IDEAL
LOGIC + HEAT H 12 - (Controls)
Appliance Code: 41-750-82

Appliance Diagram


Controls diagram for Ideal Logic + Heat H 12Click the diagram to open it on a new page

You can then pinch & zoom to adjust the size.

303 Part number 179038, PCB KM821 I2 KIT PCB KM821 I2 KIT
Ideal part no. 179038
£123.45
304 Part number 175985, CONTROL THERMISTOR (FLOW/RETURN) - HEAT CONTROL THERMISTOR (FLOW/RETURN) - HEAT
Ideal part no. 175985
£16.78
305 Part number 179043, KNOB POTENTIOMETER WHITE KNOB POTENTIOMETER WHITE
Ideal part no. 179043
£3.98
305   KNOB POTENTIOMETER BLANK
Ideal part no. 179045
£3.37
318 Part number 179227, HARNESS VOLTAGE PELV HARNESS VOLTAGE PELV
Ideal part no. 179227
£28.79
324 Part number 179072, CONTROL BOX LID KIT CONTROL BOX LID KIT
Ideal part no. 179072
£29.88
325   CONTROL BOX FRONT
Ideal part no. 179229
£35.83
