BAXI
824 SYSTEM - (Hydraulics)
Appliance Code: 41-470-74

Appliance Diagram


Hydraulics diagram for Baxi 824 SystemClick the diagram to open it on a new page

You can then pinch & zoom to adjust the size.

401   KIT FLOW BLOCK ASSY
Baxi part no. 7686280
£87.51
402 Part number 248432, SCREW M5 x 10 SCREW M5 X 10
Baxi part no. 248432
£3.26
403   KIT BYPASS PIPE
Baxi part no. 7686282
£39.26
404   KIT SEALS AND CLIPS - BYPASS
Baxi part no. 7686283
£10.64
405 Part number 7683976, KIT PRESSURE RELIEF VALVE KIT PRESSURE RELIEF VALVE
Baxi part no. 7683976
£20.33
406   KIT PRV PIPE
Baxi part no. 7683977
£22.62
407 Part number 5114748, PRESSURE SWITCH PRESSURE SWITCH
Baxi part no. 5114748
£19.79
408   PIPE - EXPANSION VESSEL
Baxi part no. 7715761
£18.14
409   KIT O-RINGS X2 EXPAN VESSEL
Baxi part no. 7683973
£7.41
410 Part number 7683968, KIT GAS VALVE 22V ASSEMBLY KIT GAS VALVE 22V ASSEMBLY
Baxi part no. 7683968
£98.33
411   NOZZLE GAS 5.0 KIT
Baxi part no. 7211862
£12.58
412   KIT GAS PIPE ASSEMBLY
Baxi part no. 7683970
£46.52
413   GASKET GAS VALVE SIT 848
Baxi part no. 7214350
£7.11
414   G3/4 FIBRE WASHER
Baxi part no. 720910201
£15.79
415   SEAL & FIXING SPRING - GAS PIPE
Baxi part no. 7683971
£7.41
416   NOW USE 7855245 KIT GRUNDFOS PUMP ASSEMBLED
Baxi part no. 7684006

416   KIT GRUNDFOS PUMP UPM4
Baxi part no. 7855245
£163.34
417 Part number 7686336, KIT PUMP HEAD KIT PUMP HEAD
Baxi part no. 7686336

418 Part number 720777601, AIR VENT VALVE AIR VENT VALVE
Baxi part no. 720777601
£31.80
419 Part number 720782801, SEAL HYDRO GROUP SEAL HYDRO GROUP
Baxi part no. 720782801
£10.53
420   KIT CONNECTIONS PACK - SYS
Baxi part no. 7686322
£102.59
421   KIT RETURN BLOCK ASSY
Baxi part no. 7686281
£42.80
423   KIT BLANKING PLUGS SYSTEM
Baxi part no. 7686320
£7.97
427 Part number 248000, WASHER - SEALING WASHER - SEALING
Baxi part no. 248000
£3.16
