VOKERA
PLUS 18V REV 0 (06/2018) - (Hydraulics 2)
Appliance Code: 41-364-05 REV 0

Appliance Diagram


Hydraulics 2 diagram for Vokera Plus 18V Rev 0 (06/2018)Click the diagram to open it on a new page

You can then pinch & zoom to adjust the size.

  DEGASSER CONNECTION ASSEMBLY
Vokera part no. 20096793		 £3.99
7 Part number 10026267, Pipe (Rep 10027317) PIPE (REP 10027317)
Vokera part no. 10026267		 £29.45
9 Part number 20020182, Flow Pipe Assembly (Rep 10029515) FLOW PIPE ASSEMBLY (REP 10029515)
Vokera part no. 20020182		 £76.95
17   AIR VENT VALVE
Vokera part no. 20147535		 £6.30
25 Part number 10028405, Siphon SIPHON
Vokera part no. 10028405		 £56.05
26 Part number 10028540, Condensing pipe CONDENSING PIPE
Vokera part no. 10028540		 £5.51
27 Part number 10027192, Flexible pipe FLEXIBLE PIPE
Vokera part no. 10027192		 £7.13
71   AIR BLEEDING CONNECTION PIPE
Vokera part no. 20020181		 £6.75
72 Part number 10023235, VENT PLUG (up to serial no. 20099226O0950120) VENT PLUG (UP TO SERIAL NO. 20099226O0950120)
Vokera part no. 10023235		 £4.28
73 Part number 10028431, COCK (up to serial no, 20099226O0950120) COCK (UP TO SERIAL NO, 20099226O0950120)
Vokera part no. 10028431		 £9.50
247 Part number 5203, Plastic Washer PLASTIC WASHER
Vokera part no. 5203		 £0.19
288 Part number 6898, O Ring O RING
Vokera part no. 6898		 £1.05
372   CLIP
Vokera part no. 2588		 £0.86
432 Part number 10024958, Locking Pin LOCKING PIN
Vokera part no. 10024958		 £1.05
476 Part number 10026324, O ring O RING
Vokera part no. 10026324		 £2.95
477 Part number 10026269, Clip CLIP
Vokera part no. 10026269		 £1.05
512 Part number 10027193, Washer WASHER
Vokera part no. 10027193		 £1.14
538   HOSE CLAMP
Vokera part no. 20152306		 £2.09
574   FLEXIBLE PIPE
Vokera part no. 20153685		 £12.35
582 Part number 9695, Thermostat THERMOSTAT
Vokera part no. 9695		 £8.55
700 Part number 20019888, Air Separator (UP TO SERIAL NO. 20097278PR05P005812) AIR SEPARATOR (UP TO SERIAL NO. 20097278PR05P005812)
Vokera part no. 20019888		 £18.05
700 Part number 20032553, NOW USE 20019888 DEGASSER KIT NOW USE 20019888 DEGASSER KIT
Vokera part no. 20032553
701   PIPE
Vokera part no. 20019764		 £28.50
702   PIPE
Vokera part no. 20020180		 £17.10
704 Part number 20019767, Locking Pin LOCKING PIN
Vokera part no. 20019767		 £0.48
705   LOCKING PIN
Vokera part no. 20120828		 £1.14
825 Part number 20081926, Thermistor/NTC Replaced 20003819 and 20004365 THERMISTOR/NTC REPLACED 20003819 AND 20004365
Vokera part no. 20081926		 £17.10
