFOLD TO PRV
Ideal part no. 173169
59 Part number 173171, PIPE MAINS COLD-IN PIPE MAINS COLD-IN
Ideal part no. 173171
59   PIPE ASSEMBLY - MAINS COLD IN
Ideal part no. 174493
66 Part number 173179, PIPE-GAS MAINS-IN ASSY 325 PIPE-GAS MAINS-IN ASSY 325
Ideal part no. 173179		 £25.81
67   PIPE-PRV S TO TUNDISH 325
Ideal part no. 173181		 £23.20
70 Part number 173183, PIPE-HOT FROM TANK 325 PIPE-HOT FROM TANK 325
Ideal part no. 173183
72   KIT - CH PIPE WORK 325
Ideal part no. 173793		 £67.68
77   PIPE-CH FLOW TANK TO TOP 325
Ideal part no. 173189		 £79.65
78 Part number 173190, MIXER VALVE CONNECTOR MIXER VALVE CONNECTOR
Ideal part no. 173190
79   TANK CONNECTOR
Ideal part no. 173191		 £23.33
81 Part number 173193, EXPANSION VESSEL - 19L EXPANSION VESSEL - 19L
Ideal part no. 173193		 £190.54
82 Part number 173194, EXPANSION VESSEL - 8L EXPANSION VESSEL - 8L
Ideal part no. 173194		 £115.68
87 Part number 173199, VALVE-PRESSURE GOVERNOR VALVE-PRESSURE GOVERNOR
Ideal part no. 173199		 £80.50
87 Part number 174492, VALVE-PRESSURE REDUCING VALVE-PRESSURE REDUCING
Ideal part no. 174492		 £90.90
89 Part number 173201, VALVE-THERMOSTATIC MIXING VALVE-THERMOSTATIC MIXING
Ideal part no. 173201		 £167.41
90 Part number 173202, VALVE-TEMP & PRESSURE RELIEF VALVE-TEMP & PRESSURE RELIEF
Ideal part no. 173202		 £67.70
91 Part number 173203, VALVE-PRESSURE RELIEF CH VALVE-PRESSURE RELIEF CH
Ideal part no. 173203		 £22.40
92 Part number 173204, VALVE-PRESSURE RELIEF DHW VALVE-PRESSURE RELIEF DHW
Ideal part no. 173204		 £23.50
93 Part number 173205, TUNDISH TUNDISH
Ideal part no. 173205		 £24.76
95 Part number 173207, FILLING LOOP FILLING LOOP
Ideal part no. 173207		 £54.83
101 Part number 173213, PRESSURE GAUGE ASSY PRESSURE GAUGE ASSY
Ideal part no. 173213		 £13.99
102 Part number 173214, FASCIA CONTROLS FASCIA CONTROLS
Ideal part no. 173214		 £28.16
104   PANEL TOP HE260/HE325
Ideal part no. 173827		 £42.90
105   PANEL UPPER SIDE HE260/HE325
Ideal part no. 173828		 £69.62
106   PANEL UPPER FRONT HE260/HE325
Ideal part no. 173829		 £52.27
107   PANEL LOWER SIDE HE325
Ideal part no. 173832		 £40.05
