VOKERA
PLUS 29CI REV 2 NG (09/2019) - (Hydraulics 2)
Appliance Code: 47-364-47 REV 2

Appliance Diagram


Hydraulics 2 diagram for Vokera Plus 29CI Rev 2 NG (09/2019)Click the diagram to open it on a new page

You can then pinch & zoom to adjust the size.

1 Part number 20138101, 8 Litre Expansion Vessel - Replaced 20029826 8 LITRE EXPANSION VESSEL - REPLACED 20029826
Vokera part no. 20138101
£100.70
2 Part number 10028603, Pipe PIPE
Vokera part no. 10028603
£12.85
4 Part number 10025485, Auto air vent bottle (Pump) AUTO AIR VENT BOTTLE (PUMP)
Vokera part no. 10025485
£19.12
7   NOW USE 20166123 PIPE
Vokera part no. 20137499

7   PIPE
Vokera part no. 20166123
£32.04
8 Part number 20039924, Exchanger Assembly rep 20026081 EXCHANGER ASSEMBLY REP 20026081
Vokera part no. 20039924
£340.38
10   NOW USE 20186278 PIPE (FROM SERIAL NO. 20099227PR02P003267)
Vokera part no. 20164545

10   FLOW PIPE
Vokera part no. 20186278
£25.46
17 Part number 20019768, Auto air vent (Black) AUTO AIR VENT (BLACK)
Vokera part no. 20019768
£5.81
17   NOW USE 20019768 AIR VENT VALVE
Vokera part no. 20147535

19   EXPANSION VESSEL BRACKET
Vokera part no. 20125261
£2.46
25   DRAINAGE PIPE AND SIPHON KIT (FROM SERIAL NO PR35O005381 OR PR34O002804)
Vokera part no. 20169871
£20.60
25   SIPHON (UP TO SERIAL NO. PR35O005380 OR PR34O002803)
Vokera part no. 20169889
£17.19
27 Part number 20025743, PIPE TRAP PIPE TRAP
Vokera part no. 20025743
£7.24
34   HYDRAULIC CONNECTION (FROM SERIAL NO. 20097278PR05P005813)
Vokera part no. 20164544
£5.09
66 Part number 10027545, Flexible pipe FLEXIBLE PIPE
Vokera part no. 10027545
£8.88
88 Part number 20039954, Return Connection for Compact A RETURN CONNECTION FOR COMPACT A
Vokera part no. 20039954
£4.94
200 Part number 5023, 3/4" Fibre Washer 3/4" FIBRE WASHER
Vokera part no. 5023
£0.43
288 Part number 6898, O Ring O RING
Vokera part no. 6898
£1.03
290 Part number 10027757, Locking Pin LOCKING PIN
Vokera part no. 10027757
£0.77
290 Part number 2165, NOW USE 10027757 LOCKING PIN NOW USE 10027757 LOCKING PIN
Vokera part no. 2165

302 Part number 5025, WASHER WASHER
Vokera part no. 5025
£0.92
370 Part number 10023533, O Ring O RING
Vokera part no. 10023533
£1.36
371 Part number 10023532, Locking Pin LOCKING PIN
Vokera part no. 10023532
£13.63
432 Part number 10024958, Locking Pin LOCKING PIN
Vokera part no. 10024958
£0.98
436 Part number 10025062, Locking Pin LOCKING PIN
Vokera part no. 10025062
£2.26
538   HOSE CLAMP
Vokera part no. 20152306
£1.99
587   CONNECTION (FROM SERIAL NO. PR35O005381 OR PR34O002804)
Vokera part no. 10030382
£3.08
668 Part number 20019767, Locking Pin LOCKING PIN
Vokera part no. 20019767
£0.43
735   WATER FILTER
Vokera part no. 20165861
£1.02
825 Part number 20081926, Thermistor/NTC Replaced 20003819 and 20004365 THERMISTOR/NTC REPLACED 20003819 AND 20004365
Vokera part no. 20081926
£16.76
870   SILICONE TUBE (FROM SERIAL NO. PR35O005381 OR PR34O002804)
Vokera part no. 20169891
£2.28
