WORCESTER
MULTIPOINT BF ERP 7702311041 - (Gas Valve)
Appliance Code: 7702311041

Appliance Diagram


Gas Valve diagram for Worcester Multipoint BF ERP 7702311041Click the diagram to open it on a new page

You can then pinch & zoom to adjust the size.

1   GAS VALVE
Worcester part no. 87070210700
2   THROTTLE HOUSING
Worcester part no. 87052050690
3   SETTING SCREW
Worcester part no. 87034040970		 £8.18
4 Part number 87002050010, O-RING (10X) O-RING (10X)
Worcester part no. 87002050010		 £2.14
5   PROTECTIVE CAP (10X)
Worcester part no. 87005050010		 £1.75
6   SCREW M5X12 STEEL PHILLIPS PAN HD
Worcester part no. 87434010020		 £0.74
7   WASHER (10X)
Worcester part no. 87010040010		 £1.50
8   COMPRESSION SPRING
Worcester part no. 87046030670		 £2.98
9   COMPRESSION SPRING
Worcester part no. 87046031180		 £0.76
10   POPPET VALVE HEAD (2)
Worcester part no. 87085002440		 £47.96
11   VALVE STEM
Worcester part no. 87031010570		 £8.18
12   O-RING (10X)
Worcester part no. 87402050020		 £1.75
13 Part number 87005070020, GAS FILTER GAS FILTER
Worcester part no. 87005070020		 £0.09
14 Part number 87001030140, WASHER-FIBRE 24OD X 16ID X 2MM (10X) WASHER-FIBRE 24OD X 16ID X 2MM (10X)
Worcester part no. 87001030140		 £0.74
15   PILOT GAS FILTER
Worcester part no. 87032030010		 £1.57
16   SCREW (10X)
Worcester part no. 87034010510		 £0.76
17 Part number 87072010120, MAGNETIC UNIT MAGNETIC UNIT
Worcester part no. 87072010120		 £52.23
18   VALVE OPERATION HOUSING
Worcester part no. 87080080090		 £29.03
19   POPPET VALVE HEAD
Worcester part no. 87085002390
20   RETAINING RING (10X)
Worcester part no. 29160809040		 £0.56
21   WASHER (10X)
Worcester part no. 87010040200		 £1.48
22   SCREW (10X)
Worcester part no. 87034010650
23   SLOTTED PLATE
Worcester part no. 87010000840
24   GUIDE PLATE
Worcester part no. 87010003650
25 Part number 29106124240, SCREW NO8X3/8" PHILLIPS (10X) SCREW NO8X3/8" PHILLIPS (10X)
Worcester part no. 29106124240		 £0.56
26   KIT GAS INLET - ACCESSORY N1125
Worcester part no. 7709003578
