POTTERTON
PERFORMA 24 ECO HE - (Combustion Box)
Appliance Code: 47-393-11

Appliance Diagram


Combustion Box diagram for Potterton Performa 24 Eco HEClick the diagram to open it on a new page

You can then pinch & zoom to adjust the size.

200 Part number 5112369, FLUE ADAPTER HE (NO SEALS) FLUE ADAPTER HE (NO SEALS)
Potterton part no. 5112369
£12.33
201 Part number 5112370, GASKET ADAPTER GASKET ADAPTER
Potterton part no. 5112370
£4.57
202 Part number 5113313, TAP ADAPTER TAP ADAPTER
Potterton part no. 5113313
£4.57
203 Part number 5113314, O RING O RING
Potterton part no. 5113314
£3.16
204 Part number 247731, PLATE BLANKING PLATE BLANKING
Potterton part no. 247731
£5.88
205 Part number 247732, GASKET - PLATE BLANKING GASKET - PLATE BLANKING
Potterton part no. 247732
£3.26
208 Part number 248192, STUD - FRONT PANEL STUD - FRONT PANEL
Potterton part no. 248192
£3.26
210 Part number 5112999, NOW USE 5137532 PRESSURE SWITCH 80 NOW USE 5137532 PRESSURE SWITCH 80
Potterton part no. 5112999

210 Part number 5137532, FAN PRESSURE SWITCH FAN PRESSURE SWITCH
Potterton part no. 5137532
£36.20
211 Part number 5112367, PIPE-PRESSURE SWITCH NEG.BLACK PIPE-PRESSURE SWITCH NEG.BLACK
Potterton part no. 5112367
£4.57
212 Part number 248003, PIPE - VALVE COMPENSATION PIPE - VALVE COMPENSATION
Potterton part no. 248003
£3.26
212 Part number 5112574, NOW USE 248003 PIPE P/SWITCH POSITIVE NUTR NOW USE 248003 PIPE P/SWITCH POSITIVE NUTR
Potterton part no. 5112574

214   HOOD ASSEMBLY - 80 HE
Potterton part no. 5112628
£16.88
215 Part number 248094, WASHER - SEALING G3/8 WASHER - SEALING G3/8
Potterton part no. 248094
£3.54
216 Part number 247445, ADAPTER - PRESSURE PIPE ADAPTER - PRESSURE PIPE
Potterton part no. 247445
£7.15
217 Part number 248003, PIPE - VALVE COMPENSATION PIPE - VALVE COMPENSATION
Potterton part no. 248003
£3.26
218 Part number 248011, INSULATION SIDE PANEL - 105 INSULATION SIDE PANEL - 105
Potterton part no. 248011
£7.74
219 Part number 248012, INSULATION - REAR PANEL INSULATION - REAR PANEL
Potterton part no. 248012
£10.26
220 Part number 248013, INSULATION - FRONT PANEL INSULATION - FRONT PANEL
Potterton part no. 248013
£12.55
221 Part number 248015, PANEL-COMBUSTION CHAMBER-105 PANEL-COMBUSTION CHAMBER-105
Potterton part no. 248015
£9.51
223 Part number 5112743, PANEL-COMBUSTION BOX FRONT-80 PANEL-COMBUSTION BOX FRONT-80
Potterton part no. 5112743
£29.75
224 Part number 247437, SURROUND - VIEWING WINDOW SURROUND - VIEWING WINDOW
Potterton part no. 247437
£5.88
225 Part number 247436, VIEWING WINDOW VIEWING WINDOW
Potterton part no. 247436
£5.88
226 Part number 248028, NOW USE 247435 GASKET VIEWING WINDOW NOW USE 247435 GASKET VIEWING WINDOW
Potterton part no. 248028

226 Part number 247435, VIEWING WINDOW GASKET VIEWING WINDOW GASKET
Potterton part no. 247435
£3.36
228 Part number 248023, CLIP - HEAT EXCHANGER - FIXING CLIP - HEAT EXCHANGER - FIXING
Potterton part no. 248023
£6.96
229 Part number 5112401, RETROFIT OUTLET CH PIPE RETROFIT OUTLET CH PIPE
Potterton part no. 5112401
£14.29
230 Part number 248021, O RING 17.86 x 2.62 O RING 17.86 X 2.62
Potterton part no. 248021
£3.16
232 Part number 5112431, HEAT EXCHANGER-PRIMARY - 105HE HEAT EXCHANGER-PRIMARY - 105HE
Potterton part no. 5112431
£349.18
233 Part number 248035, ADAPTER - MANIFOLD ADAPTER - MANIFOLD
Potterton part no. 248035
£11.95
234 Part number 248036, GASKET - MANIFOLD ADAPTER GASKET - MANIFOLD ADAPTER
Potterton part no. 248036
£3.26
236 Part number 248034, GASKET - BURNER MANIFOLD GASKET - BURNER MANIFOLD
Potterton part no. 248034
£3.16
239   MANIFOLD - BURNER - 80
Potterton part no. 5112639
£20.53
240 Part number 5112770, BURNER ASSEMBLY BURNER ASSEMBLY
Potterton part no. 5112770
£38.05
241 Part number 247384, IGNITION ELECTRODE - FRONT IGNITION ELECTRODE - FRONT
Potterton part no. 247384
£11.95
242 Part number 248038, INSULATION BOOT - ELECTRODE INSULATION BOOT - ELECTRODE
Potterton part no. 248038
£5.88
244 Part number 248037, LEAD - IGNITION ELECTRODE LEAD - IGNITION ELECTRODE
Potterton part no. 248037
£5.88
245 Part number 5112382, LEAD-SENSING ELEC/TRAP CONNECT LEAD-SENSING ELEC/TRAP CONNECT
Potterton part no. 5112382
£9.51
246   COMBUSTION CHAMBER ASSY-80 HE
Potterton part no. 5112631
£45.64
247 Part number 247439, INJECTOR 1.18mm INJECTOR 1.18MM
Potterton part no. 247439
£4.45
247 Part number 248211, INJECTOR - 0.77 LPG INJECTOR - 0.77 LPG
Potterton part no. 248211
£5.74
248 Part number 5112397, WASHER DIA 60 OUTLET BEND WASHER DIA 60 OUTLET BEND
Potterton part no. 5112397
£5.88
249 Part number 5112398, WASHER DIA100 OUTER ADAPT SEAL WASHER DIA100 OUTER ADAPT SEAL
Potterton part no. 5112398
£5.88
