CHAFFOTEAUX
CALYDRA GREEN 24 - (NO Diagrams)
Appliance Code: 47-980-25

Appliance Diagram


Sorry, a diagram could not be found for this appliance.

101   EXCHANGER 24KW
Chaffoteaux part no. 61306074		 £1 252,16
107   FIXING BRACKET
Chaffoteaux part no. 61306181		 £39,20
108   FIXING BRACKET
Chaffoteaux part no. 61306180		 £88,33
109   HOOKING BRACKET
Chaffoteaux part no. 61306448		 £5,90
110 Part number 61309624, ELECTRODES ELECTRODES
Chaffoteaux part no. 61309624		 £115,57
112   WASHER D:65-59-2.6
Chaffoteaux part no. 61307588		 £4,58
114 Part number 61306078, TRAP TRAP
Chaffoteaux part no. 61306078
115 Part number 61010125, TAPPING SCREW CBLSX D: 4.2-9.5 TAPPING SCREW CBLSX D: 4.2-9.5
Chaffoteaux part no. 61010125		 £0,42
116 Part number 60081265-02, SILICONE TUBE D: 21x2.5 L: 1M SILICONE TUBE D: 21X2.5 L: 1M
Chaffoteaux part no. 60081265-02		 £48,25
117   DUCT FIRST SECTION
Chaffoteaux part no. 61306026		 £204,23
119 Part number 61010131, SCREW HX M 5-12 SCREW HX M 5-12
Chaffoteaux part no. 61010131		 £0,42
121 Part number 61308092, O-RING 17.76X1.78 O-RING 17.76X1.78
Chaffoteaux part no. 61308092		 £3,18
122 Part number 61308782, SCREW D: 5-14 SCREW D: 5-14
Chaffoteaux part no. 61308782		 £0,66
202   FLUE CONNECTION
Chaffoteaux part no. 61309242		 £31,09
203 Part number 61310088, GASKET D:66-58.4-9 (TO 03/06) GASKET D:66-58.4-9 (TO 03/06)
Chaffoteaux part no. 61310088		 £9,90
205 Part number 61306029, GASKET D:66.6 (TO 03/06) GASKET D:66.6 (TO 03/06)
Chaffoteaux part no. 61306029		 £12,93
212 Part number 61300262, GASKET (TO 03/06) GASKET (TO 03/06)
Chaffoteaux part no. 61300262		 £4,90
213 Part number 61306698, PLUG KIT (TO 03/06) PLUG KIT (TO 03/06)
Chaffoteaux part no. 61306698		 £8,27
222   OUTGOING FLUE BOX
Chaffoteaux part no. 61306028		 £116,46
227 Part number 61010847, TAPPING SCREW CBLSX D:4.2-12.5 TAPPING SCREW CBLSX D:4.2-12.5
Chaffoteaux part no. 61010847		 £0,81
228 Part number 61010648, TAPPING SCREW CBLSX D: 6.3-13 TAPPING SCREW CBLSX D: 6.3-13
Chaffoteaux part no. 61010648		 £0,44
230 Part number 61300258, GASKET (/ Flue bend turret) GASKET (/ FLUE BEND TURRET)
Chaffoteaux part no. 61300258		 £2,73
231 Part number 61306030, GASKET D:129.4 (TO 03/06) GASKET D:129.4 (TO 03/06)
Chaffoteaux part no. 61306030		 £33,62
303   TOP PANEL BOX
Chaffoteaux part no. 61305438		 £21,47
304 Part number 60081273, FOAM SEAL 12.5x5 L: 2.5M FOAM SEAL 12.5X5 L: 2.5M
Chaffoteaux part no. 60081273		 £23,36
308 Part number 60057488, SPIRE CLIP SPIRE CLIP
Chaffoteaux part no. 60057488		 £0,78
309   BASE - BOX
Chaffoteaux part no. 61307613		 £19,98
311   CASE COVER
Chaffoteaux part no. 60081851		 £56,39
314 Part number 61010109, GROMMET GROMMET
Chaffoteaux part no. 61010109		 £3,87
315 Part number 60039017, GROMMET GROMMET
Chaffoteaux part no. 60039017		 £1,98
401 Part number 61307584, GAS VALVE GAS VALVE
Chaffoteaux part no. 61307584		 £234,51
401   GAS VALVE LPG
Chaffoteaux part no. 61312986		 £188,08
403   SCREW CLXS M 4-30
Chaffoteaux part no. 61015154		 £1,56
403   NOW USE 61015154 SCREW CLXS M 4-30
Chaffoteaux part no. 61310333
406   GASKET
Chaffoteaux part no. 61308335		 £4,70
407 Part number 61307585, FAN ASSY FAN ASSY
Chaffoteaux part no. 61307585		 £192,28
408   SCREW CLSX M 5-12
Chaffoteaux part no. 61308327		 £0,53
410 Part number 61306072, GASKET GASKET
Chaffoteaux part no. 61306072		 £1,92
412 Part number 61310121, SILENCER SILENCER
Chaffoteaux part no. 61310121		 £19,70
418   CONNECTION
Chaffoteaux part no. 61012649		 £10,27
436 Part number 60021061-40, O-RING D: 22-2.6 O-RING D: 22-2.6
Chaffoteaux part no. 60021061-40		 £0,99
501   TUBE-EXCHANGER TO THREE-WAY VALVE
Chaffoteaux part no. 61310175		 £9,18
502 Part number 61002399, HEATING CONNECTION PIN HEATING CONNECTION PIN
Chaffoteaux part no. 61002399		 £1,96
504 Part number 60024164-51, O-RING D: 17-4 O-RING D: 17-4
Chaffoteaux part no. 60024164-51		 £1,18
505 Part number 60081839, THREE-WAY VALVE THREE-WAY VALVE
Chaffoteaux part no. 60081839		 £141,30
506 Part number 61010050, CLIP CLIP
Chaffoteaux part no. 61010050		 £3,87
507 Part number 61010572, OVERHEAT THERMOSTAT 100C OVERHEAT THERMOSTAT 100C
Chaffoteaux part no. 61010572		 £6,87
510 Part number 61000733, THERMISTOR TEMP. SENSOR THERMISTOR TEMP. SENSOR
Chaffoteaux part no. 61000733		 £28,04
511 Part number 61002083, TEMPERATURE SENSOR CLIP TEMPERATURE SENSOR CLIP
Chaffoteaux part no. 61002083		 £1,08
514 Part number 61302409-01, SANITARY HEAT EXCHANGER (16 P.) SANITARY HEAT EXCHANGER (16 P.)
Chaffoteaux part no. 61302409-01		 £112,94
514 Part number 61302409, NOW USE 61302409-01 WATER / WATER HEAT EXCHANGER 16 NOW USE 61302409-01 WATER / WATER HEAT EXCHANGER 16
Chaffoteaux part no. 61302409
516 Part number 61307589, CLIP (TO 03/06) CLIP (TO 03/06)
Chaffoteaux part no. 61307589		 £2,72
518 Part number 61014228, TOP INTERFACE SYSTEM TOP INTERFACE SYSTEM
Chaffoteaux part no. 61014228		 £44,51
520 Part number 61012952, FLEXIBLE PIPE FLEXIBLE PIPE
Chaffoteaux part no. 61012952		 £22,21
522 Part number 61010005, CLIP CLIP
Chaffoteaux part no. 61010005		 £1,53
526 Part number 61009834-14, O-RING 8.9X2.7 O-RING 8.9X2.7
Chaffoteaux part no. 61009834-14		 £1,57
529 Part number 61014220, HEATING FLOW TUBE HEATING FLOW TUBE
Chaffoteaux part no. 61014220		 £11,24
530 Part number 60061855-19, SHEET GASKET D: 24-17-1.5 SHEET GASKET D: 24-17-1.5
Chaffoteaux part no. 60061855-19		 £0,69
531   HYDRAULIC PLATE
Chaffoteaux part no. 61014214		 £7,68
532 Part number 60081471, WATER THROTTLE WATER THROTTLE
Chaffoteaux part no. 60081471		 £38,44
535 Part number 61012963, TAP BODY TAP BODY
Chaffoteaux part no. 61012963		 £18,43
537 Part number 60024164-18, O-RING D: 13.6-2.7 O-RING D: 13.6-2.7
Chaffoteaux part no. 60024164-18		 £0,44
540 Part number 61012946, SPINDLE SPINDLE
Chaffoteaux part no. 61012946		 £7,41
542   CLIP
Chaffoteaux part no. 60079845		 £2,53
550 Part number 61014218, HEATING RETURN TUBE HEATING RETURN TUBE
Chaffoteaux part no. 61014218		 £15,84
551   GAS TUBE
Chaffoteaux part no. 61307590		 £35,38
552 Part number 61015245, PLUG PLUG
Chaffoteaux part no. 61015245		 £5,13
553 Part number 60024164-13, O-RING D: 8.9-1.9 O-RING D: 8.9-1.9
Chaffoteaux part no. 60024164-13		 £0,50
558 Part number 61306995, PUMP LEAD (2 SPEEDS) PUMP LEAD (2 SPEEDS)
Chaffoteaux part no. 61306995		 £15,06
561 Part number 61014172, BOTTOM INTERFACE SYSTEM BOTTOM INTERFACE SYSTEM
Chaffoteaux part no. 61014172		 £54,86
564 Part number 61009834-30, O-RING D: 24.6-3.6 O-RING D: 24.6-3.6
Chaffoteaux part no. 61009834-30		 £0,90
565 Part number 61305560, HEATING FILTER HEATING FILTER
Chaffoteaux part no. 61305560		 £2,84
567 Part number 60030898-03, CLIP CLIP
Chaffoteaux part no. 60030898-03		 £1,00
569 Part number 61002249, LIP SEAL x1 LIP SEAL X1
Chaffoteaux part no. 61002249		 £1,88
570   HEATING RETURN TUBE
Chaffoteaux part no. 61310176		 £8,18
571 Part number 61009833-37, O-RING D: 16-1.9 O-RING D: 16-1.9
Chaffoteaux part no. 61009833-37		 £0,60
572 Part number 61303461, PUMP + AIR SEPARATOR 15/60 PUMP + AIR SEPARATOR 15/60
Chaffoteaux part no. 61303461		 £273,54
572   PUMP HEAD UPMO 60PH
Chaffoteaux part no. 65119656-01		 £273,54
572 Part number 61301964, NOW USE 65119656-01 PUMP + AIR SEPARATOR 15/50 NOW USE 65119656-01 PUMP + AIR SEPARATOR 15/50
Chaffoteaux part no. 61301964
573 Part number 61000652-10, CAPACITOR CAPACITOR
Chaffoteaux part no. 61000652-10		 £23,72
574 Part number 61304618, GASKET KIT GASKET KIT
Chaffoteaux part no. 61304618		 £4,09
575 Part number 61308091, O-RING 17.86X2.62 O-RING 17.86X2.62
Chaffoteaux part no. 61308091		 £1,31
582 Part number 61012790, CYLINDER 6L CYLINDER 6L
Chaffoteaux part no. 61012790		 £290,68
583 Part number 61012808, LINKING TUBE LINKING TUBE
Chaffoteaux part no. 61012808		 £6,61
584 Part number 61012886, NUT NUT
Chaffoteaux part no. 61012886		 £39,11
585 Part number 61012909-02, PIN PIN
Chaffoteaux part no. 61012909-02		 £1,18
586 Part number 61012983, CLIP CLIP
Chaffoteaux part no. 61012983		 £1,54
587   WASHER D: 12.5-5.2-5
Chaffoteaux part no. 61015757		 £0,54
588 Part number 61304608, AIR SEPARATOR HEAD ASSEMBLY AIR SEPARATOR HEAD ASSEMBLY
Chaffoteaux part no. 61304608		 £23,62
589 Part number 61012743, STOPPED WATER THROTTLE BODY STOPPED WATER THROTTLE BODY
Chaffoteaux part no. 61012743		 £12,40
590 Part number 61014983, COLD WATER TUBE COLD WATER TUBE
Chaffoteaux part no. 61014983		 £13,91
591 Part number 61002490, PLUG PLUG
Chaffoteaux part no. 61002490		 £1,21
592   WASHER D: 12-6.2-1.2
Chaffoteaux part no. 60007059-03		 £0,41
593   NUT H M 6-1
Chaffoteaux part no. 60026501-03		 £0,44
594 Part number 61009834-15, O-RING D: 2.7-10.5 O-RING D: 2.7-10.5
Chaffoteaux part no. 61009834-15		 £0,50
595 Part number 60022831-07, SHEET GASKET D: 10.5-6.2-1.5 SHEET GASKET D: 10.5-6.2-1.5
Chaffoteaux part no. 60022831-07		 £1,31
596 Part number 61014984, PRESSURE RELIEF VALVE DRAIN PRESSURE RELIEF VALVE DRAIN
Chaffoteaux part no. 61014984		 £20,79
597 Part number 60061853-02, SHEET GASKET D: 13.9-10.4-1.5 SHEET GASKET D: 13.9-10.4-1.5
Chaffoteaux part no. 60061853-02		 £0,49
598 Part number 60081266, TUBE PVC D: 9x12 L: 1M TUBE PVC D: 9X12 L: 1M
Chaffoteaux part no. 60081266		 £7,83
599 Part number 61020242, CONNECTION CONNECTION
Chaffoteaux part no. 61020242		 £10,38
601   ELECTRICAL BOX
Chaffoteaux part no. 61311319		 £299,37
602 Part number 61020510, SCREW FX90 L:16 SCREW FX90 L:16
Chaffoteaux part no. 61020510		 £0,44
604   INSTRUCTIONS SUPPORT
Chaffoteaux part no. 61309315		 £7,23
607 Part number 61002105-20, IGNITER IGNITER
Chaffoteaux part no. 61002105-20		 £50,54
609 Part number 61010014, CONNECTOR COVER CONNECTOR COVER
Chaffoteaux part no. 61010014		 £5,81
610   FAN-IGNITER CABLE
Chaffoteaux part no. 61309837		 £30,16
611   WIRE ASSEMBLY
Chaffoteaux part no. 61309454		 £17,52
612   CONNECTION STRIP
Chaffoteaux part no. 61010152		 £4,36
613   TAPPING SCREW TCBL D:4 L:10
Chaffoteaux part no. 61020509		 £0,42
614 Part number 61010007, ELECTRICAL BOX COVER ELECTRICAL BOX COVER
Chaffoteaux part no. 61010007		 £11,02
615 Part number 61310357, PRINTED CIRCUIT BOARDS PRINTED CIRCUIT BOARDS
Chaffoteaux part no. 61310357		 £375,20
617 Part number 61010006, ELECTRIC BOX PLATE ELECTRIC BOX PLATE
Chaffoteaux part no. 61010006		 £30,81
618   PLUG
Chaffoteaux part no. 61011316		 £1,07
621   TRANSMITTER OF LEDS
Chaffoteaux part no. 61306012		 £13,25
622   CONTROL PANEL
Chaffoteaux part no. 61306019		 £7,09
623   SIGHT GLASS
Chaffoteaux part no. 61303830		 £2,65
627 Part number 61003456, FUSE 250V 2A FUSE 250V 2A
Chaffoteaux part no. 61003456		 £1,20
628 Part number 61003634, FUSE 250V 1A - TEMPORISED FUSE 250V 1A - TEMPORISED
Chaffoteaux part no. 61003634		 £1,20
629 Part number 61003635, FUSE 250V 1.25A - TEMPORISED FUSE 250V 1.25A - TEMPORISED
Chaffoteaux part no. 61003635		 £1,20
630 Part number 61307845, FUSE 250V 0.315A - TEMPORISED FUSE 250V 0.315A - TEMPORISED
Chaffoteaux part no. 61307845		 £1,20
632   CLOSURE PLATE
Chaffoteaux part no. 61304599		 £0,89
634   CONNECTING TERMINAL
Chaffoteaux part no. 61308032		 £2,43
634   NOW USE 61308032 FEEDER
Chaffoteaux part no. 61308031
638 Part number 61305893, CABLE THREE WAY VALVE CABLE THREE WAY VALVE
Chaffoteaux part no. 61305893		 £13,20
639 Part number 61308086, ELECTRODE CABLE ELECTRODE CABLE
Chaffoteaux part no. 61308086		 £4,42
640   TRANSFORMER
Chaffoteaux part no. 61308149		 £66,66
701   TOP STAY PLATE
Chaffoteaux part no. 61010029		 £5,69
703 Part number 60056676-06, EXPANSION VESSEL 7L EXPANSION VESSEL 7L
Chaffoteaux part no. 60056676-06		 £142,17
704   OBSOLETE CHASSIS
Chaffoteaux part no. 61010028
705 Part number 61010170, EXPANSION VESSEL AIR HOSE EXPANSION VESSEL AIR HOSE
Chaffoteaux part no. 61010170		 £13,82
706   TAPPING SCREW CBLSX D: 6.3-19
Chaffoteaux part no. 61014516		 £0,54
709 Part number 60081824, FLEXIBLE PIPE KIT FLEXIBLE PIPE KIT
Chaffoteaux part no. 60081824		 £13,38
710 Part number 61002406, CLIP CLIP
Chaffoteaux part no. 61002406		 £1,40
711 Part number 61009834-10, O-RING 5.7X1.9 O-RING 5.7X1.9
Chaffoteaux part no. 61009834-10		 £0,50
802   CASE
Chaffoteaux part no. 61010016		 £459,42
805 Part number 61303158, PRESSURE GAUGE PRESSURE GAUGE
Chaffoteaux part no. 61303158		 £27,20
806   DOOR
Chaffoteaux part no. 61306020		 £9,19
807   SERIGRA. STRIP (WITHOUT PROG.)
Chaffoteaux part no. 61310207		 £16,79
813 Part number 61015797, SPACER SPACER
Chaffoteaux part no. 61015797		 £4,03
902 Part number 61020388, WATER FLOW SERVICE TAP WATER FLOW SERVICE TAP
Chaffoteaux part no. 61020388		 £38,12
903 Part number 61020916, HOT WATER CONNECTION HOT WATER CONNECTION
Chaffoteaux part no. 61020916		 £13,20
904 Part number 61020389, GAS SERVICE TAP GAS SERVICE TAP
Chaffoteaux part no. 61020389		 £23,64
905   COLD WATER TAP
Chaffoteaux part no. 61302612-01		 £88,33
905 Part number 61302612, NOW USE 61302612-01 COLD WATER TAP NOW USE 61302612-01 COLD WATER TAP
Chaffoteaux part no. 61302612
907   HOOKING BRACKET
Chaffoteaux part no. 61012457		 £7,16
908   WASHER D: 14.2-7.2-1.2
Chaffoteaux part no. 60005369-03		 £0,41
909   WOOD SCREW
Chaffoteaux part no. 60025617-03		 £0,79
910   BOTTOM STAY PLATE
Chaffoteaux part no. 61011683		 £6,59
918   LOCK NUT 3/4"
Chaffoteaux part no. 60031140		 £1,20
919 Part number 61002775-07, FLOW REGULATORE 7L/MIN(DARK GREEN) FLOW REGULATORE 7L/MIN(DARK GREEN)
Chaffoteaux part no. 61002775-07		 £7,96
919 Part number 61002775-08, FLOW REGULATORE 8L/MIN (WHITE) FLOW REGULATORE 8L/MIN (WHITE)
Chaffoteaux part no. 61002775-08		 £7,75
919 Part number 61002775-10, FLOW REGULATORE 10L/MIN (BLUE) FLOW REGULATORE 10L/MIN (BLUE)
Chaffoteaux part no. 61002775-10		 £7,75
919 Part number 61002775-12, FLOW REGULATORE 12L/MIN (RED) FLOW REGULATORE 12L/MIN (RED)
Chaffoteaux part no. 61002775-12		 £7,75
919 Part number 61002775-14, FLOW REGULATORE 14L/MIN (PINK) FLOW REGULATORE 14L/MIN (PINK)
Chaffoteaux part no. 61002775-14		 £7,66
919 Part number 61002775-15, FLOW REGULATORE 15L/MIN (PALE GREEN) FLOW REGULATORE 15L/MIN (PALE GREEN)
Chaffoteaux part no. 61002775-15		 £7,68
920 Part number 60031139, LOCK NUT 1/2" LOCK NUT 1/2"
Chaffoteaux part no. 60031139		 £2,27
922 Part number 61302611, HAND LEVER BLACK HAND LEVER BLACK
Chaffoteaux part no. 61302611		 £0,64
923 Part number 61302610, HAND LEVER YELLOW HAND LEVER YELLOW
Chaffoteaux part no. 61302610		 £0,79
925 Part number 60081028, DRAIN SCREW ASSY DRAIN SCREW ASSY
Chaffoteaux part no. 60081028		 £6,85
927 Part number 61016378, PRESSURE TEST POINT SCREW PRESSURE TEST POINT SCREW
Chaffoteaux part no. 61016378		 £0,55
936 Part number 61009834-18, O-RING D: 13.6-2.7 O-RING D: 13.6-2.7
Chaffoteaux part no. 61009834-18		 £0,50
937 Part number 60081266-02, TUBE PVC D: 13x17 L: 1M TUBE PVC D: 13X17 L: 1M
Chaffoteaux part no. 60081266-02		 £18,04
938 Part number 61020933, PRESSURE RELIEF VALVE PRESSURE RELIEF VALVE
Chaffoteaux part no. 61020933		 £28,36
939 Part number 60061855-14, WASHER D: 18.4-12.2-1.5 WASHER D: 18.4-12.2-1.5
Chaffoteaux part no. 60061855-14		 £0,60
943   ACCESSORY KIT
Chaffoteaux part no. 61309329		 £39,27
947   CLIP
Chaffoteaux part no. 61012927		 £0,96
5002   CONVERSION KIT G20 > G31
Chaffoteaux part no. 61311759		 £20,17
5020   OBSOLETE SLEEVE
Chaffoteaux part no. 61018789
5021   OBSOLETE EXTREMITY CHOCK DRAUG DIV SIDE
Chaffoteaux part no. 61014400
5030   JIG PLATE
Chaffoteaux part no. 61309325		 £7,75
5033   ROD PLATE
Chaffoteaux part no. 61010932		 £35,99
5035   OBSOLETE SOUND-PROOFING KIT
Chaffoteaux part no. 61305676
5040   OBSOLETE USERS' INSTRUCTIONS
Chaffoteaux part no. 61311238
6003   SIMULATING BOX 3 WAY VALVE
Chaffoteaux part no. 61012597		 £264,83
6006 Part number 61302650, SPANNER SPANNER
Chaffoteaux part no. 61302650		 £22,44
6007 Part number 61306970, STOPPED W/THROT. CONNECTOR KIT STOPPED W/THROT. CONNECTOR KIT
Chaffoteaux part no. 61306970		 £8,08


Heating spares made simple this website is secured by Geotrust

 HSP K J Plumbing Factors

Copyright ©2026 Heating Spare Parts - All Rights Reserved

Site Map | About Us | Parts Lists & Diagrams | Privacy Policy | Terms & Conditions

Facebook Twitter/X
