VIESSMANN
100-W WB1A 30KW COMBI (SERIAL NO. 7179916) - (Thermal)
Appliance Code: 47-819-05

Appliance Diagram


Thermal diagram for Viessmann 100-W WB1A 30kW Combi (Serial No. 7179916)Click the diagram to open it on a new page

You can then pinch & zoom to adjust the size.

001 Part number 7825487, Thermal switch THERMAL SWITCH
Viessmann part no. 7825487
£66.50
002 Part number 7819967, Temperature sensor TEMPERATURE SENSOR
Viessmann part no. 7819967
£66.50
007 Part number 7822742, Test port cap (set of 2) WB / B2xx TEST PORT CAP (SET OF 2) WB / B2XX
Viessmann part no. 7822742
£10.45
008 Part number 7823845, Vent pipe Adapter turret 60/100 WB1A VENT PIPE ADAPTER TURRET 60/100 WB1A
Viessmann part no. 7823845
£46.55
009 Part number 7823846, Gasket set (flue gas) WB1A GASKET SET (FLUE GAS) WB1A
Viessmann part no. 7823846
£20.90
017   UNION NUT HV
Viessmann part no. 7823854
£95.00
019 Part number 7823856, Heating flow pipe HV HEATING FLOW PIPE HV
Viessmann part no. 7823856
£22.80
033   GROMMETS
Viessmann part no. 7823870
£33.25
034 Part number 7823871, Gasket set GASKET SET
Viessmann part no. 7823871
£21.85
035 Part number 7823872, Spring clips (set of assorted) SPRING CLIPS (SET OF ASSORTED)
Viessmann part no. 7823872
£17.10
040 Part number 7822285, LIP SEAL DIA 60MM LIP SEAL DIA 60MM
Viessmann part no. 7822285
£5.81
041 Part number 7822670, VENTILATION SEAL DIA 100MM VENTILATION SEAL DIA 100MM
Viessmann part no. 7822670
£8.43
