WORCESTER
RD628 RSF (APRIL 2003 ONWARDS) 7716130090 - (Fan)
Appliance Code: 47-108-14

Appliance Diagram


Fan diagram for Worcester RD628 RSF (April 2003 Onwards) 7716130090Click the diagram to open it on a new page

You can then pinch & zoom to adjust the size.

Part number 29144114120, SCREW M4X8 (3X) AFTER FD992 AND BEFORE FD111 SCREW M4X8 (3X) AFTER FD992 AND BEFORE FD111
Worcester part no. 29144114120
£2.68
1 Part number 87161048150, CENTRIFUGAL BLOWER CENTRIFUGAL BLOWER
Worcester part no. 87161048150
£94.96
2 Part number 87161410000, AIR FLOW SENSOR AIR FLOW SENSOR
Worcester part no. 87161410000
£8.26
3 Part number 87161153060, SCREW (10X) 8X1/2" AFTER FD992 SCREW (10X) 8X1/2" AFTER FD992
Worcester part no. 87161153060
£3.59
4 Part number 87161048960, PRESSURE SWITCH PRESSURE SWITCH
Worcester part no. 87161048960
£29.03
5 Part number 87160100090, FIXING BRACKET AFTER FD385 FIXING BRACKET AFTER FD385
Worcester part no. 87160100090
£3.78
5 Part number 87161165480, AIR PRESSURE SWITCH BRACKET BEFORE RD385 AIR PRESSURE SWITCH BRACKET BEFORE RD385
Worcester part no. 87161165480
£2.60
6 Part number 87161010810, RED SILICONE TUBING 5M LONG RED SILICONE TUBING 5M LONG
Worcester part no. 87161010810
£17.40
7 Part number 87161010800, BEIGE SILICONE TUBING 1M LONG BEIGE SILICONE TUBING 1M LONG
Worcester part no. 87161010800
£9.29
8 Part number 87161412050, T PIECE MOULDING REF 416TEEP T PIECE MOULDING REF 416TEEP
Worcester part no. 87161412050
£3.36
9 Part number 29124212100, SCREW ISO NO 6B X 9.5 RECESSED SCREW ISO NO 6B X 9.5 RECESSED
Worcester part no. 29124212100
£2.56
10 Part number 87161111240, BRACKET APS BRACKET APS
Worcester part no. 87161111240
£3.31
