MODULOFLAME 280 - (Appliance Overview)

Appliance Diagram


Appliance Overview diagram for Chaffoteaux Moduloflame 280Click the diagram to open it on a new page

You can then pinch & zoom to adjust the size.

102 Part number 60061855-01, SHEET GASKET D: 24-18.2-1.5 SHEET GASKET D: 24-18.2-1.5
Chaffoteaux part no. 60061855-01
£0.64
103   PLUG
Chaffoteaux part no. 60076181
£1.98
104   OBSOLETE WASHER 17.9 X 13.2 X 1.5
Chaffoteaux part no. 0019869.01

105   OBSOLETE PLUG 3/8 M
Chaffoteaux part no. 61001583

106 Part number 60004806-03, TRAPPED NUT M 6 TRAPPED NUT M 6
Chaffoteaux part no. 60004806-03
£0.50
107   OBSOLETE INSULATION
Chaffoteaux part no. 60060085

108   OBSOLETE FIXING STRAP
Chaffoteaux part no. 0054613.00

110   TRAPPED NUT M 6
Chaffoteaux part no. 60008588-03
£2.29
116 Part number 60061855-14, WASHER D: 18.4-12.2-1.5 WASHER D: 18.4-12.2-1.5
Chaffoteaux part no. 60061855-14
£0.56
201 Part number 61008250, RECLOSING BOX RECLOSING BOX
Chaffoteaux part no. 61008250
£236.16
203 Part number 61007350, GAS ASSY GAS ASSY
Chaffoteaux part no. 61007350
£542.07
205   GAS TUBE KIT
Chaffoteaux part no. 60081551
£34.17
206   OBSOLETE WASHER 24.0 X 18.2 X 1.5
Chaffoteaux part no. 0022835.01

207   ISOLATING COCK KIT
Chaffoteaux part no. 60081214
£45.87
223 Part number 60019316-03, SCREW HS M 6-15 SCREW HS M 6-15
Chaffoteaux part no. 60019316-03
£0.53
401   BURNER HEAD
Chaffoteaux part no. 60062612
£92.76
403 Part number 60081408, BURNER BASE KIT BURNER BASE KIT
Chaffoteaux part no. 60081408
£90.61
413 Part number 60031035-03, SCREW M 5-25 SCREW M 5-25
Chaffoteaux part no. 60031035-03
£0.58
414 Part number 61010131, SCREW HX M 5-12 SCREW HX M 5-12
Chaffoteaux part no. 61010131
£0.39
415   OBSOLETE WASHER 10.0 X 5.0 X 1.0
Chaffoteaux part no. 0022118.03

416   SCREW M 5-35
Chaffoteaux part no. 60036520-03
£2.57
417 Part number 60081202, BURNER GASKET KIT BURNER GASKET KIT
Chaffoteaux part no. 60081202
£5.76
419 Part number 60036899, IGNITION ELECTRODE IGNITION ELECTRODE
Chaffoteaux part no. 60036899
£32.68
423 Part number 60031527-03, SCREW M 6-10 SCREW M 6-10
Chaffoteaux part no. 60031527-03
£0.62
433   GAS RESTRICTOR D: 6.4
Chaffoteaux part no. 60028417-45
£17.33
438   TAPPING SCREW CBLZ D: 3.9-9.5
Chaffoteaux part no. 60050460-03
£0.80
440 Part number 60033717, GASKET (/Manifold) GASKET (/MANIFOLD)
Chaffoteaux part no. 60033717
£1.41
501 Part number 61007557, HEAT EXCHANGER HEAT EXCHANGER
Chaffoteaux part no. 61007557
£324.52
502 Part number 60081489, COMBUSTION CHAMBER LINING KIT COMBUSTION CHAMBER LINING KIT
Chaffoteaux part no. 60081489
£39.29
506 Part number 61008282, OVERHEAT THERMOSTAT 105C OVERHEAT THERMOSTAT 105C
Chaffoteaux part no. 61008282
£15.24
507 Part number 60031521-03, TAPPING SCREW CBLZ D: 3.5-6.5 TAPPING SCREW CBLZ D: 3.5-6.5
Chaffoteaux part no. 60031521-03
£0.37
601 Part number 61010125, TAPPING SCREW CBLSX D: 4.2-9.5 TAPPING SCREW CBLSX D: 4.2-9.5
Chaffoteaux part no. 61010125
£0.39
702   WASHER D: 14.2-7.2-1.2
Chaffoteaux part no. 60005369-03
£0.38
705 Part number 61003959, OVERHEAT THERMOSTAT 75C OVERHEAT THERMOSTAT 75C
Chaffoteaux part no. 61003959
£23.99
801   SERIGRAPHED STRIP
Chaffoteaux part no. 61003967
£25.73
804 Part number 61009995, PRINTED CIRCUIT BOARD PRINTED CIRCUIT BOARD
Chaffoteaux part no. 61009995
£182.44
805   SWITCH CABLE
Chaffoteaux part no. 61011518
£12.75
806 Part number 61009766, HEATING THERMOSTAT HEATING THERMOSTAT
Chaffoteaux part no. 61009766
£48.35
807   SCREW M 4-6
Chaffoteaux part no. 60019197-03
£0.89
808   CABLE - FLAME
Chaffoteaux part no. 61011522
£6.99
810   CLIP
Chaffoteaux part no. 60074039
£0.69
811   BLACK AQUASTAT KNOB
Chaffoteaux part no. 61004996
£3.28
812   OBSOLETE SWITCH
Chaffoteaux part no. 61007193

814 Part number 61009730, FUSE HOLDER FUSE HOLDER
Chaffoteaux part no. 61009730
£7.27
816   RED SIGNAL
Chaffoteaux part no. 61007529
£6.29
817   OBSOLETE AQUASTAT LEAD
Chaffoteaux part no. 61011520

819   FUSE HOLDER CABLE
Chaffoteaux part no. 61003964
£11.62
832   BURNER CABLE
Chaffoteaux part no. 61009199
£44.30
832   BURNER CABLE
Chaffoteaux part no. 61009198
£50.21
836   CONTACT PIN 7 P.
Chaffoteaux part no. 61007668
£20.28
837   CONNECTION STRIP
Chaffoteaux part no. 61010152
£4.02
852 Part number 61002725, CONNECTION STRIP CONNECTION STRIP
Chaffoteaux part no. 61002725
£0.90
901 Part number 61010612, PUMP UP 15/50  230V PUMP UP 15/50 230V
Chaffoteaux part no. 61010612
£166.94
902 Part number 60080154, PUMP INLET TUBE PUMP INLET TUBE
Chaffoteaux part no. 60080154
£15.96
903 Part number 60030898-03, CLIP CLIP
Chaffoteaux part no. 60030898-03
£0.74
904 Part number 60024164-35, O-RING D: 27.8-3.6 O-RING D: 27.8-3.6
Chaffoteaux part no. 60024164-35
£0.53
909 Part number 60081194, ISOLATING COCK KIT ISOLATING COCK KIT
Chaffoteaux part no. 60081194
£62.12
912 Part number 61000652-10, CAPACITOR CAPACITOR
Chaffoteaux part no. 61000652-10
£21.93
1002 Part number 60054448, NON-RETURN VALVE NON-RETURN VALVE
Chaffoteaux part no. 60054448
£37.40
1003 Part number 0061856.03, NOW USE 60061856-03 WASHER 29.9 X 20.0 X 1.5 NOW USE 60061856-03 WASHER 29.9 X 20.0 X 1.5
Chaffoteaux part no. 0061856.03

1003 Part number 60061856-03, SHEET GASKET D: 29.9-20-1.5 SHEET GASKET D: 29.9-20-1.5
Chaffoteaux part no. 60061856-03
£1.40
1100   OUTGOING TUBE - HEATING BODY
Chaffoteaux part no. 61007604
£12.67
1200 Part number 60075709, WATER SECTION ASSY WATER SECTION ASSY
Chaffoteaux part no. 60075709
£247.41
1201 Part number 60081558, BEARING PLATE ASSY BEARING PLATE ASSY
Chaffoteaux part no. 60081558
£66.18
1202 Part number 60019870-02, NOW USE 60061853-02 THERM WASHER D: 13.9-10.4-1.5 NOW USE 60061853-02 THERM WASHER D: 13.9-10.4-1.5
Chaffoteaux part no. 60019870-02

1202 Part number 60010419, DIAPHRAGM DIAPHRAGM
Chaffoteaux part no. 60010419
£2.33
1202 Part number 60061853-02, SHEET GASKET D: 13.9-10.4-1.5 SHEET GASKET D: 13.9-10.4-1.5
Chaffoteaux part no. 60061853-02
£0.41
1205 Part number 60061854-11, SHEET GASKET D: 14.8-10.3-1.5 SHEET GASKET D: 14.8-10.3-1.5
Chaffoteaux part no. 60061854-11
£0.54
1205 Part number 0061854.11, NOW USE 60061854-11 WASHER 14.8 X 10.3 X 1.5 NOW USE 60061854-11 WASHER 14.8 X 10.3 X 1.5
Chaffoteaux part no. 0061854.11

1206 Part number 60022639, GLAND GLAND
Chaffoteaux part no. 60022639
£7.35
1207   SCREW M 6-12
Chaffoteaux part no. 60000101-13
£0.62
1212   MICRO SWITCH BOX
Chaffoteaux part no. 60078619
£34.50
1214   OBSOLETE BRASS COLLAR
Chaffoteaux part no. 0074185.00

1215   SCREW CB M 6-12
Chaffoteaux part no. 60032390-08
£0.58
1404   NUT H M 6-1
Chaffoteaux part no. 60026501-03
£0.41
1411 Part number 60014044, SCREW CLS M 6-14 SCREW CLS M 6-14
Chaffoteaux part no. 60014044
£0.63
1412 Part number 60013183-03, STAR WASHER D: 6 STAR WASHER D: 6
Chaffoteaux part no. 60013183-03
£0.41
1437   KNOB
Chaffoteaux part no. 60081592
£10.49
1501   FLANGE GASKET
Chaffoteaux part no. 61000616
£10.54
1502   BOLT
Chaffoteaux part no. 61000615
£30.07
5001   OBSOLETE SIDE PANEL
Chaffoteaux part no. 1003622.00

5015   OBSOLETE CONVERSION KIT NAT > LPG
Chaffoteaux part no. 61003976
