VOKERA
UNICA I28 REV 8 ERP (04/2018) - (Burner)

Appliance Diagram


Burner diagram for Vokera Unica i28 Rev 8 ERP (04/2018)Click the diagram to open it on a new page

You can then pinch & zoom to adjust the size.

2   ROOMSEALED CHAMBER SIDE
Vokera part no. 10026231
£29.33
3 Part number 20002995, FAN FAN
Vokera part no. 20002995
£220.10
4   BURNER (FROM SERIAL NO. 20101253N1450193)
Vokera part no. 20087379
£40.41
5   IGNITION ELECTRODE - REPLACES 20057856 (FROM SERIAL NO. 20101253N1450193)
Vokera part no. 20119995
£11.71
12   GAS PIPE
Vokera part no. 10028620
£13.54
13 Part number 20039202, Gas valve Rep 10028538 & 10027187 & 20025752 GAS VALVE REP 10028538 & 10027187 & 20025752
Vokera part no. 20039202
£150.64
14 Part number 20040675, Gas Valve Solenoid (Fits 20039202/20035533) GAS VALVE SOLENOID (FITS 20039202/20035533)
Vokera part no. 20040675
£70.50
15 Part number 10020897, Gas Cock GAS COCK
Vokera part no. 10020897
£23.07
16   AIR CHAMBER ACCESS PANEL
Vokera part no. 20069007
£43.76
27   PLASTIC HOLE COVER
Vokera part no. 20005586
£1.46
32   WASHER
Vokera part no. 20057870
£2.65
35   AIR/GAS MANIFOLD
Vokera part no. 20057885
£16.92
39   FLEXIBLE PIPE
Vokera part no. 20067581
£15.70
67   TRYTON
Vokera part no. 20057858
£21.71
72   MIXER (FROM SERIAL NO. 20101253N1450193)
Vokera part no. 20067579
£76.13
79   SENSING/DETECTION ELECTRODE - REPLACED 20072077 AND 20057857
Vokera part no. 20119996
£8.75
98   MIXER SPACER
Vokera part no. 20036990
£0.66
100   BURNER ASSEMBLY (FROM SERIAL NO. 20101253N1450193)
Vokera part no. 20057887
£97.76
105   DIFFERENTIAL PRESSURE SWITCH
Vokera part no. 20143726
£20.09
106   INLET WITH PRESSURE INTAKE
Vokera part no. 20143722
£3.10
107   SILICONE PIPE
Vokera part no. 20143725
£1.58
200 Part number 5023, 3/4" Fibre Washer 3/4" FIBRE WASHER
Vokera part no. 5023
£0.39
486 Part number 10026325, O ring O RING
Vokera part no. 10026325
£2.23
497 Part number 10026796, Fan Gasket FAN GASKET
Vokera part no. 10026796
£6.36
613 Part number 20001563, NOW USE 20002969 IGNITION TRANSFORMER NOW USE 20002969 IGNITION TRANSFORMER
Vokera part no. 20001563

613 Part number 20002969, Ignition transformer with wires Rep 10026237 & 20001563 IGNITION TRANSFORMER WITH WIRES REP 10026237 & 20001563
Vokera part no. 20002969
£37.35
784   WASHER
Vokera part no. 20057871
£2.40
785   WASHER
Vokera part no. 20057878
£4.51
786 Part number 20057872, GLASS FIBRE GLASS FIBRE
Vokera part no. 20057872
£3.71
900   COMBUSTION CHAMBER CLIP AND 2 RIVETS
Vokera part no. 20061168
£2.06
999   LPG TO NG CONVERSION KIT (FROM SERIAL NO. 20101253N1450193)
Vokera part no. 20069587
£36.19
999   NG TO LPG CONVERSION KIT (FROM SERIAL NO. 20101253N1450193)
Vokera part no. 20069593
£36.19
