CHAFFOTEAUX
V32A BF MULTIPOINT 1N - (Appliance Overview)
Appliance Code: 52-980-02

Appliance Diagram


Appliance Overview diagram for Chaffoteaux V32A BF Multipoint 1NClick the diagram to open it on a new page

You can then pinch & zoom to adjust the size.

1   OBSOLETE INDICATOR DISC
Chaffoteaux part no. 60027634

2   GAS CONTROL KNOB
Chaffoteaux part no. 60028979
£2.64
3   OBSOLETE KNURLED RING
Chaffoteaux part no. 0018732.00

5   OBSOLETE HEATING BODY
Chaffoteaux part no. 0025919.07

6 Part number 60081273-06, GLASS FIBRE D: 3.5 L: 1M GLASS FIBRE D: 3.5 L: 1M
Chaffoteaux part no. 60081273-06
£13.79
7   OBSOLETE SIGHT GLASS ASSY
Chaffoteaux part no. 60081047
£28.66
8   OBSOLETE WINDOW GASKET
Chaffoteaux part no. 0025818.00

10 Part number 60010764-03, SCREW CS M 3-8 SCREW CS M 3-8
Chaffoteaux part no. 60010764-03
£0.56
11   OBSOLETE NUT - FOR WINDOW
Chaffoteaux part no. 0010759.00

12   OBSOLETE PIEZO IGNITER
Chaffoteaux part no. 0031171.00

13   OBSOLETE ELECTRODE & CABLE ASSY
Chaffoteaux part no. 0031798.00

14   OBSOLETE BOILER IGNITOR V32
Chaffoteaux part no. 0099237.00

15   OBSOLETE SIGHT GLASS ASSEMBLY
Chaffoteaux part no. 0099268.23

21   INJECTOR D: 1.18
Chaffoteaux part no. 60014154-18
£1.75
22   OBSOLETE MANIFOLD
Chaffoteaux part no. 0025022.30

23   PRESSURE TEST POINT SCREW
Chaffoteaux part no. 60019445
£1.24
24   OBSOLETE RESTRICTOR GASKET 5.3
Chaffoteaux part no. 0023991.16

25   OBSOLETE PILOT
Chaffoteaux part no. 60100302-20

26   OBSOLETE PILOT HEAD WITH ELECTRODE SUPPORT
Chaffoteaux part no. 0022956.00

27   OBSOLETE PILOT BODY
Chaffoteaux part no. 0024167.00

30   OBSOLETE PILOT BODY
Chaffoteaux part no. 0024167.10

31 Part number 60026646, PILOT INJECTOR D: 0.3 PILOT INJECTOR D: 0.3
Chaffoteaux part no. 60026646
£7.83
32   GASKET (/INJECTOR)
Chaffoteaux part no. 60026281
£0.54
33   OBSOLETE GAS VALVE BODY
Chaffoteaux part no. 0021355.00

34   OBSOLETE MAIN GAS VALVE
Chaffoteaux part no. 60018154

35   OBSOLETE NUT
Chaffoteaux part no. 0029552.08

36   OBSOLETE SPRING SEAT /
Chaffoteaux part no. 0015586.01

37   OBSOLETE WASHER
Chaffoteaux part no. 0019866.17

39   OBSOLETE BI-METALLIC STRIP
Chaffoteaux part no. 60006073

40   OBSOLETE BI METAL STEM
Chaffoteaux part no. 0015402.00

45   OBSOLETE SPRING SEAT
Chaffoteaux part no. 60018278

46   SPRING
Chaffoteaux part no. 60022159
£1.73
47   OBSOLETE VALVE-GAS MAIN LP
Chaffoteaux part no. 0022186.00

48   GAS VALVE FACING
Chaffoteaux part no. 60011473
£0.89
49   OBSOLETE GAS SECTION V32 & A
Chaffoteaux part no. 0021465.00

50   GASKET (/GAS SECTION)
Chaffoteaux part no. 60018652
£0.96
51   OBSOLETE GAS COCK INLET MANIFOLD ASSY
Chaffoteaux part no. 60027830

52 Part number 60018653, GASKET(/Box cover) GASKET(/BOX COVER)
Chaffoteaux part no. 60018653
£0.94
53   OBSOLETE GAS COCK OPERATING MECHANISM M12 V32 M26
Chaffoteaux part no. 0026910.00

54   OBSOLETE GAS SERVICE COCK
Chaffoteaux part no. 0026155.00

56 Part number 60021061-07, O-RING D: 1.9-2.55 O-RING D: 1.9-2.55
Chaffoteaux part no. 60021061-07
£0.41
60   OBSOLETE WATER SECTION ASSY V32
Chaffoteaux part no. 0099145.00

61   OBSOLETE VENTURI 4.5MM DIAMETER
Chaffoteaux part no. 0021500.00

62   OBSOLETE SLOW IGNITION ASSEMBLY
Chaffoteaux part no. 0018376.01

63 Part number 60024164-13, O-RING D: 8.9-1.9 O-RING D: 8.9-1.9
Chaffoteaux part no. 60024164-13
£0.50
65 Part number 60100147-20, WATER SECTION REPAIR KIT WATER SECTION REPAIR KIT
Chaffoteaux part no. 60100147-20
£17.21
66   OBSOLETE PLASTIC TOP COVER
Chaffoteaux part no. 0018961.00

67   BEARING PLATE
Chaffoteaux part no. 60016416
£2.54
68 Part number 60025809-30, DIAPHRAGM DIAPHRAGM
Chaffoteaux part no. 60025809-30
£7.52
69 Part number 60043792, WATER SERVICE TAP WATER SERVICE TAP
Chaffoteaux part no. 60043792
£78.53
100   OBSOLETE COMPLETE GASKETS KIT
Chaffoteaux part no. 60023865

101   OBSOLETE WASHER SET V32 FULL KIT
Chaffoteaux part no. 0023864.00

102   GASKETS SET
Chaffoteaux part no. 60037306
£45.36
