VOKERA
EVOLVE 42C REV. 0 (10/2017) - (Hydraulics 1)
Appliance Code: 47-364-41

Appliance Diagram


Hydraulics 1 diagram for Vokera Evolve 42C Rev. 0 (10/2017)Click the diagram to open it on a new page

You can then pinch & zoom to adjust the size.

30 Part number 20049617, QUICK PRIMER PRESSURE GAUGE QUICK PRIMER PRESSURE GAUGE
Vokera part no. 20049617
£17.20
40   WATER GAUGE CARRIER
Vokera part no. 20123121
£1.73
50 Part number 20132277, NOW USE 20189868 Heat Exchanger NOW USE 20189868 HEAT EXCHANGER
Vokera part no. 20132277

50   HEAT EXCHANGER - REPLACED 20132277
Vokera part no. 20189868
£76.00
60 Part number 20123980, Three Way Valve THREE WAY VALVE
Vokera part no. 20123980
£49.02
61 Part number 20123997, Stepper Actuator and Cartridge STEPPER ACTUATOR AND CARTRIDGE
Vokera part no. 20123997
£39.92
62 Part number 20123996, Stepper Actuator STEPPER ACTUATOR
Vokera part no. 20123996
£28.22
63   CLIP
Vokera part no. 20123995
£1.63
70 Part number 10024641, By-pass casing BY-PASS CASING
Vokera part no. 10024641
£14.95
80 Part number 10030114, NOW USE 10024640 Connection NOW USE 10024640 CONNECTION
Vokera part no. 10030114

80 Part number 10024640, Connection CONNECTION
Vokera part no. 10024640
£11.50
90 Part number 10024643, Cover for by-pass assembly COVER FOR BY-PASS ASSEMBLY
Vokera part no. 10024643
£10.94
100   NOW USE 10025839 PIPE
Vokera part no. 20011423

100   PIPE
Vokera part no. 10025839
£17.46
110 Part number 10025840, Pipe PIPE
Vokera part no. 10025840
£12.94
120   PIPE
Vokera part no. 20123120
£21.23
130 Part number 20024559, Pressure Transductor PRESSURE TRANSDUCTOR
Vokera part no. 20024559
£32.68
131 Part number 10026494, O RING O RING
Vokera part no. 10026494
£0.72
140 Part number 20029985, DHW ACTUATOR DHW ACTUATOR
Vokera part no. 20029985
£26.85
150 Part number 20044364, Safety valve Rep 10025055 & 20034917 & 20043820 SAFETY VALVE REP 10025055 & 20034917 & 20043820
Vokera part no. 20044364
£22.49
160 Part number 10025056, Non return valve NON RETURN VALVE
Vokera part no. 10025056
£5.11
170 Part number 1552, Valve For DHW Bypass VALVE FOR DHW BYPASS
Vokera part no. 1552
£7.77
180 Part number 10025059, Connection CONNECTION
Vokera part no. 10025059
£11.53
190 Part number 10024985, Nipple NIPPLE
Vokera part no. 10024985
£11.88
220 Part number 10024646, Discharge Valve with O ring (10025064) & Washer (10025066) DISCHARGE VALVE WITH O RING (10025064) & WASHER (10025066)
Vokera part no. 10024646
£7.85
240 Part number 10027351, Thermistor/NTC Sensor THERMISTOR/NTC SENSOR
Vokera part no. 10027351
£7.96
250   FLOW GOVERNOR 15 LITRES PER MINUTE (LIME GREEN)
Vokera part no. 10026042
£5.94
260 Part number 10027757, Locking Pin LOCKING PIN
Vokera part no. 10027757
£0.77
260 Part number 2165, NOW USE 10027757 LOCKING PIN NOW USE 10027757 LOCKING PIN
Vokera part no. 2165

270 Part number 10024986, Locking Pin LOCKING PIN
Vokera part no. 10024986
£0.98
280 Part number 10024958, Locking Pin LOCKING PIN
Vokera part no. 10024958
£0.98
290 Part number 10025062, Locking Pin LOCKING PIN
Vokera part no. 10025062
£2.26
300 Part number 10025063, Locking Pin LOCKING PIN
Vokera part no. 10025063
£0.98
310 Part number 10024988, O ring O RING
Vokera part no. 10024988
£0.81
320 Part number 6898, O Ring O RING
Vokera part no. 6898
£1.03
330 Part number 10025064, O ring O RING
Vokera part no. 10025064
£5.30
340 Part number 10023533, O Ring O RING
Vokera part no. 10023533
£1.36
350 Part number 5026, 1/2" Fibre Washer 1/2" FIBRE WASHER
Vokera part no. 5026
£0.39
370 Part number 10025065, O ring O RING
Vokera part no. 10025065
£1.91
380 Part number 10025066, Washer WASHER
Vokera part no. 10025066
£3.27
390 Part number 10025067, O ring O RING
Vokera part no. 10025067
£2.61
410   GASKET
Vokera part no. 20123123
£0.83
520   COCK
Vokera part no. 20132651
£31.62
530   HEATING COCK (FROM SERIAL NO. 20119408M250109)
Vokera part no. 20141319
£15.39
540   HEAT WATER COCK
Vokera part no. 20132652
£21.23
550   HEAT WATER COCK
Vokera part no. 20132653
£19.26
560   FILLING COCK
Vokera part no. 20132655
£8.18
570   ANGLE PIPE
Vokera part no. 20132654
£9.55
580   SAFETY VALVE PIPE
Vokera part no. 20132656
£8.91
585   FLEXIBLE PIPE/FILLING LOOP (CURVED)
Vokera part no. 20141318
£13.32
670   WASHER
Vokera part no. 20133198
£2.26
680   WASHER
Vokera part no. 20133197
£1.79
690 Part number 5023, 3/4" Fibre Washer 3/4" FIBRE WASHER
Vokera part no. 5023
£0.43
694   CAP NUT
Vokera part no. 20133199
£1.18
696   CAP NUT
Vokera part no. 20133200
£1.06
820   EXTERNAL UTILITIES BOX
Vokera part no. 20123127
£44.57
910   FIVE POSITIONS FAIRLEAD
Vokera part no. 20123125
£1.65
999 Part number 10026046, Flow governor 14 Litres per Minute (Pink) FLOW GOVERNOR 14 LITRES PER MINUTE (PINK)
Vokera part no. 10026046
£6.11
999   DARK BLUE FLOW RESTRICTOR
Vokera part no. 20141317
P.O.A.
