BRAEMAR 3 CAT 1N - (Appliance Overview)
Appliance Code: 32-077-13

Appliance Diagram


Appliance Overview diagram for Baxi Braemar 3 CAT 1NClick the diagram to open it on a new page

You can then pinch & zoom to adjust the size.

1   OBSOLETE CASE COMPLETE - OUTER
Baxi part no. 090018

2 Part number 092018, OBSOLETE BEZEL-CONTROL KNOB-BRAE.3 OBSOLETE BEZEL-CONTROL KNOB-BRAE.3
Baxi part no. 092018

3   OBSOLETE FRAME SIDE UPPER LH
Baxi part no. 040866

4   OBSOLETE FRAME-RH-UPPER-BERMUDA LFE
Baxi part no. 040867

5   OBSOLETE FRAME-LH SIDE LOWER- BERM LFE
Baxi part no. 040868

6   OBSOLETE FRAME-RH-LOWER-BERMUDA LFE
Baxi part no. 040869

7   SCR-NO 8X14TPIX1/2 HARDTWIN-WD
Baxi part no. 042244
£2.18
8   CLIP-EDGE-SPR.STEEL
Baxi part no. 102010
£2.04
9   OBSOLETE BRKT-LOCATION-FIRE FRONT
Baxi part no. 060043

10   OBSOLETE PANEL-FRONT-BRAEMAR & LFE-ASSY
Baxi part no. 060023

11   OBSOLETE LOCATION BRACKET - FRONT PANEL
Baxi part no. 060024

13   OBSOLETE LOUVRE-TOP TRIM-BREAMAR & LFE.
Baxi part no. 060026

14   OBSOLETE CAP-TRIM
Baxi part no. 062544

15   OBSOLETE LOUVRE-ASSY-BRAEMAR & LFE
Baxi part no. 060027

16   OBSOLETE CLIP-EDGE-HARD-TEM CAR STL 1/2
Baxi part no. 082097

17   OBSOLETE REFLECTOR-BRAEMAR & LFE
Baxi part no. 042727

18   OBSOLETE BRKT-REFLECTOR SUPPORT-675C
Baxi part no. 040746

19 Part number 102012, NUT-CAPT-U-TYPE-No8 ZNPD CHRM NUT-CAPT-U-TYPE-NO8 ZNPD CHRM
Baxi part no. 102012
£3.12
20 Part number 062600, OBSOLETE WASHER NYLON-CONTROLS COVER OBSOLETE WASHER NYLON-CONTROLS COVER
Baxi part no. 062600

22   OBSOLETE COVER-CONTROL-ASSY-BRAEMAR.
Baxi part no. 060030

23 Part number 060051, OBSOLETE Restrictor View OBSOLETE RESTRICTOR VIEW
Baxi part no. 060051

24   OBSOLETE RIVET-NYLON ROKUT
Baxi part no. 102009

25   OBSOLETE GUARD-DRESS - BRAEMAR & LFE
Baxi part no. 042742

26   OBSOLETE CASE - INNER
Baxi part no. 090019

28   OBSOLETE CABLE/PIPE CLIP (LATCHING TONGUE TYPE) FOR
Baxi part no. 042161

29   CLIP-CABLE-F/E-T/CARR 23790-11
Baxi part no. 062539

31   OBSOLETE PRECISION SCREW M6 X 25 HEXAGON HEAD - STE
Baxi part no. 062430

33   OBSOLETE BRKT-CONTROL.ROD-BRAEMAR 3
Baxi part no. 090024

34   WASHER-PLAIN-5MM ZINC PLTD
Baxi part no. 062447
£2.36
35   OBSOLETE BADGE - PATENT
Baxi part no. 092007

36   OBSOLETE BLANKING PLATE - SURROUND
Baxi part no. 090030

37   OBSOLETE STRAP-FIXING-BRAEMAR
Baxi part no. 090012

38   OBSOLETE WASHER SHAKEPROOF.INT-M4 ZN PD
Baxi part no. 062451

39   OBSOLETE H-EXCH-ASSY-BRAEMAR-3
Baxi part no. 090020

39   OBSOLETE RESTRICTOR - FLUE BREAKER
Baxi part no. 090028

40   OBSOLETE BRACKET - INNER CASE LOCATION
Baxi part no. 060039

41   OBSOLETE BRACKET - OUTER CASE LOCATION LH
Baxi part no. 060040

42   OBSOLETE BRACKET - OUTER CASE LOCATION RH
Baxi part no. 060033

43   OBSOLETE BAR-FUEL RETAINING-ASSY
Baxi part no. 060034

44   OBSOLETE BRKT-GAS CONTROL.TAP-BRAE2
Baxi part no. 090007

45   OBSOLETE MACHINE SCREW M5 X 8 SLOTTED CHEESE HEAD -
Baxi part no. 062413

46 Part number 062452, WASHER SHAKEPROOF INT-M5-ZN PD WASHER SHAKEPROOF INT-M5-ZN PD
Baxi part no. 062452
£3.12
47   OBSOLETE BAFFLE-FRONT-ST-STEEL-BRAE-3
Baxi part no. 090021

49   OBSOLETE REFLECTOR-INNR-LH-BRAE 3 2 LFE
Baxi part no. 042839

50   OBSOLETE REFLECTOR-INNR-RH-BRAE 3 2 LFE
Baxi part no. 042838

51 Part number 092019, RADIANT-4-PIECE-LFE-BRAE RADIANT-4-PIECE-LFE-BRAE
Baxi part no. 092019

52   OBSOLETE BRICK-BACK 575 LFE & BRAEMAR
Baxi part no. 062588

53   OBSOLETE BRICK-SIDE BRAEMAR
Baxi part no. 062590

54   OBSOLETE ARTIFICIAL FUEL - LARGE PACK
Baxi part no. 062506

56   OBSOLETE PLATE-CLOSURE-BRAEMAR-3
Baxi part no. 090023

57 Part number 092020, KNOB-CONTROL-BRAEMAR-3 KNOB-CONTROL-BRAEMAR-3
Baxi part no. 092020

58   OBSOLETE ROD GAS TAP CONTROLS (PLATED)
Baxi part no. 062629

60   OBSOLETE TAP-DUP-PIEZO-IGNITION-H-WYMAN
Baxi part no. 092022

61   OBSOLETE LEAD-ELECTRODE-BRAEMAR 2
Baxi part no. 092011

62 Part number 042941, IGNITOR-PIEZO-REF 66111 (VERN) IGNITOR-PIEZO-REF 66111 (VERN)
Baxi part no. 042941

63 Part number 092012, OBSOLETE ELECTRODE-IGNITION-BRAEMAR 2 OBSOLETE ELECTRODE-IGNITION-BRAEMAR 2
Baxi part no. 092012

64 Part number 062560, SCR-TF-M4 x 6mm PAN POZI ZN P SCR-TF-M4 X 6MM PAN POZI ZN P
Baxi part no. 062560
£3.12
65   OBSOLETE ELBOW-90D-1/4 BSP FXF-M I
Baxi part no. 012008

67   OBSOLETE PIPE-INLET FEED.BRAEMAR 2
Baxi part no. 092013

68   OBSOLETE PIPE-FEED BRNR NUTS&OLVS BRA2
Baxi part no. 090008

69   OBSOLETE PIPE-FEED-BNR-NUTS-OLVS-RHBRA2
Baxi part no. 090009

70   OBSOLETE INJ-FIRE-N/GAS CAT 18-220 BRAY
Baxi part no. 092002

71   OBSOLETE BURNER-FIRE BRAEMAR 2 & LFE
Baxi part no. 062610

72   OBSOLETE SCR-SET-M5 X 12MM-CH HD ZNPD
Baxi part no. 062416

73 Part number 092006, OBSOLETE ARRESTER LINT-BRAE.LFE OBSOLETE ARRESTER LINT-BRAE.LFE
Baxi part no. 092006
