BIASI
INOVIA 30C ERP - (Pump -Expansion Vessel- Main Heat Exchanger From Serial NO 030900518)
Appliance Code: 47-583-39

Appliance Diagram


Pump -Expansion Vessel- Main Heat Exchanger From Serial NO 030900518 diagram for Biasi Inovia 30C ERPClick the diagram to open it on a new page

You can then pinch & zoom to adjust the size.

3   PUMP CONNECTION FORK
Biasi part no. BI1262116
£1.57
20 Part number BI1262112, O RING GASKET 2.62 X 17.86 O RING GASKET 2.62 X 17.86
Biasi part no. BI1262112
£0.66
26   TAPPING SCREW 5 X 12
Biasi part no. BI1351107
£1.33
41   FORK
Biasi part no. KI1042101
£0.68
48 Part number BI1262114, O RING GASKET 1.9 X 16 O RING GASKET 1.9 X 16
Biasi part no. BI1262114
£0.60
53 Part number BI1202105, GASKET 3/8" FOR EXP VESSEL GASKET 3/8" FOR EXP VESSEL
Biasi part no. BI1202105
£0.55
54 Part number BI1212112, O-Ring Gasket O-RING GASKET
Biasi part no. BI1212112
£0.66
61 Part number BI1536101, FLUE OUTLET GASKET FLUE OUTLET GASKET
Biasi part no. BI1536101
£4.75
62   FLUE ADAPTER FOR ADV PLUS/INOVIA
Biasi part no. BI1552101
£14.59
63   SAFETY THERMAL FUSE
Biasi part no. BI1562121
P.O.A.
64 Part number BI1432101, M110B.32KW HEAT EXCHANGER M110B.32KW HEAT EXCHANGER
Biasi part no. BI1432101
£362.23
65   FLUE OUTLET LIP GASKET
Biasi part no. BI1432104
£7.79
66   FLUE TEMPERATURE PROBE NTC
Biasi part no. BI1782103
£36.94
67 Part number BI1181110, O-RING 1.78 X 10.82 O-RING 1.78 X 10.82
Biasi part no. BI1181110
£1.23
68 Part number BI1462100, EXPANSION VESSEL EXPANSION VESSEL
Biasi part no. BI1462100
£114.74
69   LOCK NUT
Biasi part no. BI1462106
£1.66
70   EXPANSION VESSEL PIPE
Biasi part no. BI1562107
£17.51
71 Part number BI1262113, O RING GASKET 2.62 X 9.92 O RING GASKET 2.62 X 9.92
Biasi part no. BI1262113
£0.66
72   CONNECTION SPRING
Biasi part no. BI1462107
P.O.A.
73   CONDENSATE TRAP
Biasi part no. BI1782107
£15.19
74   CONDENSATE CONNECTION HOSE
Biasi part no. BI1262128
£7.02
75 Part number BI1002113, Grommet Seal Mfs GROMMET SEAL MFS
Biasi part no. BI1002113
£3.91
76 Part number BI1262120, FORK FOR AAV FORK FOR AAV
Biasi part no. BI1262120
£5.27
77   ERP PUMP
Biasi part no. BI1672100
£229.72
78   PUMP MOTOR
Biasi part no. BI1672101
P.O.A.
79 Part number BI1172113, Pump Gasket Front PUMP GASKET FRONT
Biasi part no. BI1172113
£2.19
80 Part number BI1212107, Automatic Air Purger Valve AUTOMATIC AIR PURGER VALVE
Biasi part no. BI1212107
£20.18
81   CONDENSING HEAT EXCHANGER INLET PIPE
Biasi part no. BI1672102
P.O.A.
82 Part number BI1442106, SPRING MOUNTING TEMP PROBE SPRING MOUNTING TEMP PROBE
Biasi part no. BI1442106
£14.01
83   COND HEAT EXCHANGER CON CLIPS
Biasi part no. BI1432106
£3.07
84   CONDENSATE DISCHARGE PIPE
Biasi part no. BI1782111
P.O.A.
85   M2.9 X 4.5 SCREW
Biasi part no. BI1002127
£0.11
86   CONDENSING HEAT EXCHANGER OUTLET PIPE
Biasi part no. BI1672103
P.O.A.
87 Part number BI1172105, Overheat Thermostat OVERHEAT THERMOSTAT
Biasi part no. BI1172105
£14.32
