WORCESTER
50/70-OOO-GB (NOV 2001 ONWARDS) 7716100087 - (Not Shown 50/70-B20B Drawing)
Appliance Code: 7716100087

Appliance Diagram


Not Shown 50/70-B20B Drawing diagram for Worcester 50/70-OOO-GB (NOV 2001 Onwards) 7716100087Click the diagram to open it on a new page

You can then pinch & zoom to adjust the size.

0   BURNER B20B ASSEMBLY
Worcester part no. 87161053130
0 Part number 87161153110, OIL HOSE HNBR 700MM OIL HOSE HNBR 700MM
Worcester part no. 87161153110		 £27.51
0 Part number 8716118364, SATRONIC CONTROL BOX DKO972 SATRONIC CONTROL BOX DKO972
Worcester part no. 8716118364		 £185.44
0 Part number 87161405540, NIPPLE 1/4" CONICAL X 1/4" CONICAL NIPPLE 1/4" CONICAL X 1/4" CONICAL
Worcester part no. 87161405540		 £18.54
0   NOZZLE DANFOSS 1.00 60 DEG S
Worcester part no. 87161427220
0 Part number 87161427300, EBI 052F0004 TRANSFORMER EBI 052F0004 TRANSFORMER
Worcester part no. 87161427300		 £135.18
0 Part number 87161427320, (FHP) 90W MOTOR (FHP) 90W MOTOR
Worcester part no. 87161427320
0 Part number 87161427340, DRIVE COUPLING - AEG(FHP) MOTOR-B11,B20 DRIVE COUPLING - AEG(FHP) MOTOR-B11,B20
Worcester part no. 87161427340		 £6.73
0 Part number 87161427350, PHOTOCELL & FLANGE - SATRONIC MZ770 PHOTOCELL & FLANGE - SATRONIC MZ770
Worcester part no. 87161427350		 £59.21
0 Part number 87161427360, PUMP BFP11L3 OIL (LEFT HAND) PUMP BFP11L3 OIL (LEFT HAND)
Worcester part no. 87161427360		 £182.04
0 Part number 87161427370, COIL SOLENOID VALVE BFP21L3 COIL SOLENOID VALVE BFP21L3
Worcester part no. 87161427370		 £83.20
0   BLAST TUBE K TYPE X 94MM
Worcester part no. 87161427390		 £95.68
0 Part number 87161427520, IGNITION ELECTRODE 11593701 IGNITION ELECTRODE 11593701
Worcester part no. 87161427520		 £14.57
0 Part number 87161427530, ELECTRODE HOLDER ELECTRODE HOLDER
Worcester part no. 87161427530		 £8.98
0 Part number 87161427610, CABLE TRANSFORMER SUPPLY-(DANFOSS EBI) CABLE TRANSFORMER SUPPLY-(DANFOSS EBI)
Worcester part no. 87161427610		 £18.19
0 Part number 87161427690, WASHER COPPER 1/4" WASHER COPPER 1/4"
Worcester part no. 87161427690		 £2.33
0 Part number 87161427780, PUMP ARMATURE FOR DANFOSS BFP PUMP ARMATURE FOR DANFOSS BFP
Worcester part no. 87161427780		 £93.30
0 Part number 87161427820, NOW USE 87161570420 Relay base satronic tf 830 b NOW USE 87161570420 RELAY BASE SATRONIC TF 830 B
Worcester part no. 87161427820
0   NOZZLE DANFOSS 1.75 60 DEG S
Worcester part no. 87161427940		 £20.73
0   NOZZLE DANFOSS 1.35 60 DEG S
Worcester part no. 87161427960		 £20.73
0 Part number 87161464020, FAN WHEEL - B20 FAN WHEEL - B20
Worcester part no. 87161464020		 £70.81
0 Part number 87161466200, LEAD FOR BFP11L3 OIL PUMP LEAD FOR BFP11L3 OIL PUMP
Worcester part no. 87161466200		 £17.67
0 Part number 87161565130, NOZZLE DANFOSS 2.00 60 DEG S NOZZLE DANFOSS 2.00 60 DEG S
Worcester part no. 87161565130
0   BRAKE PLATE PL21.5/10 (K TYPE)
Worcester part no. 87161565180		 £112.98
0 Part number 87161565210, SHROUD FOR EBI TRANSFORMER SHROUD FOR EBI TRANSFORMER
Worcester part no. 87161565210		 £4.68
0 Part number 87161566580, NOZZLE HOLDER CHECK VALVE DANFOSS NOZZLE HOLDER CHECK VALVE DANFOSS
Worcester part no. 87161566580		 £29.45
0 Part number 87161566660, 4UF CAPACITOR FOR AEG(FHP) MOTOR[+/-5%] 4UF CAPACITOR FOR AEG(FHP) MOTOR[+/-5%]
Worcester part no. 87161566660		 £48.21
0 Part number 87161566910, SATRONIC MZ770S PHOTOCELL LEAD ONLY SATRONIC MZ770S PHOTOCELL LEAD ONLY
Worcester part no. 87161566910		 £13.44
0 Part number 87161566920, SATRONIC MZ770S PHOTOCELL C/W FLANGE&LEAD SATRONIC MZ770S PHOTOCELL C/W FLANGE&LEAD
Worcester part no. 87161566920		 £44.78
0   AIR DISTRIBUTOR COLLAR 70X15MM SLOT
Worcester part no. 87161570040		 £15.39
0   ELECTRODE LEADS (PAIR) LENGTH 330MM
Worcester part no. 87161570050		 £25.62
0   NOZZLE HOLDER
Worcester part no. 87161570060		 £52.84
0   REAR COVER PLATE FOR NOZZLE HOLDER B20
Worcester part no. 87161570070		 £22.54
0   NOZZLE HOLDER ADJUSTMENT SCALE B20
Worcester part no. 87161570080		 £5.68
0   NOZZLE HOLDER ADJUSTMENT COG B20
Worcester part no. 87161570090		 £6.90
0   NOZZLE ADJUSTING DRIVE COG B20
Worcester part no. 87161570100		 £5.85
0   REAR COVER PLATE GROMMET
Worcester part no. 87161570110		 £2.79
0   MOTOR CABLE - AEG(FHP)
Worcester part no. 87161570120		 £11.71
0   AIR INTAKE REGULATOR/COVER B20
Worcester part no. 87161570130		 £43.29
0 Part number 87161570140, PUMP SUNTEC AS47C PUMP SUNTEC AS47C
Worcester part no. 87161570140		 £174.71
0 Part number 87161570150, PIPE - TWO CONVERSION SCREW - DANFOSS PIPE - TWO CONVERSION SCREW - DANFOSS
Worcester part no. 87161570150		 £7.97
0   PIPE - TWO CONVERSION SCREW - SUNTEC AS4
Worcester part no. 87161570160		 £10.34
0   PIPE NOZZLE CONNECTING BFP11 PUMP TO B20
Worcester part no. 87161570170
0   BURNER MAIN BODY - FRAME - B20(SERIES 2)
Worcester part no. 87161570180		 £195.70
0   FRONT COVER - FRAME - B20 (SERIES 2)
Worcester part no. 87161570190		 £77.57
0   FAN HOUSING RIGHT HALF - B20
Worcester part no. 87161570200		 £62.95
0   FAN HOUSING LEFT HALF - B20
Worcester part no. 87161570210		 £55.65
0 Part number 87161570420, CONTROL BOX BASE-SATRONIC CONTROL BOX BASE-SATRONIC
Worcester part no. 87161570420		 £41.65
