ARISTON
AQUABRAVO ITD 150 (06/2011) - (Exploded View)
Appliance Code: 3826504

Appliance Diagram


Exploded View diagram for Ariston Aquabravo ITD 150 (06/2011)Click the diagram to open it on a new page

You can then pinch & zoom to adjust the size.

1 Part number 60001790, ELEMENT 3000W + ANODE L:450 ELEMENT 3000W + ANODE L:450
Ariston part no. 60001790
£73.21
3 Part number 65110976, THERMOSTAT TBS L:450 THERMOSTAT TBS L:450
Ariston part no. 65110976
£22.60
21 Part number 60000225, SAFETY DEVICE PACK SAFETY DEVICE PACK
Ariston part no. 60000225
£155.27
22 Part number 969046, TEMPERATURE+PRESSURE RELIEF VALVE (FROM 04/08) TEMPERATURE+PRESSURE RELIEF VALVE (FROM 04/08)
Ariston part no. 969046
£76.84
23 Part number 65105593, ANODE D:16 L:160 M6 ANODE D:16 L:160 M6
Ariston part no. 65105593
£8.20
32 Part number 60001793, GASKET GASKET
Ariston part no. 60001793
£2.40
33 Part number 60001968, O-RING D: 47,63-3,53 O-RING D: 47,63-3,53
Ariston part no. 60001968
£1.78
49 Part number 61005323, PIN PIN
Ariston part no. 61005323
£1.04
51 Part number 61005265, FOOT FOOT
Ariston part no. 61005265
£3.02
54 Part number 935185, CUT-OUT THERMOSTAT INDIRECT CUT-OUT THERMOSTAT INDIRECT
Ariston part no. 935185
£36.21
55 Part number 935184, REGULATION THERMOSTAT INDIRECT REGULATION THERMOSTAT INDIRECT
Ariston part no. 935184
£32.79
56 Part number 60001791, BULB THERMOSTAT 70- BULB THERMOSTAT 70-
Ariston part no. 60001791
£67.64
57 Part number 60000224, TWO-WAY VALVE TWO-WAY VALVE
Ariston part no. 60000224
£179.66
70 Part number 60000223, EXPANSION VESSEL 12L EXPANSION VESSEL 12L
Ariston part no. 60000223
£94.58
