VOKERA
MYNUTE 35 EHE REV 7 (01/2013) - (Hydraulics 2)
Appliance Code: 20001646

Appliance Diagram


Hydraulics 2 diagram for Vokera Mynute 35 EHE Rev 7 (01/2013)Click the diagram to open it on a new page

You can then pinch & zoom to adjust the size.

1 Part number 2573, Expansion Vessel Rep 106333 10 Litre EXPANSION VESSEL REP 106333 10 LITRE
Vokera part no. 2573
£104.11
2 Part number 10025188, Flexible pipe for Expansion vessel FLEXIBLE PIPE FOR EXPANSION VESSEL
Vokera part no. 10025188
£15.43
3 Part number 10027258, NOW USE 20185332 Pump NOW USE 20185332 PUMP
Vokera part no. 10027258

3   ERP PUMP - REPLACED 10027571 10027258 20039926 & 20005582
Vokera part no. 20185332
£202.10
4 Part number 10025485, Auto air vent bottle (Pump) AUTO AIR VENT BOTTLE (PUMP)
Vokera part no. 10025485
£19.12
6   PIPE
Vokera part no. 10027741
£22.28
7   PIPE
Vokera part no. 10024519
£19.31
8 Part number 10020513, Main Heat Exchanger MAIN HEAT EXCHANGER
Vokera part no. 10020513
£207.44
9   FLOW PIPE
Vokera part no. 10020519
£14.85
10   PIPE
Vokera part no. 10027742
£42.44
25 Part number 10027546, Siphon SIPHON
Vokera part no. 10027546
£64.17
27 Part number 20066463, Plastic Condense Pipe Replaced 10028015 PLASTIC CONDENSE PIPE REPLACED 10028015
Vokera part no. 20066463
£25.12
43 Part number 01005411, Condensing unit CONDENSING UNIT
Vokera part no. 01005411
£471.10
48   PIPE
Vokera part no. 10024518
£28.12
49   PIPE
Vokera part no. 10024520
£19.79
66 Part number 10027545, Flexible pipe FLEXIBLE PIPE
Vokera part no. 10027545
£8.88
200 Part number 5023, 3/4" Fibre Washer 3/4" FIBRE WASHER
Vokera part no. 5023
£0.43
201 Part number 5026, 1/2" Fibre Washer 1/2" FIBRE WASHER
Vokera part no. 5026
£0.39
202 Part number 5041, Washer WASHER
Vokera part no. 5041
£0.19
277 Part number 6903, Screw SCREW
Vokera part no. 6903
£1.50
287 Part number 2258, High Limit Thermostat HIGH LIMIT THERMOSTAT
Vokera part no. 2258
£8.97
288 Part number 6898, O Ring O RING
Vokera part no. 6898
£1.03
290 Part number 10027757, Locking Pin LOCKING PIN
Vokera part no. 10027757
£0.77
290 Part number 2165, NOW USE 10027757 LOCKING PIN NOW USE 10027757 LOCKING PIN
Vokera part no. 2165

370 Part number 10023533, O Ring O RING
Vokera part no. 10023533
£1.36
371 Part number 10023532, Locking Pin LOCKING PIN
Vokera part no. 10023532
£13.63
393 Part number 10024141, O ring O RING
Vokera part no. 10024141
£16.60
394 Part number 10024142, O ring O RING
Vokera part no. 10024142
£0.69
395 Part number 10024143, O ring O RING
Vokera part no. 10024143
£11.33
396 Part number 01005292, Connections kit CONNECTIONS KIT
Vokera part no. 01005292
£29.99
520 Part number 10027352, Thermistor/NTC Sensor (20004978) THERMISTOR/NTC SENSOR (20004978)
Vokera part no. 10027352
£13.58
532 Part number 10027540, Condense Unit Washer CONDENSE UNIT WASHER
Vokera part no. 10027540
£8.88
